Summary of Contents for CSSUN LPR Series
- Page 1 LPR Series LiFePO4 Lithium Pack Rack Mounted ESS Standard 19’ LiFePO4 Lithium Battery Pack 25.6V50Ah ~ 640Ah 51.2V50Ah ~ 320Ah User Manual CSSUN Energy Co., LTD 2024.8.16V1.02...
-
Page 2: Table Of Contents
LPR Series LiFePO4 Lithium Pack Table Of Contents 1. Basic Specification 2. Product Introduction 3. LCD introduction 4. Installation 5. Electrical Connection 6. Warning 7. Warranty 1 1 1... -
Page 3: Basic Specification
LPR Series LiFePO4 Lithium Pack 1. Basic Specification LPR48V100 LPR48V150 LPR48V200 LPR24V100 Model No. LPR48V100H LPR48V150H LPR48V200H Voltage 25.6Vdc 48Vdc/51.2Vdc 100Ah Capacity 100Ah 150Ah 200Ah Energy 2.56KWh 4.8KWh/5.12KWh 7.2KWh/7.68KWh 9.6KWh/10.24KWh Max. Chg voltage 29.2V 54.75V/58.4V Cut-off Dsg voltage 39.0V/42.0V Stand. Chg current Max. -
Page 4: Product Introduction
LPR Series LiFePO4 Lithium Pack 2. Product Introduction 2.1 Interface Introduction Name Silk-screen Remark Negative — M8 screw nut/2P terminal/Black Positive M8 screw nut-Red/2P terminal Power button ON/OFF Power button Breaker Breaker Output breaker RS485 communication port RS485 parallel port... - Page 5 LPR Series LiFePO4 Lithium Pack 2.2 Connectors Charge/Discharge connectors: Positive pole(+) and Negative pole(-) from battery to inverter via breaker 485/CAN: Active communication portal between battery and inverter 485-1/485-2: Get dynamic monitoring data of battery from upper computer by USB-RS485 tool Address: Reserved address portal for multiple parallel connections RS485/CAN connector is RJ45.
-
Page 6: Lcd Introduction
LPR Series LiFePO4 Lithium Pack SOC indicator Status Charge Discharge ● ● ● ● ● ● ● ● SOC indicator 0-25% Flash2 25-50% Flash2 50-75% Flash2 75-100% Flash2 100% RUN indicator Flash3 Note: Flash way Flash way Flash1 0.25S 3.75S... - Page 7 LPR Series LiFePO4 Lithium Pack 3.2 The interface generally displays the total battery voltage, battery percentage, current, and temperature of the battery. Press the NEXT key to display the remaining capacity, full capacity, and number of cycles. 1. Next is the menu bar action:...
- Page 8 LPR Series LiFePO4 Lithium Pack 3.2.3 Click on the bar of Battery temperature, the display is as follows: Display 4 cell temperatures, 1 MOS temperature, 1 ambient temperature ② Tap the battery status Bat status and ENTER. The following information is displayed: StatusIn-battery state，Standby-Resting state，CHG-On charge，DSG-In discharge state...
- Page 9 LPR Series LiFePO4 Lithium Pack High discharge temperature alarm 0x0100 0x0100 Charge overcurrent protection Discharge low temperature alarm 0x0200 0x0200 Discharge overcurrent protection Ambient high temperature alarm 0x0400 0x0400 Short circuit protection Ambient low temperature alarm 0x0800 0x0800 Front-end detects IC errors...
- Page 10 LPR Series LiFePO4 Lithium Pack ③Ver infor——ENTER，appear as follows： ④Pro Set ——ENTER，appear as follows： 3.4 RS485，ENTER The communication protocol selection screen is displayed. Select the inverter protocol that you want to be compatible with. The following information is displayed: RS485...
-
Page 11: Installation
LPR Series LiFePO4 Lithium Pack Pylon Goodwe Growatt Victron Deye brand 3.6 Select an inverter protocol of the desired brand, confirm the setting page, and click OK. The setting success page is displayed 4. Installation 4.1Inventory of items --------------- Items... -
Page 12: Electrical Connection
LPR Series LiFePO4 Lithium Pack 5.Electrical Connection 5.1System diagram The diagram is the household solar energy storage system. And it is suitable for off-grid and hybrid system. 5.2 Battery in parallel The LiFePO4 battery is a smart battery to match all off-grid and hybrid solar inverter (48Vdc/51.2Vdc) types. - Page 13 LPR Series LiFePO4 Lithium Pack 5.2.1 Inverter in Lead-acid battery mode If the inverter dose not match the battery BMS communication, the inverter can be set in Lead- acid mode. And the battery communication (RS485/CAN) port can be float. If inverter brand factory does not have CAN/RS485 port, just plug and play use.
- Page 14 LPR Series LiFePO4 Lithium Pack 6.Warning It is very important and necessary to read the user guider carefully before installing or using the battery. Failure to follow any of the instructions or warnings in this document can result in electrical shock, serious injury, death, or may damage the battery and the whole system.
-
Page 15: Warranty
LPR Series LiFePO4 Lithium Pack 3.2 During operation If the battery system needs to be moved or repaired, the power must be cut off first and the battery is completely shutdown. ◆ It is prohibited to connect the battery with different type of battery;...
