Summary of Contents for Telia 202241
- Page 1 Telia LTE Gateway 202241 User manual 162241 16 June 2023 V1.0E...
-
Page 2: Table Of Contents
Contact Information .................................14 We are Telia Company. Our 20,800 talented colleagues serve millions of customers every day in one of the world’s most connected regions. With a strong connectivity base, we’re the hub in the digital ecosystem, empowering people, companies... -
Page 3: Declaration Of Conformity
Declaration of conformity We, Telia Sverige AB, Vasagatan 23, SE-903 29 Umeå, Sweden. Hereby declare that this product, a voice gateway identified as Telia LTE Gateway 202241, conforms with the following directives: RED 2014/53/EU, RoHS 2011/65/EU, RoHS3 2015/863/EU. The product complies with the following standards/norms:... -
Page 4: Installation Overview
Telia LTE Gateway 202241 User manual 1.0E Installation overview Connection Insert the SIM card, connect the Antenna, the lift phone and Power. ANTENNA Battery LTE Gateway PHONE POWER SUPPLY 230 VAC Lift phone in LIFT CAR 12-24 VDC... -
Page 5: Installation
Telia LTE Gateway 202241 User manual 1.0E Installation Find a suitable place to mount the LTE gateway following these guide lines: - Make sure the LTE network coverage is good before the LTE gateway is installed. Place the Antenna near a window if possible. -
Page 6: Change Sim Card
Telia LTE Gateway 202241 User manual 1.0E Change SIM card If the SIM-card needs to be changed, the new SIM-card must have “1234” as PIN- codes or have the PIN-code deactivated. - Turn off the LTE Gateway, remove the DC power connector from the LTE Gateway. -
Page 7: Front Panel Connectors And Indications
Telia LTE Gateway 202241 User manual 1.0E Front panel connectors and indications Reset Button Signal LED indicator Network/SIM LED indicator Power/Battery LED indicator Phone LED indicator Antenna SMA Connector for the antenna SIM card slot for insertion of SIM card... -
Page 8: Battery
Telia sales. Telia art no.132004 batteries are designed with a wider temperature range and approved to be used with the product. Other types of batteries might damage the LTE Gateway. If other supplier of batteries is used Telia cannot guarantee functionality as the function may not be as good. -
Page 9: Intercom
Telia LTE Gateway 202241 User manual 1.0E Intercom Connect a regular phone to RJ11 jack on gateway and Flex DUO to phone quick connect terminal. The Flex DUO needs to have ID programmed (ID 1-9) with P*140*ID P and intercom function activated with P*530 P. -
Page 10: Low Battery Voltage Indication And Battery Fault
Telia LTE Gateway 202241 User manual 1.0E Low battery voltage indication and Battery fault It is possible to configure the Gateway to send a SMS when a Low battery voltage indication or battery fault occurs, the functionality is activated by sending an SMS to the LTE Gateway. - Page 11 Telia LTE Gateway 202241 User manual 1.0E In this example when the power to the Gateway is re-established and the battery voltage is above the set voltage level the following is sent from the Gateway: SMS from Gateway: Battery V level OK from Lift 452...
-
Page 12: Sending Current Time To Flex Duo
Telia LTE Gateway 202241 User manual 1.0E Dial tone battery alarm The Dial tone battery alarm to the lift phone, indicating a battery fault alarm, is default activated but can be turned off. In case the function is deactivated the LTE Gateway will always use normal dial tone when the line is taken off-hook. -
Page 13: Relay Control
Telia LTE Gateway 202241 User manual 1.0E Relay control The Gateway has a relay that can be controlled by SMS. The relay can be set in state on, off or made to send a 3 second on pulse with the SMS commands on, off or pulse. -
Page 14: Hotline
Telia LTE Gateway 202241 User manual 1.0E Hotline Hotline is a function to make the gateway automatically dial a pre-programmed number when the connected phone goes off hook. To enable send a SMS SMS to Gateway: SMS acknowledgement from Gateway:... -
Page 15: Technical Data
Telia LTE Gateway 202241 User manual 1.0E Parameter Description UID with last 6 digits representing serial number of the Gateway Firmware version of the Gateway Current signal strength (signal strength in %) S H/L Highest signal during last 24h/lowest signal during last 24h since last restart. -
Page 16: Repair Return Procedure
User manual 1.0E Repair return procedure Telia Company only accepts returns that have a valid RMA number. Please contact Telia Company support to receive a RMA number. All returns must then be sent well packed with freight pre-paid to our service address:...
