Healthtree Medical JKS50A Instruction Manual

Instruction Manual
Pulse Oximeter
JKS50A
Please read the user manual carefully and keep it for future reference. If
you need any further assistance, please contact our customer support
team.
1
Introduction – English
Precautions for use
1. In order to have more accurate measurements of SpO2 and PR, the
oximeter should be used in quiet and comfortable environment.
2. When the oximeter is in use, it must be ensured the batteries have
sufficient capacity; otherwise there might be such phenomena as
starting-up abnormalities or inaccurate measurement data, etc.
3．Please use a dry finger to measure, and keep still when measuring
4. Please do not measure with nail polish/fake nails/excessive
fingernails
5. Since dark-skinned people have a stronger ability to absorb infrared
rays, it takes longer to measure
6. The temperature will affect the measurement results. If the
temperature of the tested finger is too low, please rub the finger to warm
it up and measure again.
7. Excessive ambient light (including fluorescent lamps, double rubies,
etc., infrared heaters, direct sunlight, etc.) will affect the measurement
results. Please cover appropriately or change the measurement
environment.
8. This oximeter is suitable for children aged 2 years and above. The
oximeter can not only measure fingers, but also toes and soles (it mainly
depends on the development level of the child's measurement area.
Fingers that are too thin, toes and soles that are too large and thick are
not suitable for measurement).
9.This item for sports and aviation use only, not for medical use.
2
Battery Installations
1. Press the button down on the back panel of oximeter and push the
battery cover horizontally along the arrow.
2. Install the two AAA batteries into battery cabin
in correct polarities. (as shown as the right)
3. Close the battery cover.
Notes:
Pay attention to the correct polarities terminals of the battery,

which are marked with plus and minus signs. Do not install the
battery in wrong direction.
Please remove the battery if the oximeter will not be used for

long time.
Why does the reading always change?

The pulse oximeter measures data in real time. Since the body

changes dynamically, the results also change over time. Please
use it with confidence.
Operation Instructions
1.Install two AAA batteries into battery cassette before closing its cover.
2.Nip the oximeter, then insert one of fingers into the rubber hole of the
oximeter before releasing the oximeter, and your nail surface
must be upward.
3.Press the function button once on front panel.
4.Your finger and body do not tremble
during measuring.
5.Read corresponding data in only one
direction on the display screen.
3
