Summary of Contents for Spinfire Blaze
- Page 1 Blaze Stringing Machine Manual Installation and Operation www.spinfiresport.com...
-
Page 2: Table Of Contents
Table of Contents SPINFIRE BLAZE Description of Parts 1 TABLE OF CONTENTS.................1 2 DESCRIPTIONS OF PARTS..............1 3 ASSEMBLY INSTRUCTIONS...............2 4 STRINGING THE FRAME..............3 5 CLAMP BASE ADJUSTMENTS............4 6 PREPARATION OF STRINGING............5 7 CALIBRATING THE MACHINE ……………………………………………5 8 IF THE BRAKE STOPS WORKING………………..………………………6 1. -
Page 3: Assembly Instructions
Assembly Instruction Step 1: Take out the base (1) from Step 4: Screw in the height the paper box and place it on the adjustment knob using a spanner. flat ground. Take out the pole (2) You can adjust the height of the from the box and screw it to the machine by pulling out this knob, base using the four holes including... -
Page 4: Stringing The Frame
Step 7: Adjust the moveable Step 3: To pull the string place mounting arms by turning the it in the string gripper (9). Hold mounting arm adjustment knob string to a 90 degree angle as clockwise. Again make sure it is shown (or use your finger to tight without being too tight. -
Page 5: Clamp Base Adjustments
Step 9: Adjust the moveable Step 6: Apply the clamp to the mounting arms by turning the tensioned string and place it as adjustment knobs counter close to the edge of the frame as clockwise. possible (without touching damaging the frame). Clamp base adjustment This only needs to be done if your Step 7: To release the tension... -
Page 6: Preparation Of Stringing
Preparation of Stringing Calibrating the Machine Calibrate the tension head when you find the stringing machine is not pulling at To clamp the string, squeeze the lever the correct tension. To test your machine you need a Tension Calibration Scale. closed to close. -
Page 7: If The Brake Stops Working
Step 3: Use a 2mm Allen key to loosen the safety screw. To achieve a higher tension, turn the tension adjustment screw counterclockwise by tension arm using a 2.5mm Allen key. To reduce the tension, turn it clockwise. For instance, if the tension locking lever releases before 60 pounds, turn the tension adjustment screw counterclockwise to adjust the catch downward.
