USER
MANUAL
With QSense, we are powering a sustainable future through innovation,
efficiency, and unwavering reliability,
we can transform energy management,
one watt at a time.
monitoring watt matters
USER MANUAL
most. Together,

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Q SENSE and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Infinix Q SENSE

  • Page 1 USER MANUAL With QSense, we are powering a sustainable future through innovation, efficiency, and unwavering reliability, monitoring watt matters most. Together, we can transform energy management, one watt at a time. USER MANUAL...
  • Page 2 Infinix Energy Solutions QSense Comprehensive User Manual Table of Contents 1. QSense Comprehensive Overview About QSense Key Features Product Specifications Device Parameters Product Overview Activity Lights Color Indications Power Indicator Product Limitations Connection Diagram Operating Instructions Measurement Procedure Maintenance Troubleshooting...
  • Page 3 User Account Setup and Login Procedures 6. Dashboard Overview Detailed Explanation of the Dashboard Interface Key Features: Power Quality Monitoring, Real-Time Alerts, Historical Data Analysis Navigating Different Sections of the Dashboard 7. Using QSense Monitoring Power Quality Setting Up and Customizing Alerts Generating and Interpreting Reports Tips for Maintaining Optimal Power Quality 8.

  • Page 4: Product Specifications

    Voltage RMS Measurement • Current RMS Measurement • Active Power Measurement • Active Energy Measurement • Reactive Power Measurement • Reactive Energy Measurement • Apparent Power Measurement • Apparent Energy Measurement • Voltage Total Harmonic Distortion • Current Total Harmonic Distortion •...

  • Page 5: Product Overview

    Device Parameters Minimum Maximum 200 VAC line to line 480 VAC line to line Voltage 100 VAC line to neural 240 VAC line to neutral Current 100 A peak Frequency 45 Hz * 65 Hz * Operating Temperature 0 °C * 55°C Disclaimer: QSENSE Device is tested on 120 –...

  • Page 6: Power Indicator

    Blue Fading Register clearing mode Green Fading Measuring data Blue 1x Flash Sending data Flashing Communication lost 1x Flash No internet Power Indicator Colour Activity Description Green Steady Connected to AC Power Steady No AC Power – Running on battery power No AC power and no battery power Limitations Below are the current transformer turns ratio and its equivalent maximum...
  • Page 7 Connection Diagram Operating Instructions Before setting up, ensure that QSENSE is OFF. Refer to the CONNECTION DIAGRAM. The current transformer arrow must be facing to the load side. Safety reminder: The person in-charge of setting-up QSense must be a technician or have experience in electrical parameters. 1.
  • Page 8 Connect the blue wire to phase C grid Connect the green wire to neutral 2. Phase Current Grid line clamping 2.1. IA Current Transformer Clamp the IA CT to the phase A grid, CT arrow must be pointing to the load side. 2.2.

  • Page 9: Troubleshooting

    Do not connect to voltage higher than 240 VAC. Do not use the device when measuring higher than 100 A. Calibration Calibration of the device should be done by qualified technicians at Infinix Energy Management only. Calibration cannot be completed by the end user.
  • Page 10 Safety Information For safety in operating this instrument, read these instructions • completely before using the device and comply fully. Failure to observe these warnings can result in severe injury or death. Do not use the device in any manner not specified in the instruction •...
  • Page 11 Voltage Measurement Wires • USB and Ethernet Cables • User Manual • Installation Requirements Compatible Android device for the QSense Config Application. • Access to the local Wi-Fi network for device configuration. • Proper personal protective equipment for safe installation. •...
  • Page 12 Plug the IA, IB, IC male plugs into their respective female ports on the QSense device. 6. Power On the Device: Turn on the QSense device using the power switch. 4. Software Installation Installation Requirements Operating Systems: Android (for QSense Config Application) •...
  • Page 13 3. Open QSense Config Application: Open the application and proceed to the Wi-Fi Provision section. 4. Enter Wi-Fi Credentials: Input and confirm the local Wi-Fi credentials. 5. Confirm Configuration: Allow the device to configure the Wi-Fi connection. 5. Initial Configuration First-Time Setup Wizard 1.
  • Page 14 Navigating Different Sections of the Dashboard 1. Navigation Menu: Use the menu to access different sections such as monitoring, alerts, and reports. 2. Monitoring Section: View real-time power quality data. 3. Alerts Section: Manage and customize alerts. 4. Reports Section: Generate and view detailed reports. 7.
  • Page 15 1. Store Device Properly: Keep the device in a dry place with temperatures not exceeding 50°C. 2. Avoid Dust and Moisture: Ensure the device is not exposed to dust or moisture. 3. Battery Replacement: Replace the battery pack every 2-3 years. 4.
  • Page 16 2. Firmware Updates: Regular firmware updates are provided to ensure optimal performance and new features. For more information about QSense and its features, visit our website at www.infinixenergy.com or contact us at info@infinixenergy.com. Infinix Energy Solutions Empowering Efficiency Through Data-Driven Insights; WATT MATTERS MOST. www.infinixenergy.com...
