  • Page 1 Repair Guide Basic Model HW-T650/ZA Applicable Mode HW-T6** Ver.1.0...
  • Page 2: Table Of Contents

    Contents 1. Precautions 1-1. Safety Precautions .............................1-1 1-2. Servicing Precautions ............................1-3 1-3. Precautions for Electrostatically Sensitive Devices (ESDs) ...............1-4 1-4. Installation Precautions ...........................1-5 2. Disassembly and Assembly 2-1. Disassembly ................................ 2-1 2-1-1. Separate the Cover-Bottom ......................2-1 2-1-2. Separate PCB MAIN & Wireless & etc...................
  • Page 3 Samsung- authorized service provider. Any damage or defect to product resulting from a repair, or an attempt to repair, the product by any person other than a Samsung certified service provider will not be covered by the warranty.
  • Page 4 Samsung’s liability in any case shall be limited to the greatest extent permitted by law. Samsung reserves the right, at its sole discretion, to change, modify, add or remove portions of any part of this manual at any time. It is your responsibility to check the manual periodically for changes. Your use of the manual...
  • Page 5: Precautions

    Precautions 1. Precautions • Follow these safety instructions while servicing the ESD to prevent damage and to protect against potential hazards such as electrical shock and X-rays. • For continued safety, do not attempt to modify the circuit board. • Disconnect the AC power and DC power jack before servicing. Warning •...
  • Page 6 Precautions 5. Insulation Resistance Cold Check: Antenna (1) With the unit’s AC plug disconnected from the AC source, Terminal connect an electrical jumper across the two AC prongs. (2) Set the power switch to ON. Exposed (3) Measure the resistance between the shorted AC plug and Metal Part any exposed metallic parts.
  • Page 7: Servicing Precautions

    Precautions 1-2. Servicing Precautions • An electrolytic capacitor installed with the wrong polarity might explode. Warning • Before servicing units covered by this service manual, read and follow the Safety Precautions section of this manual. Caution • If unforeseen circumstances create conflict between the following servicing precautions and any of the safety precautions, always follow the safety precautions.
  • Page 8: Precautions For Electrostatically Sensitive Devices (Esds)

    Precautions 1-3. Precautions for Electrostatically Sensitive Devices (ESDs) • Some semiconductor (“solid state”) devices are easily damaged by static electricity. Such components are called Electrostatically Sensitive Devices (ESDs). Examples include integrated circuits and some field- effect transistors. The following techniques will reduce the occurrence of component damage caused by static electricity. 1.
  • Page 9: Installation Precautions

    5. Installing the product in a special place like below rather than normal environment may cause serious quality concerns due to its special conditions. If this is the case, make sure to contact a local Samsung service center before installing the product.
  • Page 10: Disassembly And Assembly

    Disassembly and Assembly 2. Disassembly and Assembly • As this product has parts that are sensitive to static electricity, be careful when handling them. Warning 2-1. Disassembly • Disconnect the product from the power source before disassembly. • Follow these directions carefully; never use metal instruments to pry apart the cabinet. Caution •...
  • Page 11: Separate Pcb Main & Wireless & Etc

    Disassembly and Assembly 2-1-2. Separate PCB MAIN & Wireless & etc • Disconnect harness & ffc cables. (1ea / 2ea) Remark Remark • Lift the main PCB Ass'y. * . Caution : HANDLE WITH CARE! IR Receiver part may bump against the body. •...
  • Page 12: Disassembling Soundbar Body

    Disassembly and Assembly 2-1-3. Disassembling Soundbar Body • Unfasten 18 screws on the rear. Remark Remark • Flip the body, and lift the top cover.
  • Page 13: Separate Oled Module

    Disassembly and Assembly 2-1-4. Separate OLED Module • Unfasten 2 screws on right cover and detach a FFC cable on OLED PBA. Remark - P/N: AH81-09795A, Type: 3.0mm*10.0mm (black) 2-1-5. Separate ASSY-KEY-PCB • Remove black rubber button, disassemble two M2 x L6 screws and lift PCB. Remark 2-1-6.
  • Page 14: Assembly

    Disassembly and Assembly 2-2. Assembly • Please assemble in reverse order of disassembly steps. • The exterior may differ depending on the product. Note...
