Philips PET810 Service Manual
Hide thumbs Also See for PET810:

Advertisement

Quick Links

DVD Portable Player
Service Manual

TABLE OF CONTENTS

Technical Specification................................................1
Safety Instructions.......................................................2
Instruction for Use.......................................................3
Mechanical Instructions............................................... 4
Troubleshooting & Service tips.....................................5
Overall block diagram.................................................. 6
Overall wiring diagram................................................ 7
Electrical diagram....................................................... 8
Component layout...................................................... 9
Service part list..........................................................10
Revision list...............................................................11
©Copyright 2005 Philips Consumer Electronics B.V. Eindhoven, The Netherlands
All rights reserved. No part of this publication may by reproduced, stored in a
retrieval system or transmitted, in any form or by any means, electronics,
mechanical, photocopying, or otherwise without the prior permission of Philips
Version 1.5
PET810
PET805
/
All version
Chapter
3141 785 30465

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PET810 and is the answer not in the manual?

Questions and answers

Summary of Contents for Philips PET810

  • Page 1: Table Of Contents

    All rights reserved. No part of this publication may by reproduced, stored in a retrieval system or transmitted, in any form or by any means, electronics, mechanical, photocopying, or otherwise without the prior permission of Philips 3141 785 30465 Version 1.5...
  • Page 2: Technical Specification

    E.g. 050303 Procedure on how to upgrade the software of the DVD Portable Current consumption Download the latest software from the Philips support site. Unzipped the files and then burn it onto a CD ROM DC-IN SUPPLY (9.0V) then playback the CD ROM on the DVD Portable.
  • Page 3: Safety Instructions

    2.0 SAFETY INSTRUCTIONS WAARSCHUWING WARNING Alle IC’s en vele andere halfgeleiders zijn All ICs and many other semi-conductors are gevoelig voor electrostatische ontladingen susceptible to electrostatic discharges (ESD). (ESD). Careless handling during repair can reduce life Onzorgvuldig behandelen tijdens reparatie kan drastically.
  • Page 4: Esd Protection

    2.1 ESD PROTECTION When the power supply is being turned on, you may not remove this laser cautions label. If it removes, radiation of laser may be received. PREPARATION OF SERVICING Pickup Head consists of a laser diode that is very susceptible to external static electrocity. Although it operates properly after replacement, if it was subject to electrostatic discharge during replacement, its life might be shortened.
  • Page 5: Instruction For Use

    PET810_ENG.QXD 4/25/05 9:26 AM Page 2 3.0 INSTRUCTION FOR USE 1 J( / § 7 0 OPEN For previous (J( ) or next (§) Opens disc door to insert or chapters, tracks or titles remove disc 2 5 / 6 8 POWER/CHG Search backward (5 ) or search Power and charging indicator...
  • Page 6 PET810_ENG.QXD 4/25/05 9:26 AM Page 3 Main unit controls Front of player Left of player Right of player...
  • Page 7 PET810_ENG.QXD 4/25/05 9:26 AM Page 4 Remote Control 1 3, 4, 1, 2 6 A > B Up / down / left / right cursor To repeat or loop a sequence in a title Confirms selection PLAY-MODE Selects play order options 2 VOL+ + / / −...
  • Page 8 PET810_ENG.QXD 4/25/05 9:26 AM Page 5...
  • Page 9: Mechanical Instructions

    4.0 MECHANICAL INSTRUCTIONS 1. Back View as Fig.1 Remove 10 screws to disassemble the base as Fig.2 5. Remove top cover as Fig.7,8 Fig.2 Fig.8 10 screws Fig.7 Fig.1 6. Remove IF board shield as Fig.9 2. Soldered short pattern for laser diode as Fig.3 soldered 3 screws Fig.9...
  • Page 10: Troubleshooting & Service Tips

    5.0 TROUBLESHOOTING & SERVICE TIPS 5.1 Procedure to change region code 1. Power on player and open DVD Door. 2. Press <Set Up> at Remote Control. In <Set Up Menu> select <Preferences>. 3. For PET710 – Press successively 2 1 2 2 2 5. ▼.
  • Page 11 5.0 TROUBLESHOOTING & SERVICE TIPS SYMPTOM: NO POWER, NO GREEN LED start Check if the power cable replace cable/ No defect, return set OK? adapter set to customer AC adapter Check if the replace connector power and play and switch unit button OK? replace MAIN go to other...
  • Page 12 5.0 TROUBLESHOOTING & SERVICE TIPS SYMPTOM: THE INITIAL SCREEN IS NOT DISPLAYED ON THE LCD Refer to the symptom NO start POWER, NO GREEN LED Replace broken Check if the Repair connector harness LED on the front lights up? Remove the LCD Open the top and Is the cover and plate of...
  • Page 13 5.0 TROUBLESHOOTING & SERVICE TIPS SYMPTOM: THE DVD DRIVE DOES NOT WORK Press the DISC cover switch at the center of the DVD player and turn on the power. Then check whether or not the optical pick- up lens of the DVD drive lights. CAUTION: start Visible laser radiation when open and interlock defeated.
  • Page 14 5.0 TROUBLESHOOTING & SERVICE TIPS SYMPTOM: THE DVD DRIVE DOES NOT OPERATE WITH BATTERY start Install a good battery does the LED lights up orange while the AC adapter is connected and does the DVD drive operate OK? NOTE: - For this check, use a battery which is not fully Replace battery charged (because the LED does not light when the battery is fully charged.)
  • Page 15 5.0 TROUBLESHOOTING & SERVICE TIPS SYMPTOM: NO SOUND COMES FROM THE HEADPHONES start Insert a good Customer  headphones and check if headphones the problem persist? defective Replace main board...
  • Page 16: Overall Block Diagram

    6.0 OVERALL BLOCK DIAGRAM OSCILLATOR DC 9V 16M FlashROM 64M SDRAM OZ9RR TC4W53 74HCU04 27MHz 14.31818MHz MX29LV160ABTC-70 NT56V6620C0T-75S 27MHz UPD5100 HIGH VOLTAGE ASS'Y TFT MONITOR RF AMP & SERVO & DVD PROCESSOR DV23(HD80) MPEG-2 DECODER & VIDEO ENCODER PU mechanism MT1389SE +3.3V +1.8V...
  • Page 17: Overall Wiring Diagram

    7.0 OVERALL WIRING DIAGRAM SWITCH PCB BATT+ LD/VCC XS001 SPEAKER L CD/DVD SW BATTERY VCOMS XS001 ISEN VRCD VSEN VRDVD VCOMS LD/CD SPIO LD/DVD MODE2 LCDR MODE1 LCDG SPOI FCS- LCDB SPIO TRK+ MODE1 TRK- 3.3V FCS+ 3.3V 3.3V 3.3V LIMIT 3.3V TFT +5V...
  • Page 18: Electrical Diagram

    8.0 ELECTRICAL DIAGRAM - MAIN BOARD CIRCUIT DIAGRAM (POWER CIRCUIT DIAGRAM) cation: REPLACE PUSE WITH SAME TYPE AND RATING L003 CDRH6D38-330MC #HV9V Littelfuse T3A/125V C001 C140 C141 C142 16V/47U 100n 100n 100n VD09 UDZS7E-174.7B N002 BA033 N003A L002 VD010 IR7304 CDRH6D38-330MC ISS355 DV33...
  • Page 19 8.0 ELECTRICAL DIAGRAM - MAIN BOARD CIRCUIT DIAGRAM (TFT CIRCUIT DIAGRAM) UPD5100VDD UPD5100VDD R238 -14.5V CB21 CB17 CB16 C198 CB20 R199 C170 +16.5V 100n 100n 100n 100n 100n C197 C203 10U/16V C169 VD33 C168 C194 100n ISS355 100n 14.31318 ECJ3YF1C106Z CB15 C171 C193...
  • Page 20 100P C117 R93 750K VD17 C228 STZ6.2N R120 C236 C234 +P5V C234 C234 C176 C519 C235 R115 VD19 WX10HB-2-20K 100U/6.3V 300P STZ6.2N R116 R64 560 AGND YUV0/CIN RR104 DVDA XS006 DVDA C138 DVDB DVDB VREF DV DC DACVDDB speaker DVDC DACVDDC DV DD KEYIN0...
  • Page 21 8.0 ELECTRICAL DIAGRAM - HIGH VOLTAGE BOARD CIRCUIT DIAGRAM C1 1 R1 1 1210 C1 0 UI8.5 SO T-23 R1 0 SO T-23...
  • Page 22: Component Layout

    9.0 COMPONENT LAYOUT - PET810 PTH HV POWER BOARD DIAGRAM...
  • Page 23 9.0 COMPONENT LAYOUT - PET810M MAIN BOARD DIAGRAM...
  • Page 24: Service Part List

    RC810 REMOTE PET805 994000001904 PET810 VIDEO WIRE VCABLE PET805 994000001903 PET810 AUDIO WIRE ACABLE PET805 994000002229 PET810/05 ADPV18A AC POWER ACADAPTOR ADAPTER 994000001898 PET810/00 ADPV18A AC POWER ACADAPTOR ADAPTER 994000001902 PET810 CAR CIGARETTE ADAPTER CARADATPOR PET805 994000001906 PET810 TRAVEL BAG (AY4233)
  • Page 25: Display Frame

    10.0 SERVICE PARTS LIST 994000002242 PET810 20 PIN HARNESS (LE140) PET805 994000002141 PET810 LTA080B441A TFT LCD PET805 994000002228 PET810 DV23 LOADING ASS'Y PET805 994000002144 PET810 SPEAKER PET805 994000002334 PET810 TOP COVER PET805 994000002335 PET810 DISPLAY FRAME PET805 994000002148 PET810 MIDDLE CABINET...
  • Page 26: Control Key Pad

    10.0 SERVICE PARTS LIST 996500037999 PET810 HINGE FIXED PLATE LEFT 341 996500038000 PET810 HINGE FIXED PLATE RIGHT 994000002989 PET810 CONTROL KEY PAD PET805 994000002333 PET810 DOOR ASSY PET805 994000002338 PET810 DOOR SPRING PET805 994000002341 PET810 OPEN BUTTON SPRING PET805...
  • Page 27: Revision List

    11.0 REVISION LIST Version 1.0 (3141 785 30460) Initial release PET810/00/05 Version 1.1 (3141 785 30461) Chapter 10: Service parts list adapted with revised service 12NC on ADPV18A AC POWER ADAPTER of PET810/00 & PET810/05. Version 1.2 (3141 785 30462)
