- Page 1 USER MANUAL Super-Automatic Coffee Machine: Milano Turbosteam...
- Page 2 User Manual Milano Turbosteam Read the manual carefully before use and keep it safe...
-
Page 3: Table Of Contents
User Manual Contents 1 Introduction ............................5 1.1 Welcome to Use ........................5 1.2 Labels and symbols ........................5 2 General safety tips ..........................7 2.1 Danger to users ......................... 7 2.2 Hazard to the machine ......................10 3 Product Description ..........................12 3.1 Welcome to Use ........................ - Page 4 User Manual 4.4 Turn on the power, ........................24 4.4.1 Coffee maker ........................ 24 4.4.2 Confirming the Water Source Mode ................24 4.4.3 Counting ........................25 4.4.4 Diagnosis ........................26 4.4.5 Machine Status ......................29 5 First Run ............................. 30 5.1 Set up the machine configuration - model number ...............
- Page 5 User Manual 6.3 Daily Rinse..........................49 6.3.1 Brewer flushing......................49 6.3.2 Milk Road rinse......................50 6.3.3 Automatic flushing Settings ..................51 6.4 Cleaner ............................ 51 6.5 Daily machine cleaning ......................52 6.5.1 Display guided cleaning program ................52 6.5.2 System Cleaning ......................53 6.5.3 Brewer cleaning ......................
-
Page 6: Introduction
User Manual 1 Introduction 1.1 Welcome to use This instruction manual gives you the information of MILANO TURBOSTEAM and other products and how to use them. If you do not use the coffee machine according to the relevant instructions in this manual, we do not assume any responsibility for the loss caused by this. - Page 7 User Manual Conditions exist that could cause damage to the machine. Be sure to follow the precautions to prevent such hazards. Fire hazard/combustible materials. Watch out for fire. Hot liquids. A dangerous condition that may cause burns. A hazard exists at the flow ...
-
Page 8: General Safety Tips
User Manual Crush hazard. Dangerous conditions that can cause splint injuries. Only symbols are used for identification below. Be sure to follow the precautions to prevent such hazards Poisoning hazard. A general hazardous condition that may result in injury from ... - Page 9 User Manual Self-use and operation should be supervised by trained personnel to ensure compliance with maintenance regulations and to resolve usage issues at all times. Only coffee beans should be filled in the coffee bean tank, and only ground coffee beans ...
- Page 10 User Manual Drinks with additives or residues may cause allergies. Be sure to follow the following: In the self-service application, express the possible use of allergenic additives through the coffee machine prompt board. In the case of a service person application, a trained person should inform you of possible ...
-
Page 11: Hazard To The Machine
User Manual Hot surface. High temperature exists in the flow outlet position, ES brewer and boiler. Only allow contact with handles pre-designed for output. Clean the ES brewer only after the coffee machine has cooled. Squeeze \ scratch hazard. There is a risk of being crushed by touching any moving part. Only handles pre-designed for output are allowed to be touched. - Page 12 User Manual Use original parts for repairs. For visible external damage or leakage, contact your service partner immediately for replacement or repair. Do not rinse the machine with water or clean it with steam cleaner. Do not place the machine where it may be sprayed with water. ...
-
Page 13: Product Description
User Manual 3 Product Description 3.1 Welcome to use The MILANO TURBOSTEAM is used to make and output various types of coffee drinks and milk drinks with syrup. The equipment is suitable for commercial use in hospitality, catering or similar establishments. -
Page 14: Installation And Commissioning
User Manual Rated current 10A\16A（Refer to nameplates） Exposed length of power cord Greater than 1.5m Coffee machine operating Temperature 5℃-35℃, relative humidity is less than 80% temperature/humidity Rated pressure 0.6 MPa Communication interface USB; WIFI; 4G Device display 7 ", 10.1 "display Coffee bean box capacity JL15, 500 g;... -
Page 15: Installation
User Manual Sharp edges of packaging materials can lead to injury. Cutting nylon cable ties may make Eye injury. Wear gloves when unpacking the machine and keep safety goggles on. Contaminated water inlet pipes may pose a health hazard. It must be cleaned after installation, commissioning or commissioning again. -
Page 16: Power Supply
User Manual 4.1.2 Climatic conditions Hazards to machinery. The following climatic conditions are suitable for placing coffee machines. If these conditions are not guaranteed, the machine may be damaged. Be sure to observe the following conditions: The ambient temperature should be maintained at 5 ° C - 40 ° C. ... -
Page 17: Connecting The Power Cable
User Manual Do not lift or pull the device through the power cord. Do not pull the plug out of the socket by pulling on the power cord. Never touch the power cord or plug with wet hands! Do not plug wet plugs into sockets! 3.5.2 Power connection cable Danger to the user. -
Page 18: Water Inlet Conditions
User Manual 3.6.2 Water intake conditions Water Pressure 0.1-0.6 MPa (1-6 bar) recommended Inlet temperature Minimum Greater than 0°C Maximum value 30°C 3.7 Mount 3.7.1 Unwrap the machine Read the "Set Up" and "Power Supply" sections carefully before starting the installation! Pay attention to the installation instructions that come with it! Unwrap the machine. -
Page 19: Device Description
User Manual Do not grip the outlet of the drink or touch the surface of the boiling device while it is heating. Hazard to the machine. Wrong operation may damage the touch screen. Do not press the display with brute force, high pressure, or sharp objects. 4.1 Equipment introduction 4.1.1 Machine external operating unit Coffee maker (front) -
Page 20: Technical Parameters
User Manual Product interface Company Time/date LOGO Hot water boiler temperature Milk road Steam boiler Brewer flush temperature Page turn Product button Single/double cup buttons toggle button Product Language name switch button 4.1.2 Technical parameters JL08 JL29 recommended Cup capacity per recommended Cup capacity per Drinks... -
Page 21: Accessories
User Manual American American style Style Long Long coffee coffee Milk Milk coffee coffee Water Water JL15 JL31B recommended Cup capacity per recommended Cup capacity per Drinks daily serving size hour Drinks daily serving size hour Italian Italian American American style Style Long... -
Page 22: Functional Specifications
User Manual Optional accessories ICONS Item name Functional Product parameters specifications Milk cold bin For refrigeration and 220 (W) x400(H)x403(D)mm/ fresh use 220 (W) x430(H)x403(D)mm, capacity 9L Fresh Granny box Container for holding Food grade, 5L fresh milk Bottom cabinet (can A bottom cabinet for Can be customized be customized) -
Page 23: Add And Connect
User Manual 4.3 Add and connect Special care must be taken when replenishing that the maximum amount of filling must not cause the container lid to come into contact with the contents. 4.3.1 Connecting water source Water quality affects human health! Water sources must meet the sanitary standards for drinking water Pay attention to the sanitary condition of water pipes. -
Page 24: Connecting The Wastewater Pipe
User Manual B. Internal water source Open the lid of the tank, raise the tank upward, fill the tank with clean water, and load the tank back into the machine. The water level of the tank is detected, and the water shortage interface is prompted. C. -
Page 25: Connecting The Refrigerator
User Manual 4.3.3 Connect the refrigerator Insert one end of the milk tube into the port on the left side of the refrigerator, straighten the milk tube, and move the refrigerator flush with the coffeemaker cabinet. 4.3.4 Connect the power supply to the refrigerator Insert the refrigerator power cord, female head, into the socket of the machine;... -
Page 26: Counting
User Manual In the interface that pops up, click "General -> Water Supply" and select the correct water supply method (corresponding to the way you actually connect your water source). Take the empty measuring cup and put it under the outlet mouth, click "Start test" when the water is finished, read the value on the measuring cup, and click "Save"... -
Page 27: Diagnosis
User Manual Click "Drinks", [item] Counting mode interface [All] Counting mode interface Counting by Drink type screen Reset the counter screen Life Counter Counts by drink type interface 4.4.4 diagnosis... - Page 28 User Manual Press and hold, the top left corner of the screen, enter your password (Tester: test9527) in the dialog box that pops up, and click "OK". Enter the background management interface and click on "Diagnosis", the diagnostic functions include "software and operating version, fault, diagnostic test".
- Page 29 User Manual Software and Operating Versions - Applications: Users can check and update application versions here; Software and Operational version - Network Status: Users can check and set up networks here. Software and operating version -SIM Card Number: Users can set the SIM card number here (hardware support required);...
-
Page 30: Machine Status
User Manual Diagnostic test - Status query: Users can check the status of all parts of the machine here; Diagnostic test - Valve test: Here the user can test all the valves within the machine. Diagnostic Test - Heater test: Users can test all boilers in the machine here; Diagnostic test - Sensor: The user can test all the sensors inside the machine here. -
Page 31: First Run
User Manual Click the icon to enter the "Status Details", press the prompt on the machine, and proceed with processing; Click the "machine reset" button, the machine will automatically redetect. 5 First run 5.1 Set up machine configuration - model number Press and hold, in the upper left corner of the screen, enter the password (Administrator: jn9527, Operation and maintenance personnel: 9527) in the dialog box that pops up, and click "OK". -
Page 32: Connecting To The Network
User Manual 5.2 Connect to the Internet Inside the machine, take out the signal receiver. Open the glue plug under the display, insert the signal receiver into the USB port on the right, and the machine will automatically restart. When the machine restarts, long press, the top left corner of the screen, enter the password: jn9527 in the pop-up dialog box, and click "OK". -
Page 33: Connecting To A Server
User Manual Click the name of the WIFI you want to connect to, enter your password in the pop-up dialog box, and tap "Connect". Note: When using a single machine, you do not need to connect to the network, you can ignore this step. -
Page 34: Fill The Box
User Manual Click "Diagnostic Test" -> "Status Query" to view: Service connection configuration; Service connection status, indicating successful connection to the server; Service connection status: failed to connect to the server; If the server fails to be connected, contact your local carrier or agent to check whether the server is registered. -
Page 35: Fill The Milk Box In The Refrigerator With Milk
User Manual 5.5 Fill the milk carton in the refrigerator with milk It is Important to: Contaminated milk tubes can be a health hazard. It must be cleaned after installation, commissioning, or running again. Follow the cleaning procedure guided by the display screen before the initial output of the drink. Insert the refrigerator door key and turn it clockwise to open the refrigerator door;... -
Page 36: Commissioning And Calibration
User Manual 5.6 Debugging and Calibration Calibrate Grinder calibration Before adjusting the grinder, prepare the (low magnitude) electronic scale! Grinder thickness adjustment First calibration Empty coffee beans (empty grinder residue before adjusting grinder) 5.6.1 Grinder thickness adjustment method 1、 Open the coffee bean box and find the grinder coarseness adjustment knob. 2、... -
Page 37: Adjusting The Temperature Of Hot Milk And Milk Foam
User Manual 3、 Take out the coffee grinder grinding powder thickness adjustment tool (grinder adjustment key), insert the tool into the adjustment knob, press down to the end to rotate. In the absence of beans, first turn the knob counterclockwise to the disc fit position (can not be twisted under normal torque until), then turn the knob clockwise to between 5-6, as a reference thickness position (the thickness of the general espresso), and then fine-tune according to the thickness of the powder during the calibration process (clockwise is to adjust the thickness,... - Page 38 User Manual Note Note: Because each part or powder has different physical characteristics, it is necessary to recalibrate each time the cartridge, motor or coffee beans from different manufacturers, and the amount of material in the cartridge should be greater than 1/3 of the volume of the cartridge when calibrated. Grinder calibration steps: 1、...
-
Page 39: Fresh Milk Calibration
User Manual 4、 Click the "Grinder Calibration" option, -> "Start" button, the grinder starts to work, the grinder out of the powder mouth, will produce coffee powder, and finally drop into the coffee grounds box. 5, take out the coffee grounds box in the machine, put it on the electronic scale "zero/peel", put the coffee grounds box "zero/peel"... - Page 40 User Manual Calibration steps for fresh milk: 1、 Place the empty measuring cup under the outlet mouth and move the outlet mouth down to the lowest to lowest position. 2, Long press, in the upper left corner of the screen, enter the password (administrator: jn9527) in the pop-up dialog box, and click "OK".
-
Page 41: Product Testing And Adjustment
User Manual 4. Click the "Foam Calibration or Hot Milk Calibration" option and -> click the "Start" button to discard the foam or hot milk. Replace with an empty measuring cup and place it under the outlet mouth; Click the "Start" button again. When the milk foam or hot milk is finished, take off the measuring cup with the milk foam or hot milk, read the value of the milk foam or hot milk in the measuring cup with eye level, input the read value in the blank under [Input milk foam capacity] / [Input hot milk amount], and click "Save". -
Page 42: Beverage Management
User Manual 5.8 Drink Management Enter the background of the machine, click "Beverage management", enter the beverage management interface, you can choose single/double cups of drinks, add products, batch operation, import products, export products. Click to add a drink or product picture, you can edit the product: product ID (the entered ID needs to be consistent with the ID on the server), product name, product recipe, production time, price setting, sorting, normal display, removal, single cup, double cup, save function;... -
Page 43: Setting The Sales Mode
User Manual 5.9 Set the selling mode Free mode sales interface - no product price payment mode sales interface - product price Enter the background of the machine, click "Machine Settings", select [function mode] in the pop-up interface, and click the icon of "function mode". Click the "Payment System"... -
Page 44: Beverage Making
User Manual 5.10 Drink Making Place the cup under the mouth and select a drink from the display; Adjust the taste in the touch screen, there are five levels, and then confirm; Free mode or set to 0 yuan, the machine directly make drinks, will not pop up, scan the code payment interface;... -
Page 45: Operator Options
User Manual 5.12 Operator option The operator option has the following functions: language switch, Stop Drink Making, Screensaver, AD, General picture Down, Date Time, Auto, etc., Eco Mode, Direct Drink Making. Play the picture switch on, the prepared picture to the U disk, the U disk into the USB port (USB port at the bottom left bottom of the display), import the picture from the U disk;... - Page 46 User Manual According to the requirements (picture size, name) on the computer to make "logo, start the picture", and then test them to the U disk, and then the U disk into the USB port (USB port at the bottom left bottom of the display), import the picture from the U disk;...
-
Page 47: Empty
User Manual 5.13 Clear Pictures 5.13.1 Coffee grounds box Heat may cause damage. Do not use the dishwasher to clean the powder residue box . ► Remove the coffee grounds box from the machine. ► Empty the coffee grounds box and clean it. ►... -
Page 48: Shutdown
User Manual When using a stacking machine, improper transportation can cause damage to the machine. The following points must be noted when using a trolley to change the position of the machine: • For safety reasons, you must not push the trolley when changing its position, only drag it. •... -
Page 49: Cleaning
User Manual 6 Cleaning Thorough cleaning and maintenance are essential requirements for achieving food hygiene conditions. Only by regular maintenance, cleaning and maintenance (twice a week or increasing the frequency of cleaning according to the specific use) can the machine provide superior tasting drinks and satisfy customers. -
Page 50: Cleaning Schedule
User Manual 6.2 Cleaning plan The following two cleaning plans are available for technical service personnel to configure: • The cleaning plan for "TechnoSmart Default" (standard). • A "manual" cleaning schedule. The cleaning intervals described in this chapter comply with the cleaning schedule of "TechnoSmart Default". -
Page 51: Milk Road Rinse
User Manual In the pop-up box there are two keys "confirm or cancel", click "confirm" to execute the first program, click "cancel" to return to the menu bar of the previous layer; Select the "OK" button until the ES brewer flush procedure is complete. 6.3.2 Milk Route Rinse Enter the background of the machine, click the "cleaning and maintenance"... -
Page 52: Automatic Flushing Settings
User Manual 6.3.3 Automatic flushing Settings Go to the background of the machine, clean/maintain, set the automatic Cleaning Settings, Monday to Sunday, set the automatic cleaning time at a certain time every day. 6.4 Cleaning Agent Cleaning agents can cause poisoning! Only use cleaners recommended by the manufacturer of the device. -
Page 53: Daily Machine Cleaning
User Manual There is a risk of burns. When the machine is rinsing, hot water is discharged from the mouth of the drink. Do not reach under the outlet while the machine is rinsing. 6.5 Daily machine cleaning 6.5.1 Display to guide the cleaning routine Preparation - Utensils needed for cleaning. -
Page 54: System Cleaning
User Manual 6.5.2 System cleaning Enter the machine background - click "Cleaning/Maintenance" - "System cleaning"; In the pop-up dialog box, select [OK] to go to the next step, select [Cancel] to return to the menu of the previous layer; Click [OK] to go to the next step. Draw out the water tray and empty the water in the tray;... - Page 55 User Manual The cleaning tablet is dissolving the water, please wait... ; Tablet dissolve time to program automatic execution cleaning, cleaning in... Please wait a moment. Empty clean pill box and clean Add 500ml warm water and click [NEXT] The machine is cleaning automatically, please wait... When the water runs out and the time is up, take out the cleaning box and put the milk carton in the refrigerator.
-
Page 56: Brewer Cleaning
User Manual 6.5.3 ES brewer cleaning Enter the machine background - click "Clean/Maintain" - "ES brewer Clean"; In the pop-up dialog box, select [OK] to proceed to the next step, select [Cancel] to return to the menu of the previous layer; Click [OK] to go to the next step. -
Page 57: Milk Path Cleaning
User Manual The machine performs ES brewer cleaning procedures. The ES brewer cleaning time takes about 15 minutes to complete, wait patiently until the program is over, the interface prompts: "ES brewer cleaning is completed, click OK to return the user to the beverage selection screen"; Click "OK" to return to the drink screen. -
Page 58: Clean The Coffee Grounds Box
User Manual Enter the background of the machine - click "Cleaning/maintenance" - "Milk Road Cleaning"; In the pop-up dialog box, select [OK] to go to the next step, select [Cancel] to return to the menu of the previous layer; Click [OK] to go to the next step. Get 1 or 2 Rinza milk cleaning tablets;... -
Page 59: Clean The Water Tray
User Manual Coffee grounds box cleaning method: Pull the water tray out of the machine, remove the coffee grounds box, and dump the coffee grounds. Use clean water and household cleaner to thoroughly clean the coffee grounds box. Rinse with clean water and dry with a clean towel, load the coffee grounds box, and reload ... -
Page 60: Clean The Drink Out Of The Mouth
User Manual 6.5.7 Clean the drink out of the mouth First pull out the milk tube, hold down the buckle on both sides of the beverage outlet mouth, pull down hard, take off the steam nozzle, fresh milk heating chamber, fresh milk outlet mouth seal cover, fresh milk outlet mouth, coffee outlet mouth, rinse with water. -
Page 61: Emptying The Waterway
User Manual 6.7 Empty waterways Enter the background of the machine, click "machine Settings", and click "Restart" in the pop-up interface. The next dialog box will pop up. First click the "Boiler transport Antifreeze protection" button in the interface, follow the interface prompts to operate (empty the tank or cut off the external water source), and then click "Next"... -
Page 62: Preventive Measures
User Manual 7 preventive measure 7.1 Cleanser 7.1.1 Use Danger of poisoning from ingesting detergent. Be sure to observe the following: Cleaning agent storage should be kept away from children and unauthorized persons. Do not ingest cleaning agents. Do not mix cleaning agents with other chemicals or acids. -
Page 63: Disposal Of Waste
User Manual 7.1.3 Disposal of waste If recycling is not possible, the cleaner and its storage must be disposed of in accordance with local laws. 7.2 Health Regulations 7.2.1 water The possible health hazards of not using water properly! The water source must meet the sanitary standards for drinking water. Be sure to observe the following points: The water must be clean and pollution-free. -
Page 64: Safety And Quality Assurance
User Manual 8 Safety and quality assurance The manufacturer does not accept any responsibility for damage that may occur to the coffee machine if the user does not follow the instructions for the use and installation of the machine. Take care to follow the instructions. The installation site should be kept dry and waterproof;... -
Page 65: Certification
User Manual Contaminated The outlet spout is not installed Check and reinstall water tray correctly The coffee is ground too coarse Adjusting grinder Coffee flows too The dose is not nearly as good as fast Recalibrate or check the recipe Settings expected Coffee bean box feed stop plate Check and open it... - Page 66 CQC certification. Jinuo intelligent provides the inspection report of the machine and related food contact parts. Marketed globally by: TRUFROST AND BUTLER PRIVATE LIMITED 1215, 12th Floor, Tower B, Emaar Digital Greens, Golf Course Extn. Road, Sector 61, Gurugram – 122102 (India) T.
