Summary of Contents for Ever TITANIO LW3D3032N0A1-00

Page 1 Manual for Installation Use and Maintenance LW3D3032N0A1-00 LW3D3070N0A1-00 I T A N I O VECTOR - STEPPER - DRIVES Manual code: MAN.HILW3D30xx - Release 0.2 Build 00 Pag. 1...
Page 2 This document is registered by EVER and may not be copied or reproduced completely or partially without the written permission of EVER. EVER have the right to modify the manual and their products to improve the reliability and performances without being obliged to update the previously released products and manuals, or to inform the user about the concerning alterations.
Page 3: Table Of Contents
INDEX 1 INTRODUCTION 1.1 Guarantee ............................1.2 In this manual ..........................1.3 General drive description ....................... 2 FUNCTIONAL CHARACTERISTICS 2.1 Mechanical and Environmental ....................2.2 Electrical ............................2.2.1 Power supply ........................2.2.2 Digital inputs ........................2.2.3 Digital FAULT Output ......................2.3 Standards .............................
Page 4: Introduction
During the guarantee period of the product, Ever is in no case responsible for damages to the product caused by improper storage or installation, negligent maintenance or unauthorized modiﬁcations or repairs to the product.
Page 5: General Drive Description
General drive description The information in this manual refers to the standard versions of the drives LW3D30xxN0A1-00. Where there is the general indication, the informations should be considered applicable to all version. The drives have been designed to drive with stepless technology 2 phase stepper motors, keeping the phase current sinusoidal regardless from the selected step angle resolution, in order to realize ﬂuid movements and precise positioning.
Page 6: Functional Characteristics
FUNCTIONAL CHARACTERISTICS Mechanical and Environmental LW3D30xxN0A1 UNIT NOTES Excluding the footprint of the mating 128 x 74 x 30 Dimensions connectors. (For details check the (L x D x H) following mechanical design). Weight Excluding the mating connectors. IP protection class IP20 Pollution Degree 5°C ÷...
Page 7: Electrical
Electrical 2.2.1 Power supply For the functioning of the drives a DC power supply is needed. For the technical speciﬁcations, limitations and connections regarding the power supply, refer to the chapters 3.2 Planning the power supply and 3.3 Choosing the stepper motor . LW3D3032 LW3D3070 UNIT...
Page 8 Protections and warinings: PROTECTION TRIGGER EFFECT RESTORE - opening of the drive Over Current power stages; Short circuit It’s necessary to remove the Fast electronic protection or excessive power supply to the drive to on the motor outputs - LEDs signalling; against short circuits current eliminate the cause of the...
Page 9 A detailed description of the protections and the related visualizations is given in paragraph 3.7 Analyses of malfunctions . FUNCTIONAL DIAGRAM OF THE PROTECTIONS AND WARNINGS � �� ...
Page 10: Digital Inputs
2.2.2 Digital Inputs The drives are equipped with 4 digital inputs for the control of the functions: • Boost current BOOST • Enabling of the power stage • Step (or CLK_UP) STEP • Direction (or CLK_DWN) All digital inputs are available on CN2 connector of the drive and they can be used at voltages 2-24Vdc.
Page 11 Steps per Rotation Table: The rotation measured in degrees of the motor shaft, for every single step pulse depends on the settings of the Roto-switch R1 (refer to paragraph 3.5.2.2 Step angle). The following table shows the number of necessary step pulses to let the motor shaft execute a full rotation (360°) and the rotation in degrees executed by the motor shaft at every step pulse (the table refers to 50 poles motors, 1.8°...
Page 12 The following ﬁgures supply some examples of possible connections to the digital inputs: Voltage: 3.3 – 24 Vdc Voltage: 2 – 24 Vdc N.B. It’s recommended to use 2Vdc digital inputs only in Line-Driver conﬁguration to have more noise immunity.. For a proper use, the Digital inputs must be wired using shielded cables.
Page 13 Electrical speciﬁcation of digital inputs: TYPE CHARACTERISTICS UNIT Supply voltage Input frequency Threshold switching voltage 1.61 Standard Current at 2Vdc 3.13 (EN, BOOST) Current at 3.3Vdc 5.84 Current at 5Vdc 6.28 Current at 24Vdc 8.75 Supply voltage Input frequency Threshold switching voltage 1.61 High-speed Current at 2Vdc...
Page 14: Digital Fault Output
2.2.3 Digital FAULT Output Through this digital output you can check the operational status of the drives. FAULT OUTPUT MEANING OUTPUT VISUALIZATION Green LED OFF and FAULT Not ready – FAULT visualization following paragraph Not engaged One or more active 3.5.3 Operational statuses and (Transistor open) protections.
Page 15: Standards
Standards The EVER drives have been designed and produced observing the following Directives and Standards: Directives: 2014/35/EU Low Voltage 2014/30/EU Electromagnetic compatibility Standards: EN 61800-3 Variable speed drives – Electromagnetic compatibility and speciﬁc testing methods EN 61800-5-1 Variable speed drives – Safety requirements The compliance with the Electromagnetic Compatibility directives of the EVER product can only be veriﬁed if the entire machine, where from the drive is a component, has been designed and...
Page 16: Drive Installation
DRIVE INSTALLATION In this section are given some guidelines for the safe installation of the drives and the stepper motor. CN2: Digital inputs and output CN2.1 +BOOST CN2.2 -BOOST CN2.3 +ENABLE CN2.4 -ENABLE CN2.5 +STEP CN2.6 -STEP CN2.7 +DIR CN2.8 -DIR CN2.9 +OUT...
Page 17: Safe Installation And Use Of The Unit
EVER will not take any responsibility for indirect damage due to negligence, wrong installation, modiﬁcations to the product without approval or wrong connections of the equipment to the wiring.
Page 18 ELECTROMAGNETIC COMPATIBILITY Take all precautions and requirements which are necessary for the compliance with the electromagnetic compatibility (drive is in Category C3 following standard EN 61800-3). Some disturbances generated by other insufﬁciently ﬁltered and/or shielded equipment, can cause malfunctions in the drive which can result into uncontrolled movements. When making connections,...
Page 19: Planning The Power Supply
Planning the power supply Circuit and power supply connection schemes. Manual code: MAN.HILW3D30xx - Release 0.2 Build 00 Pag. 19...
Page 20 Main characteristics of the drive power supply: AC network switch: is a recommended safety device. Primary protections: use fuses on the AC bus or an equivalent safety switch. Surge suppressors: on the primary circuit, they protect the drive against Surges coming from the primary network power supply.
Page 21 Secondary protections: must be placed before the rectiﬁer bridge and must be calibrated depending on the set phase current. Instead of the secondary protections can be used an automatic safety switch. Rectiﬁer bridge: a rectiﬁer of 15A is recommended for the maximum absorption of a single axle.
Page 22 Power supply schematic of a multi-axles installation: Manual code: MAN.HILW3D30xx - Release 0.2 Build 00 Pag. 22...
Page 23: Choosing The Stepper Motor
Choosing the stepper motor drives have been designed to function with 2 phase stepper motors with the following characteristics: • the nominal winding current depends on drives model: LW3D3032 LW3D3070 U.M. Notes MIN. TYP. MAX MIN. TYP. MAX 0.21 3.20 1.70 7.10 Arms Motor...
Page 24: Connections, User Settings And Visualizations
onnections, user settings and visualizations Please refer to paragraph 3 DRIVE INSTALLATION for position of connectors, dip-switches and roto-switches. 3.5.1 Connection to the drive 3.5.1.1 Pinout of the connectors CN1 : DC power supply and motor – 6 positions connector, pitch 5.08mm Pos.
Page 25: Cables Section
3.5.1.3 Cables section Function Cable Minimum Maximum Power supply and PE 0.5 mm² (AWG20) 1.5 mm² (AWG15) Motor output 0.5 mm² (AWG20) 1.5 mm² (AWG15) Digital inputs 0.14 mm² (AWG25) 0.5 mm² (AWG20) Digital outputs 0.14 mm² (AWG25) 0.5 mm² (AWG20) 3.5.1.4 Guideline for wiring For a correct drive installation: Guideline for wiring...
Page 26: User Configurations
3.5.2 User conﬁgurations The drives are equipped with a series of Dip-Switches with 8 contacts and two Roto-Switches with 16 positions. In factory default all DIPs are OFF, R1 is in 2 position and R2 is in 0 position. This condition set the minimum current, a standard value of the step angle and none torque ﬁlter. NOTE: the device reads the Dips and Roto-Switch R1 only during the Power up.
Page 27: Step Angle
3.5.2.2 Step angle The type of step angle could be selected by the Roto-switch R1 on 15 different levels. It possible to select step angle base “2” : 1/2, 1/4 ,1/8, 1/16, 1/32, 1/64, 1/128, 1/256 and step angle base “5” : 1/5, 1/10, 1/25, 1/50, 1/125, 1/250 and also the Full Step. The factory default is in position 2 = 1/4 step angle.
Page 28: Automatic Reduction Of The Motor Current (Rwc)
3.5.2.4 Automatic Reduction of the motor current (RWC) Allows to reduce consumption and heating of the motor and drives when is not required a movement. The motor is stopped with a reduced current manteining also a detent torque. DIP5 Default Function The motor current will be reduced to 70% of the nominal value 1 second after the last step pulse.
Page 29: Torque Filter
3.5.2.8 Torque Filter With Roto-Switch R2 is possible to set a Torque Filter in order to reduce vibrations, resonance and noise of the motor. Roto-Switch R2 position Torque ﬁlter level None (Default) ..Medium ..High NOTE : the Roto-Switches R2 is read and executed in real time. If it’s necessary a setting change, take all necessary measures to avoid possible dangerous contacts.
Page 30: First Start Up Procedure
First start up procedure • Check all connections: power supply and motor. • Make sure that the application settings are correct. • Attention : the default condition of the Dip-Switches and Roto-Switches set the minimum motor phase current and 1/4 of step angle. Take into consideration this settings in the ﬁnal installation. •...
Page 31: Analyses Of Malfunctions
Analyses of malfunctions The green LED power ON or blinking indicates that the drives are powered correctly. When one of the following situations occurs, the drive enters an alarm status signalled by leds and the FAULT output is opened. Defect Cause Action May be caused due to a...
Page 32: Return Procedure
To return a damaged drive to EVER please ﬁll the RMA form available at Return procedure www.everelettronica.it or through this direct link: http://www.support-everelettronica.com/en/rma.asp An email including the RMA number and the return procedure will be send by EVER to the customer. Manual code: MAN.HILW3D30xx - Release 0.2 Build 00 Pag. 32...
Page 33: Appendices
APPENDICES Basic connections The following ﬁgures show examples of typical connections. A.1.1 Step / Direction �� ...
