USE AND MAINTENANCE MANUAL
DECLARATION OF QUALITY
DECLARATION OF WARRANTY
DECLARATION OF PERFORMANCE DoP
MODEL
ZENIT
ISLAND VERSION, LEANING VERSION, WALL
SINGLE MODULE, COUPLED
ENG
MUT 097
Cod. 340406
Rev. 4
31/03/2023
Gibus S.p.A. Via Luigi Einaudi, 35 35030 Saccolongo (PD) - ITALY www.gibus.it - gibus@gibus.it

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ZENIT and is the answer not in the manual?

Questions and answers

Summary of Contents for Gibus ZENIT

  • Page 1 DECLARATION OF QUALITY DECLARATION OF WARRANTY DECLARATION OF PERFORMANCE DoP MODEL ZENIT ISLAND VERSION, LEANING VERSION, WALL SINGLE MODULE, COUPLED MUT 097 Cod. 340406 Rev. 4 31/03/2023 Gibus S.p.A. Via Luigi Einaudi, 35 35030 Saccolongo (PD) - ITALY www.gibus.it - gibus@gibus.it...

  • Page 3: Important Note

    Read in particular the chapter on safety. Dear Customer, thank you for choosing a Pergola by "Gibus", we are pleased to deliver this manual in order to help you to use the product in the best possible way. Please read carefully the recommendations described in the following pages and keep the manual at hand for the Gibus specialist who will be responsible for management and maintenance of the Pergola.
  • Page 4 Rev. 4 These instructions were translated from Italian (original language). Gibus S.p.A. reserves all rights to this manual, including the right, at any time, to make any necessary changes aimed at improving its products and the manual itself without prior notice.

  • Page 5: Table Of Contents

    3.5 Supplementary materials 3.6 Biocidal products 3.7 Noise level 4 TECHNICAL DATA 4.1 Type 4.2 ZENIT ISLAND 4.3 ZENIT FRONTAL LEANING VERSION 4.4 ZENIT LATERAL LEANING VERSION 4.5 ZENIT WALL 4.6 Coupling module 5 PACKING, HANDLING AND TRANSPORTATION 6 SAFE INSTALLATION 6.1 Mechanical structure...
  • Page 6 10 DISASSEMBLY AND DISPOSAL 10.1 Disposing of the Pergola TROUBLESHOOTING 11.1 Faults and failures table 12 CONVENTIONAL WARRANTY UP TO THE FIFTH YEAR 13 ZENIT EXPLODED DRAWING 13.1 1 MODULE 13.2 COUPLING MODULE TYPE 1 13.3 COUPLING MODULE TYPE 2 13.4 CROSS-SHAPED COUPLING 13.5 FABRIC COVER...

  • Page 7: Chapter 1: Introduction

    Models: ZENIT (ISLAND - LEANING VERSION) Revision No. 04 Published: 20/02/2018 Manufacturer’s data: Gibus S.p.A. via L. Einaudi, 35 - 35030 SACCOLONGO (PD) - ITALY http: www.gibus.it - e-mail: gibus@gibus.it List of annexes: - Installation instructions - Motors and automatisms instructions...

  • Page 8: Warnings For Use

    - ZENIT ISLAND: Self-supporting isolated drop awning with retractable stretched cloth, available single or multi-module, with coupling modules. - ZENIT LEANING VERSION: drop awning leaning against the wall with retractable stretched cloth, available single or multi-module, with coupling modules. - ZENIT WALL: Wall-mounted drop awning with retractable stretched cloth, available single or multi-module, with coupling modules.

  • Page 9: Regulations And Self-Certification Documentation

    UNI EN 13561 and the self-certification document (Declaration of Performance DoP) are included in APPENDIX 0 and APPENDIX 1 on the last pages of this manual. The original Declaration of Performance DoP issued by the manufacturer is kept by Gibus S.p.A. 1.3.2 With reference to UKCA marking This User’s Manual was prepared according to EN 13561 and the “Supply of Machinery (Safety)

  • Page 10: Liability

    Code 340406 Rev. 4 RESPONSIBILITY Gibus SpA is not liable and has no obligations for any accidents to persons or property, which may occur due to: - Failure to follow the instructions in this manual regarding the installation, use and maintenance of the Pergola;...

  • Page 11: Chapter 2: Safety Requirements

    IMPORTANT: In order to use the awning for purposes other than those described above, a specific permission given by the manufacturer is required. Failure to follow the conditions for proper use, automatically voids any warranty given by the manufacturer. USE AND MAINTENANCE MANUAL www.gibus.com Page...

  • Page 12: Use Environment

    The installation of the awning must be carried out strictly in accordance with the manufacturer's instructions provided in this manual and especially following the attached Installation Instructions referred to in the pertinent sections of this manual (Chap. 6 and Chap. 7). USE AND MAINTENANCE MANUAL www.gibus.com Page...

  • Page 13: Recommendations

    - If the structure leans against an existing building, carry out the lighting hazard assessment again in accordance with Law Decree 81/08 (in chapter III of Title III) by applying the technical reference regulations such as CEI EN 62305-2 (CEI 81-10/2). USE AND MAINTENANCE MANUAL www.gibus.com Page...

  • Page 14: Chapter 3: Technical Description

    Rev. 4 CHAPTER 3: TECHNICAL DESCRIPTION The drop awnings of the ZENIT line were designed and built according to the principles of constant innovation, impeccable workmanship and attention to the details of Gibus Total Quality. A system of values designed to ensure complete customer satisfaction.

  • Page 15: Electrical Components

    Provide power cables as defined in the table below. ZENIT Electric Features Type Drop Awning. 230 V (+10% +15%) 50Hz for ZENIT version 230V (*) Power supply 230 V (+10% +15%) 50Hz for ZENIT version 24V (*) 300 W (max.

  • Page 16: Electronic Components Of The Awning (Optional)

    The type of electronic component used on the Pergola is indicated in the product sheet. CAUTION: Never set the wind speed above the wind resistance of the awning itself (maximum threshold recommended for ZENIT: 60 Km/h). IMPORTANT: The installation and maintenance instructions of the control units and sensors are attached to the control unit packages, which are delivered along with the Pergola or placed in the accessory box.
  • Page 17 535 g/m², Flammability M1 (NF P92-503), CL.1 (UNI 9177), B1 (DIN 4102), C (BS 5867), Tensile strengh (ISO 1421) warp: ca 260 DaN/5 cm - weft: ca 225 DaN/5 cm, Openness factor 5 %, Elongation at break warp: 3,1 % - weft: 2,75 %. USE AND MAINTENANCE MANUAL www.gibus.com Page...

  • Page 18: Supplementary Materials

    ATTENTION: Some of the fabrics used by Gibus to package its products undergo treatments with biocidal products. For more information and to know the type of biocidal product possibly used in treating the fabric of your awning please visit our website: www.gibus.com...

  • Page 19: Chapter 4: Technical Data

    Projection up to 710 cm With 6 legs: Width up to 600 cm Projection up to 750 cm ZENIT FRONTAL LEANING VERSION (Basic Module) Tubular motor parallel to the wall With 2 legs: Width up to 600 cm Projection up to 710 cm...

  • Page 20: Zenit Island

    Code 340406 Rev. 4 ZENIT ISLAND ISLAND - SINGLE MODULE 4 legs 6 legs 4 LEGS max. L x S 6.00 x 7.10 6 LEGS max. L x S 6.00 x 7.50 Side view Front View WIDTH “L ” (cm) 1 Module n°...
  • Page 21 Fully packed cloth, even the largest sizes, offer a snow resistance of 100 kg/m or more. USE AND MAINTENANCE MANUAL www.gibus.com Page...

  • Page 22: Zenit Frontal Leaning Version

    Code 340406 Rev. 4 ZENIT FRONTAL LEANING VERSION FRONTAL LEANING VERSION 4 legs 6 legs SINGLE MODULE 2 LEGS max. L x S 6.00 x 7.10 4 LEGS max. L x S 6.00 x 7.50 Side view Front View WIDTH “L ” (cm) 1 Module n°...
  • Page 23 Fully packed cloth, even the largest sizes, offer a snow resistance of 100 kg/m or more. USE AND MAINTENANCE MANUAL www.gibus.com Page...

  • Page 24: Zenit Lateral Leaning Version

    Code 340406 Rev. 4 ZENIT LATERAL LEANING VERSION LATERAL LEANING VERSION 2 legs 3 legs SINGLE MODULE 2 LEGS max. S x L 6.00 x 7.10 3 LEGS max. S x L 6.00 x 7.50 Side view Front View PROJECTION “S” (cm) 1 Module n°...
  • Page 25 Fully packed cloth, even the largest sizes, offer a snow resistance of 100 kg/m or more. USE AND MAINTENANCE MANUAL www.gibus.com Page...

  • Page 26: Zenit Wall

    Code 340406 Rev. 4 ZENIT WALL WIDTH “L ” (cm) 1 Module n° n° Legend: kg = total weight of the drop awning (including the cloth pack). AP = Wall attachments. F = Profile breaker. USE AND MAINTENANCE MANUAL www.gibus.com...
  • Page 27 Fully packed cloth, even the largest sizes, offer a snow resistance of 100 kg/m or more. USE AND MAINTENANCE MANUAL www.gibus.com Page...

  • Page 28: Coupling Module

    Up to 710 cm. From 650 cm to 750 cm. Projection Projection BASE COUPLED module module ZENIT FRONTAL LEANING VERSION WITH COUPLING MODULE TYPE 1 COUPLING Up to 710 cm. From 650 cm to 750 cm. USE AND MAINTENANCE MANUAL www.gibus.com Page...
  • Page 29 Code 340406 Rev. 4 ZENIT FRONTAL LEANING VERSION WITH COUPLING MODULE TYPE 2 COUPLING Up to 710 cm. From 650 cm to 750 cm. ZENIT LATERAL LEANING VERSION WITH COUPLING MODULE TYPE 1 COUPLING Up to 710 cm. From 650 cm to 750 cm.

  • Page 30: Chapter 5: Packing, Handling And Transportation

    Do not use cutters. The packaging material should be disposed of or recycled in accordance with the regulations in force in the Country of destination of the product. USE AND MAINTENANCE MANUAL www.gibus.com Page...

  • Page 31: Chapter 6: Safe Installation

    In particular follow the “Instructions for proper installation” in Chapter 7. At the time of installation arrange all the tools mentioned on the first pages of the “Installation Instructions - ZENIT line”. If installers are more than one, it is necessary to appoint an operations coordinator.

  • Page 32: Electrical Connections

    For further information, please contact Technical Support. Note: follow the electrical diagrams and the assembly instructions which are kept in the awning accessory box. USE AND MAINTENANCE MANUAL www.gibus.com Page...
  • Page 33 IMPORTANT! The wiring diagrams and instructions for the use of engines and electronic control units are annexed to the control units themselves and should accompany this manual along with the Installation Instructions and carefully stored for subsequent consultations. USE AND MAINTENANCE MANUAL www.gibus.com Page...

  • Page 34: Radio Control

    SPOT lights in channel 2, RGB lights in channel 3 etc. To switch on, press ▲. to switch off press ▼. for intensity 50% press (MY). to reduce intensity, long press ▼. to increase intensity, long press ▲. USE AND MAINTENANCE MANUAL www.gibus.com Page...

  • Page 35: Chapter 7: Instructions For Proper Installation

    1st engine and power up the 2nd, repeat the programming and so on. IMPORTANT: after installation the declaration for proper installation must be compiled by the installer (Sec. 14 par. 1). USE AND MAINTENANCE MANUAL www.gibus.com Page...

  • Page 36: Chapter 8: Operation And Use Of The Pergola

    ATTENTION: never perform repeated opening and closing operations with the engine, this will activate the thermal switch, resulting in the shut-down of the engine and making manoeuvres impossible in case of need (presence of strong wind or snow). USE AND MAINTENANCE MANUAL www.gibus.com Page...

  • Page 37: Important Information On Use

    If the awning is equipped with an anemometric sensor, never set the wind speed above the wind resistance of the awning itself (maximum threshold recommended for ZENIT: 60 Km/h). ATTENTION! In the case of fault or when searching for faults, respect the safety measures.

  • Page 38: Chapter 9: Maintenance

    2nd year from the installation of the awning; this will extend the warranty up to the 5th year. If this is not done, the Gibus warranty will no longer be valid. Use original Gibus spare parts; otherwise, the warranty will be voided.

  • Page 39: Cleaning The Fabric Cover And The Side Fabrics

    Check the grounding is efficient; - if necessary clean the surfaces of the aluminium beams before removing dirt, dust and smog. Clean the surface with a paper rag and a wet sponge as explained in the previous paragraph. USE AND MAINTENANCE MANUAL www.gibus.com Page...

  • Page 40: Extraordinary Maintenance

    CHAPTER 10: DISMANTLING AND DISPOSAL CAUTION: dismantling of the Pergola must be carried out by qualified and trained staff. Ask for a specialized Gibus technician at the Service Department. CAUTION: dismantling of the Pergola must be carried out applying all the safety provisions as per installation: see chapter “SAFE INSTALLATION”...

  • Page 41: Disposing Of The Pergola

    The same symbol indicates electrical or electronic products for the “Waste Electrical and Electronic Equipment Regulations 2013”. USE AND MAINTENANCE MANUAL www.gibus.com Page...

  • Page 42: Chapter 11: Troubleshooting

    The engine does not start up. Check the operation of Faulty engine. the engine and replace if necessary The motor stops after 4-5 Allow the engine to cool minutes after continuous Thermal protection of the motor triggers. down. running USE AND MAINTENANCE MANUAL www.gibus.com Page...
  • Page 43 The awning closes and opens Calibration of too sensitive values. Trimmer Adjust the calibration and frequently. adjusted in DEMO mode. sensitivity values. Low battery. Replace the battery. Faulty remote control. Faulty remote control. Replace the remote control. USE AND MAINTENANCE MANUAL www.gibus.com Page...

  • Page 44: Chapter 12: Conventional Warranty Up To The Fifth Year

    The Gibus conventional guarantee covers the cost of spare parts in the following percentages: · In the 3rd year, the Guarantee covers 60% of the value of the spare part determined by the price shown by Gibus on the sales invoice to the dealer or, if not specifically stated therein, by the price charged for the spare part at the time of sale to the dealer;...
  • Page 45 The Gibus conventional guarantee will be recognized only if there is the Gibus hologram and “serial number” and after Gibus has checked for the compliance with the requirements and conditions set out in this chapter and in the “Use and maintenance manual””...

  • Page 46: Chapter 13: Exploded Drawing Of Zenit

    Code 340406 Rev. 4 CHAPTER 13: EXPLODED DRAWING OF ZENIT 13.1 1 MODULE USE AND MAINTENANCE MANUAL www.gibus.com Page...

  • Page 47: Coupling Module Type

    Code 340406 Rev. 4 13.2 COUPLING MODULE TYPE 1 USE AND MAINTENANCE MANUAL www.gibus.com Page...
  • Page 48 Code 340406 Rev. 4 13.3 COUPLING MODULE TYPE 2 USE AND MAINTENANCE MANUAL www.gibus.com Page...

  • Page 49: Cross-Shaped Coupling

    Code 340406 Rev. 4 13.4 CROSS-SHAPED COUPLING USE AND MAINTENANCE MANUAL www.gibus.com Page...

  • Page 50: Fabric Cover

    Code 340406 Rev. 4 13.5 FABRIC COVER USE AND MAINTENANCE MANUAL www.gibus.com Page...

  • Page 51: Chapter 14: Technical Notes

    Use Gibus original spare parts to keep the warranty valid. Accordingly, a compulsory maintenance operation within the end of the 3rd year from the installation date is to be required to the Gibus specialized technician and that will extend the warranty to the 4th year; a compulsory maintenance in the 4th year from the installation date will extend the warranty to the 5th year.
  • Page 52 Code 340406 Rev. 4 ADDITIONAL Installation Notes: ADDITIONAL Mandatory Maintenance Notes: USE AND MAINTENANCE MANUAL www.gibus.com Page...

  • Page 53: Maintenance Registry

    Code 340406 Rev. 4 14.2 MAINTENANCE AND NOTE REGISTER Operation description Full name and signature Date (including components replacement) specialized technician NOTES: 14.3 PRODUCTION NOTES See the product sheet attached to the back cover. USE AND MAINTENANCE MANUAL www.gibus.com Page...

  • Page 54: Chapter 15: Annexes

    2. Serial number: see the HOLOGRAM on the back cover 3. Designed use: Drop awning for outdoor use 4. Name and address of the manufacturer: Gibus S.p.A. - Via Einaudi, 35 - 35030 Saccolongo www.gibus.it - E-mail: gibus@gibus.it 6. Assessment and check system of constant performance: System 4 9.
  • Page 55 2. Serial number: see the HOLOGRAM on the back cover 3. Designed use: Drop awning for outdoor use 4. Name and address of the manufacturer: Gibus S.p.A. - Via Einaudi, 35 - 35030 Saccolongo www.gibus.it - E-mail: gibus@gibus.it 6. Assessment and check system of constant performance: System 4 9.
  • Page 56 HOLOGRAM Gibus S.p.A. Via Luigi Einaudi, 35 35030 Saccolongo (PD) - ITALIA www.gibus.it - gibus@gibus.it PRODUCT SHEET...
