Ninestars DZT-80-4 Manual

Introduction

Nine stars automatic infrared sensor trash cans are designed and created to make life simpler. Our automatic infrared allows an effortless way to dispose of trash. Simply put an object or hand above the sensor and the lid will then automatically open within seconds. When the object or hand is no longer within the sensor's range the lid will automatically close in seconds. Our trashcan utilizes the infrared sensor technology to create a touch-less environment. We use the highest quality material and most up to date technology in our products to ensure excellence. We keep the sensor near the lip of the lid to make disposing trash easier because once the sensor detects the trash you simply drop the trash in the trash can once lid opens.

Overview

Contents of the box

Remove all components of trash can from the box.

• Lid
• Liner ring
• Trash container

Battery installation

Locate the battery compartment underneath the trash can lid. Squeeze the tab on the battery cap in and carefully lift up to open. Insert three (3) HEAVY DUTY "D" size batteries. Insert the batteries in accordance with the positive (+) and negative (-) poles. Place the battery cap back over the compartment

Insert the trash bag

Insert the trash bag using the liner ring (see diagram). Fold the trash bag over the edges of the liner ring. Place the trash bag and the liner ring in the trash container. Tuck the bag completely into the base of the container so that edges of the bag do not show once the lid is placed on top of the base.

Insert bag through the liner ring hoop first, then fold bag edges over the ring.
DO NOT put liner ring inside the bag

Trash can set up

Align the lid with the base of the trash can and gently place the lid on top.

Turn the trash can on/off

The power switch is located on the back of the automatic lid. When the switch is in the "I" position the trash can is "ON". When the switch is in the "O" position the trash can is "OFF".

How to use your trash can

Place your hand or an object within inches of the motion sensor (located on the lid). The lid will open instantly. Once your hand or object is out of range of the sensor the lid will close within seconds.

Manual Open/close button

• The "open" button located on the lid if pressed, will open the lid. The lid will remain open until the "close" button is pressed.
• The "close" button will close the lid if the lid has been manually opened and will also reset the lid to sensor mode.

Technical Facts

1. A red light will flash when the trash can is in the "ON" position.
2. A green light will appear when the lid opens.
3. A red light will appear when the lid closes.
4. A yellow indicator light will appear when the batteries are low. Replace the batteries.

Trouble Shooting

Note: If the above solutions do not correct the problem please contact Nine Stars Group USA Inc Customer Service.

1. Do not submerge the trash can into water because it is equipped with many electrical components. The trash can may be wiped with a damp cloth.
2. Do not manually force the lid close; this can cause damage to the internal gears that allow the lid to open and close.
3. Replace used batteries in a timely manner to prevent battery acid leakage. Battery acid may cause damage to the electrical components of the trash can.
4. Do not place trash can in direct sunlight.
5. Do not mix new and used batteries.
6. Do not mix alkaline, standard (zinc-carbon), or rechargeable (NiCd, NiMH, etc) batteries.

Nine Stars Group (USA) Inc.
1929 Mount Vernon Ave., Pomona, California 91768
www.ninestarsusa.com
