- Page 1 PTA512, PTA513 and PTA514 Air Compressor User Guide Original Instructions HA0103T...
-
Page 2: Table Of Contents
Chaper 4 Troubleshooting ........................9 Chaper 5 Regulatory ..........................10 5.1 Declarations Of Conformity ................... 10 5.1.1 For Customers in Europe ....................... 10 5.1.2 For Customers In The USA ....................10 Chaper 6 Thorlabs Worldwide Contacts .................... 11 Page 0 23248-D02... -
Page 3: Chapter 1 Overview
Chapter 1 Overview Chapter 1 Overview The PTA512, PTA513, and PTA514 are high-performance air compressors designed for applications demanding the highest quality air supply. They are self contained, lightweight, and compact, with minimal vibrations due to the very low noise emitted (30 dB at 1 m) from the compressor. -
Page 4: Chapter 2 Safety
PTA5xx Series Air Compressor Chapter 2 Safety 2.1 Safety Information For the continuing safety of the operators of this equipment, and the protection of the equipment itself, the operator should take note of the Warnings, Cautions and Notes throughout this handbook and, where visible, on the product itself. The following safety symbols may be used throughout the handbook and on the equipment itself. -
Page 5: Chapter 3 Installation
Chapter 3 Installation Chapter 3 Installation 3.1 Storage The packed compressor must be stored in a dry, well ventilated, dust free area, with an ambient temperature between -10 and 40°C Maximum. 3.2 Siting Caution When choosing the site, observe the following precautions: Site the compressor on a level surface of sufficient load bearing capacity. -
Page 6: Component Identification
PTA5xx Series Air Compressor 3.5 Component Identification 1 - On/OFF Switch 4 - Air Receiver 6 - Oil Level Sight Glass 2 - Air Pressure Regulator Tank Drain 7 - Motor Housing and Oil Sump 3 - Oil Filler Pipe 5 - Air Filter Fig. -
Page 7: Operation
Chapter 3 Installation Warning Although the oil used in the compressor does not contain any hazardous substances, care should be taken to avoid contact with the skin. Caution During item (3), use only ROLOIL SINCOM/32E Fully Synthetic Compressor Oil. Do not overfill the reservoir. Damage to the oil seals could occur if the level indicated on the sight glass (see Fig. 3.1) is exceeded. -
Page 8: Maintenance
PTA5xx Series Air Compressor 3.8 Maintenance Warning Do not attempt any maintenance on the compressor until the mains supply has been isolated and system pressure has been vented. To vent system pressure, operate the pressure relief valve. 3.8.1 Scheduled Maintenance Frequencies Caution The maintenance tasks detailed in Table 3.1 must be performed within the periods stated. - Page 9 Chapter 3 Installation Replacing the Oil During the following procedure, refer to Fig. 3.1 for identification of components. 1) Identify the retaining ring on the motor housing, then remove the bolt and separate the retaining ring. 2) Remove the motor housing cover. 3) Remove and retain the sealing ring.
-
Page 10: Ordering Replacement Consumables
2) Gently pull the ring in the end of the pressure relief valve until air is released. 3.8.2 Ordering Replacement Consumables Replacement compressor oil (Part No PTA1006) is available in 500 ml bottles from www.thorlabs.com, for other parts and consumables please contact your local tech support department. -
Page 11: Chapter 4 Troubleshooting
Chapter 4 Troubleshooting Chapter 4 Troubleshooting Warning Before attempting any maintenance on the compressor: Disconnect the mains electrical supply. Release the pressure in the air tank. Maintenance should be performed only by personnel suitably trained in the operation of the compressor. Compressor does not start 1) No power from mains. -
Page 12: Chapter 5 Regulatory
PTA5xx Series Air Compressor Chapter 5 Regulatory 5.1 Declarations Of Conformity 5.1.1 For Customers in Europe 5.1.2 For Customers In The USA This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC rules. -
Page 13: Chapter 6 Thorlabs Worldwide Contacts
Contact Thorlabs for more information. Waste treatment is your own responsibility. "End of life" units must be returned to Thorlabs or handed to a company specializing in waste recovery. Do not dispose of the unit in a litter bin or at a public waste disposal site. - Page 14 www.thorlabs.com...
