- Page 1 DLB Box Manual WWW.BENY.COM DLB Box Manual ZHEJIANG BENYI NEW ENERGY CO.,LTD. WENZHOU BRIDGE INDUSTRIAL ZONE,BEIBAIXIANG TOWN, ZHEJIANG, CHINA TEL: +86-577-5717 7008 FAX: +86-577-5717 7007 VERSION: 20230811 benyi@zjbeny.com www.beny.com This catalogue has been printed on ecological paper. Zhejiang Benyi New Energy Co.,Ltd.all rights reserved.
-
Page 2: Table Of Contents
CONTENTS Normal DLB 1. About DLB 2. DLB Model Selection 3. How DLB Box Works? 4. How to install the DLB box? 5. How to Set the Max Grid Current on DLB Box? 6. DLB Troubleshooting Solar DLB 1. About solar DLB 2. -
Page 3: About Dlb
2. DLB Model Selection The DLB Extreme Mode: For a unsmart ev charger can be actived via DIP switch (the third one); For a smart ev charger can be actived via APP setting. Model BCP-DLB-01M BCP-DLB-03M Phase Single Phase Three Phase √... - Page 4 Normal DLB What the current is that you set on DLB box? For Single Phase DLB System: 1 Phase System with DLB: BCP-DLB-01M (Correct Installation) The Current of EVC = Max Grid Current(Set on DLB Box) - Household Load Current...
-
Page 5: How To Install The Dlb Box
Normal DLB Normal DLB 4. How to install the DLB box? Network cable connection Connect the DLB box with charger by the network cable. Please double check your accessories Din rall 105mm Din rail fixing parts M4*30 expansion screw kit Current Transformer Network cable - 5m Normal DLB box... - Page 6 Normal DLB Normal DLB CT installation of single phase Normal DLB Box (BCP-DLB-01M) Make CT clamp on house mains cable. (Including some of or all of house loads and EV Charger power cable) Red cable of CT should be connected to at the Home port;...
- Page 7 Normal DLB Normal DLB CT installation of single phase Normal DLB Box (BCP-DLB-01M) Make CT clamp on house mains cable. (Including some of or all of house loads and EV Charger power cable) Red cable of CT should be connected to at the Home port;...
- Page 8 Normal DLB Normal DLB CT installation of three phase Normal DLB Box (BCP-DLB-03M) Make CT clamp on house mains cable. (Including some of or all of house loads and EV Charger power cable) Red cable of CT should be connected to L1B, L2B, L3B at the Home port;...
- Page 9 Normal DLB Normal DLB CT installation of three phase Normal DLB Box (BCP-DLB-03M) Make CT clamp on house mains cable. (Including some of or all of house loads and EV Charger power cable) Red cable of CT should be connected to L1A, L2A, L3A at the Home port;...
-
Page 10: How To Set The Max Grid Current On Dlb Box
Normal DLB Normal DLB 5. How to Set the Max Grid Current on DLB Box? For 1 Phase DLB box For 3 Phase DLB box 0/17A 0/17A 0/17A 0/17A 0/17A 0/17A press simultaneously press simultaneously Press "+", "-" to adjust the value Press "+", "-"... -
Page 11: Solar Dlb
Normal DLB Solar DLB Solar DLB 1. About solar DLB LED light status Fault type Potential Cause Action Solar DLB (Dynamic Load Balancing) is available in the BCP series AC EV charger for home and solar home use, controlling and monitoring the different powers from PV to make Yellow light Red light different modes come true. -
Page 12: Solar Dlb Model Selection
Solar DLB Solar DLB 2. Solar DLB Model Selection What is Night Automatic Full Speed Mode? In this mode the EV charger will remain charged at full speed (Pm20:00- Am6:00). Note: The coin cell battery is not installed in the original factory charger (the battery is installed by yourself if required), the EV charger will lose this configuration after restarting, and it needs to reconnect the APP to configure it. -
Page 13: How The Solar Dlb Box Works
Solar DLB Solar DLB 3. How the solar DLB box works? 3 Phase System with DLB ： BCP-DLB-13M (Correct Installation) 3.1 CT Installation Diagram 1 Phase System with DLB ： BCP-DLB-11M (Correct Installation) Distribution Board Grid Inverter Solar Panel Household Loads Distribution Board Grid Inverter... -
Page 14: Once The Inverter Is Too Far To Install Pv Ct
Solar DLB Solar DLB 3.2 Once the inverter is too far to install PV CT Press button “-” and “+” simultaneously, then enter “Solar Mode”. There are two modes of Solar Mode. 1 Phase System with Solar DLB Mode 2: Press “-”... -
Page 15: How To Install The Dlb Box
Solar DLB Solar DLB Network cable connection 4. How to install the DLB box? Please double check your accessories Connect the DLB box with charger by the network cable. Din rall 105mm Din rail fixing parts M4*30 expansion screw kit Current Transformer Network cable - 5m Solar DLB box... - Page 16 Solar DLB Solar DLB CT installation of single phase Solar DLB Box (BCP-DLB-11M) Make CT clamp on house mains cable. (Including some of or all of house loads and EV Charger power cable) Red cable of CT should be connected to at the Home port &...
- Page 17 Solar DLB Solar DLB CT installation of single phase Solar DLB Box (BCP-DLB-11M) Make CT clamp on house mains cable. (Including some of or all of house loads and EV Charger power cable) Red cable of CT should be connected to at the Home port &...
- Page 18 Solar DLB Solar DLB CT installation of three phase Solar DLB Box (BCP-DLB-13M) Make CT clamp on house mains cable. (Including some of or all of house loads and EV Charger power cable) Red cable of CT should be connected to L1B, L2B, L3B at the Home port &...
- Page 19 Solar DLB Solar DLB CT installation of three phase Solar DLB Box (BCP-DLB-13M) Make CT clamp on house mains cable. (Including some of or all of house loads and EV Charger power cable) Red cable of CT should be connected to L1A, L2A, L3A at the Home port &...
-
Page 20: Lnstrustions For Using Solar Dlb
Solar DLB Solar DLB 5. lnstrustions for using solar DLB How to switchover between different Modes of solar DLB? How to switchover between solar DLB and normal DLB? Switch to Normal Mode Long press buttons Press any button for 5 seconds Switch to 0/40A Solar mode... -
Page 21: Solar Dlb Troubleshooting
Solar DLB 6. Solar DLB Troubleshooting LED light status Fault type Potential Cause Action Yellow light Red light RS485 cable is Replace on for 1s flashes 1 damaged RS485 cable time DLB offline The yellow light of the charger light board lights for 1s, then the red light flashes for one Reconnect RS485 cable is not...
