LE-UVWE5D
PRODUCT INFORMATION
5-Diopter Glass Lens
19 x 15,7 mm (7.5 x 6.2 inch)
ASSEMBLY
LE-UVWE5D package includes the following items:
•
LE-UVWE5D unit
•
Heavy Duty Mounting Clamp
•
Power Supply
•
LE-UVWE5D manual
Mounting LE-UVWE5D Magnifying Lamp
1.
Attach the mounting clamp to the side of your work
bench and hand tighten
2.
Then insert LE-UVWE5D lamp into the hole of the
mounting table clamp
ideal-tek.com
Adjustable
Tension Knob
Built-In Handle
Fully Covered Spring
Balanced Arm
ESD safe
Power Switch
UV LED Switch
White LED Switch
Brightness Controls
Magnification
Lens Dimension
Color
Lighting
Lumen
ESD safe
Plug Type
INPUT
Heavy Duty
Mounting Clamp
2.25X (5-Diopter)
19 x 15,7 mm (7.5" x 6.2")
Black
48 White LEDs ( 6500K )
30 UV LEDs ( 365nm )
Max: 1100Lm
Yes
Type F (Schuko)
100-240V~
50/60Hz 0.3AMax
1
