Coonara Midi
INSTALLATION
OPERATING INSTRUCTIONS
Coonara
WOODHEATERS ARE AUSTRALIAN OWNED
AND MANUFACTURED BY
SHAMIC SHEETMETAL AL AL AL
SHAMIC SHEETMET
SHAMIC SHEETMET
SHAMIC SHEETMET
PO BOX 8, KILSYTH, VIC. 3136
PH: 03 9737 5300 FAX: 03 9761 6455
&
Coonara MIDI
(AUST.) PTY. LTD.
https://coonara.com.au
1 of 15
Printed: 14/06/2023
Advertisement
Table of Contents
Related Manuals for Shamic Sheetmetal Coonara MIDI
Summary of Contents for Shamic Sheetmetal Coonara MIDI
- Page 1 Serial Number of Heater: ____________ Model: Coonara WOODHEATERS ARE AUSTRALIAN OWNED AND MANUFACTURED BY SHAMIC SHEETMET SHAMIC SHEETMETAL AL AL AL SHAMIC SHEETMET SHAMIC SHEETMET (AUST.) PTY. LTD. PO BOX 8, KILSYTH, VIC. 3136 PH: 03 9737 5300 FAX: 03 9761 6455 https://coonara.com.au...
- Page 2 SAVE THESE INSTRUCTIONS INSTALLATION AND OPERATION INSTRUCTIONS Have your heater installed by a registered or licensed installer and advise your insurers for inclusion in your household contents policy. In some states the installer is required to issue a certificate of compliance on the installation; - ensure you obtain this if applicable! The heater should be checked for scratches/dents prior to installation.
-
Page 3: Installation Instructions
Installation Instructions Installing the Heater 1. Select the preferred position for the heater taking into account the minimum clearances to combustible surfaces (see table below) and all combustible materials in the roof, such as: ceiling joists, roof trusses, etc. A standard, default triple skin flue system incorporating a 130º x 900mm stainless steel flue shield fitted between the active flue and decromesh casing must be used with this heater to ensure minimum clearances, as tested, are attained. -
Page 4: First Fire
FIRST FIRE YOUR HEATER HAS BEEN SPRAYED WITH HIGH TEMPERATURE PAINT. TO ENSURE THAT THE PAINT IS PROPERLY “CURED IN”, PLEASE FOLLOW THESE STEPS WHEN LIGHTING THE FIRST FIRE IN THE HEATER: • ENSURE THE AIR CONTROL SLIDE IS FULLY OPEN. •... -
Page 5: Operating Information
Operating Information Fuel Ignition: A supply of firelighters or newspapers. Kindling: 10 mm – 20 mm diameter light, split, pieces of dry wood. Start-up wood: 30 mm – 75 mm diameter medium size, split pieces of dry wood. “BURN ONLY HARDWOOD”. Starting a fire Fully open the air slide, lift the door handle upward and open the door slowly. - Page 6 Use of the fan Coonara heaters are fitted with a 3-speed fan for efficient distribution of warmth. Operating the fan in your wood heater is critical at all stages of use except at startup, where the follow steps apply: • When the fire has been underway for 30 minutes turn the fan on to low •...
-
Page 7: Replacement Parts
Preparing for a low (overnight) burn For an extended low burn ensure a maximum fuel load is placed into the heater, following the reloading procedure outlined previously. The greater the fuel load the longer the burn. After reloading close the door and leave the air inlet fully open (high) until the load is alight. The air inlet should then be turned down to the low setting. -
Page 8: Maintenance
Maintenance Paint surfaces After the curing process has taken place, little maintenance is required other than dusting off with a cotton cloth. Most marks can be buffed out with a cotton cloth without the need for retouching. NOTE: Do not use abrasive cleaners or harsh solvents (such as methylated spirits). Should you experience scuffing or scratching, or discolouration due to incomplete curing, the high temperature Coonara paint can be touched up and matching spray cans may be purchased from your... -
Page 9: Door Adjustment
Door adjustment The door is unlikely to become misaligned unless it is knocked and attempts at adjustment may cause rather than solve a problem. Always consult your Coonara dealer before attempting any adjustment to the door. 1. Remove door by opening fully and lifting door up off the hinge. (Freestanding models require top panel to be propped up prior to lifting door). - Page 10 At the end of the heater season you should clean and vacuum the fan and fan tray. Dust and hair can accumulate, especially if you have a pet. Turn the mains power off and disconnect the power lead from the wall socket. Console Model 1.
- Page 11 Baffle plate removal The baffle plate is held in place with four locating tabs – 2 either side, front and rear of the firebox. WARNING: ALLOW THE HEATER TO COOL IF HOT BEFORE ATTEMPTING BAFFLE PLATE REMOVAL. Steel Baffle 1. Lift the front of the baffle up and pull forward over the supports until the baffle clears the locating slots in the back wall of the firebox.
- Page 12 TABLE 1: FIREWOOD SPECIES AND THEIR PROPERTIES Firewood Forest Type Heat Density Splitting Ignitability Coals Sparks Avail. Species Avail. (Dry Air) Per Unit Ib/ft3/ Volume Kg/m3 Mallee Roots Mallee Difficult Poor Excellent Good Belah, Buloke Mallee 70 / Good Poor Excellent Limited Box-Ironbark...
-
Page 13: How To Make A Warranty Claim
5. Provide the details that your retailer requests to complete a Warranty Claim Form. This must include the heater model, serial number and installation compliance certificate, if applicable in your State. 6. Your retailer will forward your claim to Shamic Sheetmetal (Aust) Pty Ltd, the manufacturer of the above heater brands 7. - Page 14 Revised: 14/06/22 14 of 15 Printed: 14/06/2023...
- Page 15 See exclusions and qualifications below for further information on product coverage. WARRANTY: Shamic Sheetmetal (Aust) Pty. Ltd, warrants the firebox to be free of defects in materials and workmanship of a period of ten (10) years from the date of purchase.
