Summary of Contents for D-Link G403C
- Page 1 Version 100 | 12/13/2024 User Manual 4G LTE N300 Wi-Fi Router G403C...
-
Page 2: Manual Revisions
Preface D-Link reserves the right to revise this publication and to make changes in the content hereof without obligation to notify any person or organization of such revisions or changes. Manual Revisions Hardware Revision Date Description v1.00 2025/01/07 Initial Version... - Page 3 This device is an Energy Related Product (ErP) with High Network Availability (HiNA), and automatically switches to a power- saving Network Standby mode within 1 minute of no packets being transmitted. G403C Network Standby: 3.5W Switched Off: 0.08W D-Link G403C User Manual...
-
Page 4: Table Of Contents
Status - WAN Status ............25 SMS Outbox ................51 Status - OpenVPN Status ..........26 SMS Settings .................52 Status - User Traffic .............27 USSD ..................53 Status - Statistics ..............28 AT Command ................54 Setup ....................29 Data Cap .................55 Wizard ..................29 D-Link G403C User Manual... - Page 5 Time Zone Setting ..............74 DDNS ..................75 Deny of Service ..............76 System Log ................78 Password ................79 Ping Diagnostic ..............80 Traceroute ................81 System Settings ..............82 Auto Reboot .................83 Upgrade Firmware ..............84 Logout ..................85 Connect a Wireless Client to Your Router .......86 D-Link G403C User Manual...
-
Page 6: Product Overview
If any of the above items are missing or damaged, please contact your local reseller. Note: Using a power supply with a different voltage rating than the one included with the router will cause damage and void the warranty for this product. D-Link G403C User Manual... -
Page 7: System Requirements
• Safari 6 or later • Chrome 28 or later EAGLE PRO AI APP • iOS® or Android™ device (Please refer to the description of the Requirements app’s page to check whether your device is compatible.) D-Link G403C User Manual... -
Page 8: Introduction
With 4G LTE mobile broadband connectivity, G403C makes a great companion for residential applications and small to mid-sized businesses. The G403C supports 802.11n WLAN with speed up to 300 Mbps, and three 10/100 Mbps Ethernet ports for wired connectivity. Furthermore, the device can be configured in various mode, including Wireless ISP and Gateway mode, to suit your network environment and application needs. -
Page 9: Hardware Overview
The device is powered on. Power Indicator The devices is powered off. No Internet connection or connection failure Solid Green The device is connected to the Internet Internet Flashing Green Data is being transmitted Internet connection is not established. D-Link G403C User Manual... - Page 10 Wi-Fi (2.4G) Flashing Green Data is transmitted via Wi-Fi No Wi-Fi Blinking The router is trying to establish a wireless connection with a WPS client. WPS LED The WPS connection is established. The WPS is not activated. D-Link G403C User Manual...
-
Page 11: Back Panel
Press this button to initiate a new WPS connection. Reset Press this button with an unfolded paperclip and hold for 2-3 seconds to reset the device. Power Connector Connector for the supplied power adapter. Power Button Switch the device on or off. D-Link G403C User Manual... -
Page 12: Installation
Section 2 - Installation Installation This section will walk you through the installation of your G403C. Before you Begin • Placement of the router is very important. Do not place the router in an enclosed area such as a closet, cabinet, attic, or garage. -
Page 13: Wireless Installation Considerations
1. Keep the number of walls and ceilings between the D-Link router and other network devices to a minimum - each wall or ceiling can reduce your adapter’s range from 3-90 feet (1-30 meters.) Position your devices so that the number of walls or ceilings is minimized. -
Page 14: Setup
There are several ways you can configure your router to connect to the Internet • Hardware Setup - This section explains how to set up your G403C. Refer to Hardware Setup on page 10. • Setup Wizard - This wizard will launch when you log in to the router using your browser for the first time. Refer to Setup Wizard on page 13. -
Page 15: Hardware Setup
Section 2 - Installation Hardware Setup Step 1 Position your G403C near your Internet-connected modem. Place it in an MODEM open area for better wireless coverage. Step 2 MODEM Turn off and unplug the power to your cable or DSL broadband modem. This is required. - Page 16 If you are configuring the router wirelessly from a PC, connect to the Wi-Fi network name printed on the label attached to the bottom of your router. Note: The Wi-Fi name (SSID), Wi-Fi password, and device password are printed on the device label on the bottom of the device. MODEM SSID: Password: D-Link G403C User Manual...
- Page 17 If you are connecting to a broadband service that uses a dynamic connection (not PPPoE), you may be online already. Try opening a web browser and connecting to a website. If the website does not load, proceed to Setup Wizard on page 13. D-Link G403C User Manual...
-
Page 18: Setup Wizard
Section 2 - Installation Setup Wizard The setup wizard is designed to guide you through a step-by-step process of configuring your new G403C for Internet connection. If this is your first time installing the router, open your web browser and http://192.168.125.1... - Page 19 PPPoE, DHCP or static IP; if you choose Wireless ISP mode, you can connect to an AP on the Site Survey page under the Wireless menu. WAN Interface Setup: select one of the 3 methods for WAN connection: PPPoE, Dynamic IP, and Static IP. D-Link G403C User Manual...
- Page 20 MAC address as the MAC address for the WAN interface. Click Next to continue. Note: Be sure to remove all other existing PPPoE software from your computer. The software is no longer needed and will not work through a router. D-Link G403C User Manual...
- Page 21 ISP. For MAC address clone, select one of the connected client's MAC address as the MAC address for the WAN interface. Click Next to continue. LAN Interface Setup: enter the IP Address and Subnet Mask for your LAN interface. Click Next to continue. D-Link G403C User Manual...
- Page 22 Wi-Fi network. Your wireless clients will need this network password to be able to connect to your wireless network. If you chose the Gateway mode at Step 1, click Finished to save the configuration of the router and exit the wizard. D-Link G403C User Manual...
- Page 23 Site Survey page to connect to an AP. Click Next to continue. Configure the Encryption and authentication methods to connect to your ISP's lick Finished to save the configuration of the router and exit the wizard. D-Link G403C User Manual...
-
Page 24: Configuration
The top pane has quick access to Status, Setup, Network, LTE, Wireless, Features, and Management menu. You can access functions to manage and configure your router through these menus. Note: The system will automatically log out after a period (300 seconds) of inactivity. D-Link G403C User Manual... -
Page 25: Status
The Status page displays whether the router is currently connected to the Internet. If it is disconnected, click Click to repair to bring up the setup wizard, refer to the Setup Wizard on page 13 for more information. G403C D-Link G403C User Manual... -
Page 26: Internet
Displays the current IP address of the router. Default Gateway Displays the default gateway's IP address. Primary DNS Server Displays the IP address of the primary DNS server. Secondary DNS Server Displays the IP address of the secondary DNS server. D-Link G403C User Manual... -
Page 27: Lte Network
Reference Signal Received Quality (RSRQ), which measures the signal level and quality for the LTE network. Cell_ID Indicates the cell tower or site. SINR Signal-to-interference-plus-noise ratio, which measures the quality of wireless signal by taking account of noise and other interfering factors. D-Link G403C User Manual... -
Page 28: G403C
Section 3 - Configuration G403C Click on the G403C icon to view details about the router and its wireless settings. Here you can see the router’s current Wi-Fi network name and password, as well as the router's MAC address, IPv4 address, and IPv6 address. -
Page 29: Connected Clients
Click on the Connected Clients icon to obtain information about the connected clients of the router. On this page you can see all the clients currently connected to the router along with their IP addresses and MAC addresses. D-Link G403C User Manual... -
Page 30: Status - Wan Status
Displays whether the WAN connection type is connected or disconnected. IP Address Displays the current IP address of the WAN interface. Gateway Displays the gateway's IP address. Displays the IP address of the DNS server. Click Save when you are done. D-Link G403C User Manual... -
Page 31: Status - Openvpn Status
Displays the IP address of the OpenVPN server. Local IP Address Displays the IP address of the local end. Remote IP Address Displays the IP address of the remote end. Status Displays whether the OpenVPN connection is connected or disconnected. D-Link G403C User Manual... -
Page 32: Status - User Traffic
The total amount of downlink data of the client. Total Up The total amount of uplink data of the client. LTE Down The total amount of downlink data through LTE connection. LTE Up The total amount of uplink data through the LTE connection. D-Link G403C User Manual... -
Page 33: Status - Statistics
LAN network in bytes. The total amount of data that is sent and received through the Ethernet WAN in bytes. The total amount of data that is sent and received through the LTE network. D-Link G403C User Manual... -
Page 34: Setup
Go to Settings > Wizard to open the setup wizard. This is the same wizard that appears when you start the router for the first time. Refer to Setup Wizard on page 13 for details. Note: When the Wizard is opened, the router will disconnect from the Internet. D-Link G403C User Manual... -
Page 35: Setup
NAT. Site survey to an access point can be accessed by going to Wireless > Site Survey. You should then configure the router's wireless mode to be Client to uplink to an AP wirelessly. D-Link G403C User Manual... -
Page 36: Network
Enter the length of time for the IP address lease in minutes. The default is 10080 minutes. Enter the DNS IP address of the DHCP assignment. Domain Name Enter the domain name of the DHCP assignment. D-Link G403C User Manual... - Page 37 Click Save&Apply to save the DHCP assignment entry or click Reset to discard the entry. You can also select a specific entry of the Static DHCP List to delete it or click Delete All to erase all records. D-Link G403C User Manual...
-
Page 38: Wan Setting
To configure the IPv6 Internet and network connection details, click the IPv6 WAN Setting tab. Refer to IPv6 WAN Setting on page 38. For Dynamic IP (DHCP) refer to page 34 For Static IP refer to page 35 For PPPoE refer to page 36 D-Link G403C User Manual... -
Page 39: Dynamic Ip (Dhcp)
MAC address on the router. You can replace the WAN port’s MAC address with the MAC address of a connected client. Enable VLAN assignment on the WAN. Enable VLAN VLAN ID Enter the VLAN ID. Click Save&Apply after you have made changes on this page. D-Link G403C User Manual... -
Page 40: Static Ip
MAC address on the router. You can replace the WAN port’s MAC address with the MAC address of a connected client. Enable VLAN Enable VLAN assignment on the WAN VLAN ID Enter the VLAN ID. Click Save&Apply after you have made changes on this page. D-Link G403C User Manual... -
Page 41: Pppoe
MAC address on the router. You can replace the WAN port’s MAC address with the MAC address of a connected client. Enable VLAN Enable VLAN assignment on the WAN VLAN ID Enter the VLAN ID. Click Save&Apply after you have made changes on this page. D-Link G403C User Manual... -
Page 42: Openvpn
If you chose username/password as the authentication method, enter the password for VPN connection authentication. Select File Browse for the OpenVPN connection profile file (.ovpn) in your local directory. Upload Upload the connection profile to start establishing a connection. D-Link G403C User Manual... -
Page 43: Ipv6 Wan Setting
To configure the IPv4 Internet and network connection details, click the WAN Setting tab. Refer to WAN Setting on page For IPv6 - Auto Detection refer to page 39 For IPv6 - Static on page 40 For IPv6 - 6rd refer to page 41 D-Link G403C User Manual... -
Page 44: Ipv6 - Auto Detection
AFTR IPv6 Address Enter a valid IPv6 address. Enable MLD Proxy Enable the router to operate as Multicast Listener Discovery (MLD) proxy for IPv6 multicast routing. Click Save&Apply after you have made changes on this page. D-Link G403C User Manual... -
Page 45: Ipv6 - Static
AFTR IPv6 Address Enter a valid IPv6 address. Enable MLD Proxy Enable the router to operate as Multicast Listener Discovery (MLD) proxy for IPv6 multicast routing protocols. Click Save&Apply after you have made changes on this page. D-Link G403C User Manual... -
Page 46: Ipv6 - 6Rd
Enter the 6rd border relay IPv4 address settings supplied by Address your ISP. Enter the DSN server address in IPv6 provided by your ISP. Enable MLD Proxy Enable the router to operate as Multicast Listener Discovery (MLD) proxy for IPv6 multicast routing. D-Link G403C User Manual... -
Page 47: Ipv6 - Lan Setting
Enter the prefix's preferred lifetime. It must be less than or equal to the address's valid lifetime. Prefix Enter the prefix for manual assignment. Enable MLD Proxy Enable the router to operate as Multicast Listener Discovery (MLD) proxy for IPv6. D-Link G403C User Manual... -
Page 48: Vlan Bridge
Displays the current ULA prefix. Tagged/Untagged Port The tagged port and the untagged port will be displayed Select a VLAN configuration on the table and click Delete to delete it. Click Save&Apply after you have made changes on this page. D-Link G403C User Manual... -
Page 49: Default Route
Connect name The name of the WAN connection. Type The IP assignment method of the WAN interface. VLANMuxID The assigned VLAN ID for this WAN interface. Click Up to select the connection as the default gateway route. D-Link G403C User Manual... -
Page 50: Static Route
You can select a configured static route from the Static Route Table to delete it or click Delete All to delete all records of the table. Click Save&Apply after you have made changes on this page. D-Link G403C User Manual... -
Page 51: Ping Check
Select Ping Check to enable the ping command. Default Route Period time (sec) Enter the lifetime of the ICMP packets, Ping IP 1/2/3/4/5 Enter the IP address or web address to be the destination address. Click Save&Apply to execute the command. D-Link G403C User Manual... -
Page 52: Lte
Enter the Access Point Name manually above Bridge Enable bridge mode Roaming Enable roaming Manual DNS Enable this and enter the DNS server address manually below. Click Save&Apply after you have made changes on this page. D-Link G403C User Manual... -
Page 53: Pin Manage
Go to LTE > PIN Manage to configure PIN code to lock and unlock your SIM card. Operation Select Lock or Unlock your SIM. Then enter the PIN code below. Enter the PIN. Click Save&Apply after you have made changes on this page. D-Link G403C User Manual... -
Page 54: Sms Send
Go to LTE > SMS Send to send SMS messages. Country Code Enter the country code of the number that you tried to contact with. Contact Enter the contact name. Message Enter your message. Click Send to send the message or Back to cancel it. D-Link G403C User Manual... -
Page 55: Sms Inbox
Go to LTE > SMS Inbox to access the messages stored in the Inbox. Number The phone number of the sender. Content The content of the message. Time The timestamp of the message. Select a message and click Delete to delete the message. D-Link G403C User Manual... -
Page 56: Sms Outbox
Go to LTE > SMS Outbox to access the messages stored in the outbox. Number The phone number of the receiver. Content The content of the message. Select a message and click Delete to delete the message. D-Link G403C User Manual... -
Page 57: Sms Settings
Go to LTE > SMS Settings to configure how you would like to save your SMS messages. Storage Select either SIM Card or Module to save the messages directly in SIM or in the device's storage module. Click Save&Apply after you have made changes on this page. D-Link G403C User Manual... -
Page 58: Ussd
Unstructured Supplementary Service Data (USSD) allows ISP-specific applications to be activated with an SMS message. Send to Enter a predefined code or symbols to send via USSD. Enter an application activation code and click Send. Click Send to send your request. D-Link G403C User Manual... -
Page 59: At Command
Go to LTE > AT Command to send and receive device and cellular network parameters via the AT command. AT Command Enter the command. Click RUN to execute your command. Click Refresh to reload the result. D-Link G403C User Manual... -
Page 60: Data Cap
Enable the data limit function and enter the maximum volume allowed in MB every day in Data Cap Allowance Daily. Click Reset to reset the daily limit counter. Click Refresh to reload the result. Click Save&Apply after you have made changes on this page. D-Link G403C User Manual... -
Page 61: Band Setting
LTE B3 LTE B5 LTE B7 LTE B8 LTE B20 LTE B28 LTE B38 LTE B40 LTE B41 Select one of the available bands to operate with the LTE connection. Then click Save&Apply to save your changes. D-Link G403C User Manual... -
Page 62: Wireless
Select 40MHz if you are only using only 802.11n devices. Control Sideband Control channels are only applicable if your router is operating the 802.11n standard. The lower side band means channels 1-7 will be used whereas upper side band will use channels 5-13. D-Link G403C User Manual... - Page 63 AP1-AP4 Enable or disable each virtual AP. Band Select the wireless bands for the AP. SSID Enter the wireless name for the AP. Broadcast SSID Enable or disable the SSID to be broadcast in the network. D-Link G403C User Manual...
- Page 64 SSID The wireless name for the AP. Encryp The security method used for this wireless network. Click Delete Selected to delete a selected wireless profile or click Delete All to delete all records of the list. D-Link G403C User Manual...
-
Page 65: Security
Select either HEX or passphrase for your pre-shared key. For HEX, you must enter 64 hexadecimal characters (0-9, a-f or A-F). Pre-Shared Key Enter the pre-shared key according to the format selected above. Click Save&Apply after you have made changes on this page. D-Link G403C User Manual... -
Page 66: Access Control
Click Save&Apply at any time to save the changes you have made on this page. You can click Reset to discard your entry. The table below will display the Access Control list to allow further modification. You can delete any entry or reset all the configured list. D-Link G403C User Manual... -
Page 67: Site Survey
Select either ASCII or Hex. For HEX, you must enter hexadecimal characters (0-9, a-f or A-F) Authentication Mode For WPA encryption, select either Enterprise or Personal. WPA/WPA2 Cipher Select the cipher suite for the respective WPA encryption Suite selected above: TKIP or AES. D-Link G403C User Manual... - Page 68 Wireless Profile (go to Wireless > Basic Settings). You can then later select the wireless profile to connect to. Select either Reboot Now or Reboot Later to apply the settings. D-Link G403C User Manual...
-
Page 69: Wps
Click this button to strop the WPS process. The table below displays the currently configured wireless parameters that will be used for WPS is initiated for connection. Click Save&Apply at any time after you have made changes on this page. D-Link G403C User Manual... -
Page 70: Schedule
Select the start time (HH:MM) and end time (HH:MM) with the clock time (0~23) for the schedule. You can click Reset to discard the changes your have made on this page. Click Save&Apply after you have made changes on this page. D-Link G403C User Manual... -
Page 71: Qr Code
Go to Wireless > QR Code to access the QR code for wireless network setting. The QR code can be downloaded and shared to mobile devices so they can use the network settings to connect to the router. D-Link G403C User Manual... -
Page 72: Features
LAN and WAN side connection. Enable Web Server Allow encrypted web access from the WAN interface. Then HTTPs Access on WAN enter the https port number for both the LAN and WAN side connection. D-Link G403C User Manual... - Page 73 If you are having trouble making VoIP calls, try turning this Application Layer Gateway off. Wifi Guest Access Enable clients connected to a guess SSID to access the router's Router web interface. Click Save&Apply after you have made changes on this page. D-Link G403C User Manual...
-
Page 74: Port Filtering
Select the protocol of the traffic: TCP, UDP, or Both. Comment Write a brief description for this rule. A maximum of 20 rules can be defined. Click Save&Apply after you have made changes on this page. D-Link G403C User Manual... -
Page 75: Ip Filtering
Write a brief description for this rule. A maximum of 20 rules can be defined. Click Save&Apply after you have made changes on this page. You can alter delete a configured rule from the IP Filter Table. D-Link G403C User Manual... -
Page 76: Mac Filtering
Write a brief description for this rule. A maximum of 20 rules can be defined. Click Save&Apply after you have made changes on this page. You can alter delete a configured rule from the MAC Filter Table. D-Link G403C User Manual... -
Page 77: Port Forwarding
Enter a brief description for this rule. A maximum of 20 rules can be defined. Click Save&Apply after you have made changes on this page. You can alter delete a configured rule from the Port Forwarding Table. D-Link G403C User Manual... -
Page 78: Url Filtering
"www.ABC.com" and "xxx.ABC.com" and other URLs containing ABC. A maximum of 16 rules can be defined. You can delete an existing entry by clicking Delete Selected or Delete All. Or click Reset to cancel your selection. D-Link G403C User Manual... -
Page 79: Management
Enter the NTP server's IP address or server name for automatic Update time synchronization Automatically Adjust Enable the daylight savings time option if NTP is enabled. for Daylight Saving Click Save&Apply after you have made changes on this page. D-Link G403C User Manual... -
Page 80: Ddns
Enter the host name that you registered with your dynamic DNS service provider User Name/Email Enter your dynamic DNS account name Password/Key Enter your dynamic DNS account password Click Save&Apply at any time to save the changes after you have made changes on this page. D-Link G403C User Manual... -
Page 81: Deny Of Service
Packets/Second from a single source. Enable the UDP flood attack and define the number of Packets/Second from a single source. Enable the ICMP flood attack and define the number of Packets/Second from a single source. D-Link G403C User Manual... - Page 82 Echo Request/Reply service and the Chargen service. Enable Source IP Define the number of times per second to set the limit to block Blocking traffic from the same IP address. Click Apply Changes after you have made changes on this page. D-Link G403C User Manual...
-
Page 83: System Log
Check this box to send the router logs to a SysLog Server. Log Server IP Enter the IP address of the Syslog server. Address Log Server Port Enter the port number of the Syslog server. Click Apply Changes after you have made changes on this page. D-Link G403C User Manual... -
Page 84: Password
The Password page allows you to change the administrator account password.s New Password Enter a new password. Confirm Password Enter the new password again. Click Save & Apply after you have made changes on this page. D-Link G403C User Manual... -
Page 85: Ping Diagnostic
The Ping Diagnostic page lets you verify the availability of a destination host. Host Name or IP To perform a test, select either IPv4 or IPv6 , then enter the IP Address address or web address in the Address field. Then click RUN. D-Link G403C User Manual... -
Page 86: Traceroute
The Traceroute page shows the route of data transferred to a destination host Host Name or IP To perform a test, select either IPv4 or IPv6 , then enter the IP Address address or web address in the Address field. Then click RUN. D-Link G403C User Manual... -
Page 87: System Settings
If you want to back up the current router configuration settings before restoring to factory defaults, use the Save Settings to File function above. Reboot the Device Click this button to reboot the router immediately. D-Link G403C User Manual... -
Page 88: Auto Reboot
Select how often you want the router to perform automatic reboot. Reboot Time Select the time to reboot the device in 24-hour clock time. Click Save & Apply at any time to save the changes you have made on this page. D-Link G403C User Manual... -
Page 89: Upgrade Firmware
The new firmware version will be displayed after the new firmware file is uploaded. Select File Click Select File to upload the new firmware from you computer. Upload Click Upload to start uploading the new firmware. D-Link G403C User Manual... -
Page 90: Logout
Section 3 - Configuration Logout Go to Management > Logout. On the Logout page, you can log out of the router. You will then be redirected to the login page of the web interface. D-Link G403C User Manual... -
Page 91: Connect A Wireless Client To Your Router
Step 2 - Within 2 minutes, press the WPS button on your wireless device (or launch the software utility and start the WPS process). Step 3 - Allow up to 1 minute for your connection to be configured. Once the LED stops blinking, you will be connected with the default security method (i.e. WPA2/WPA3-mixed). D-Link G403C User Manual... -
Page 92: Windows® 11/10
Windows® 11/10 When connecting to the G403C wirelessly for the first time, you will need to input the wireless network name (SSID) and Wi-Fi password (security key) of the device you are connecting to. If your product has a Wi-Fi configuration card, you can find the default network name and Wi-Fi password here. - Page 93 Your computer will now automatically connect to this wireless network when it is detected. You can also use Wi-Fi Protected Setup (WPS) to connect to the router. Press the WPS button on your router and you will be automatically connected. D-Link G403C User Manual...
-
Page 94: Troubleshooting
1. Why can’t I access the web-based configuration utility? When entering the IP address of the D-Link router (192.168.125.1 for example), you are not connecting to a website, nor do you have to be connected to the Internet. The device has the utility built-in to a ROM chip in the device itself. Your computer must be on the same IP subnet to connect to the web-based utility. - Page 95 Section 7 - Troubleshooting • Access the web management. Open your web browser and enter the IP address of your D-Link router in the address bar. This should open the login page for your web management. • If you still cannot access the configuration, unplug the power to the router for 10 seconds and plug back in. Wait about 30 seconds and try accessing the configuration.
-
Page 96: Wireless Basics
D-Link wireless products are based on industry standards to provide easy-to-use and compatible high-speed wireless connectivity within your home, business, or public access wireless networks. Strictly adhering to the IEEE standard, the D-Link wireless family of products will allow you to securely access the data you want, when, and where you want it. You will be able to enjoy the freedom that wireless networking delivers. - Page 97 Who uses wireless? Wireless technology has become so popular in recent years that almost everyone is using it, whether it’s for home, office, business, D-Link has a wireless solution for it. D-Link G403C User Manual...
- Page 98 The wireless connection in public places is usually called “hotspots”. Using a D-Link USB adapter with your laptop, you can access the hotspot to connect to the Internet from remote locations like: airports, hotels, coffee shops, libraries, restaurants, and convention centers.
- Page 99 Security Don’t let your next-door neighbors or intruders connect to your wireless network. Secure your wireless network with the latest WPA3 security. Refer to the product manual for detail information on how to set it up. D-Link G403C User Manual...
-
Page 100: Networking Basics
Check your IP address After you install your new D-Link adapter, by default, the TCP/IP settings should be set to obtain an IP address from a DHCP server (i.e. wireless router) automatically. To verify your IP address, please follow the steps below. - Page 101 Set Preferred DNS the same as the LAN IP address of your router. The Alternate DNS is only optional or you may enter a DNS server from your ISP. 5. When you’re done, click Save. D-Link G403C User Manual...
-
Page 102: Wireless Security
WPA 3 has the strongest security among these with the increased cryptographic capability and the requirements of the Protected Management Frames (PMFs) to protect from snooping attack. D-Link G403C User Manual... -
Page 103: Technical Specifications
2 x LTE/3G fixed external antennas Security • WPA3-Personal/WPA2-Personal/WPA-Personal/None • Wi-Fi Protected Setup (WPS) WAN Connection Type • Static IP • Dynamic IP • PPPoE Power • Input: 100 to 240 V AC, 50 / 60 Hz D-Link G403C User Manual... -
Page 104: Regulatory Statements
Note The country code selection is for non-USA models only and is not available to all USA models. Per FCC regulations, all WiFi product marketed in the USA must be fixed to USA operational channels only. D-Link G403C User Manual... - Page 105 Potencia máxima de Salida Frequenza/e Potenza max. Output Frequentie(s) Max. Output Power 5.15 – 5.25 GHz 200 mW 5.25 – 5.35 GHz 200 mW 5.47 – 5.725 GHz 2.4 G 2.4 – 2.4835 GHz 100 mW D-Link G403C User Manual...
-
Page 106: European Community Declaration Of Conformity
υλικολογισμικό του προϊόντος είναι διαθέσιμα για λήψη από τη σελίδα του προϊόντος στην τοποθεσία www.dlink. com. Par les présentes, D-Link Corporation déclare que ce produit, ces accessoires et ce logiciel sont conformes aux Français [French] directives 2014/53/UE.Le texte complet de la déclaration de conformité de l'UE et le icroprogramme du produit sont disponibles au téléchargement sur la page des produits à... - Page 107 2014/53/EU. Pełen tekst deklaracji zgodności UE oraz oprogramowanie sprzętowe do produktu można pobrać na stronie produktu w witrynie www.dlink.com. Desta forma, a D-Link Corporation declara que este produto, os acessórios e o software estão em conformidade Português [Portuguese] com a diretiva 2014/53/UE. O texto completo da declaração de conformidade da UE e do firmware...
-
Page 108: Warning Statement
Appendix E - Regulatory Information Hér með lýsir D-Link Corporation því yfir að þessi vara, fylgihlutir og hugbúnaður eru í samræmi við tilskipun Íslenska [Icelandic] 2014/53/EB. Sækja má ESB-samræmisyfirlýsinguna í heild sinni og fastbúnað vörunnar af vefsíðu vörunnar á www. - Page 109 Die Funktionalität im Ad-hoc-Modus bei Betrieb auf 5 GHz ist für dieses Gerät eingeschränkt. Bei dem Ad-hoc-Modus handelt es sich um eine Peer-to-Peer-Kommunikation zwischen zwei Client-Geräten ohneeinen Access Point. • Bitte schlagen Sie im Handbuch oder Datenblatt nach nach, ob Ihr Gerät eine 2,4 GHz und / oder 5 GHz Verbindung nutzt. D-Link G403C User Manual...
-
Page 110: Notes D'utilisation
• Por favor compruebe el manual o la ficha de producto para comprobar si el producto utiliza las bandas inalámbricas de 2.4 GHz y/o la de 5 GHz. D-Link G403C User Manual... - Page 111 Dit toestel kan niet functioneren in Ad-hoc mode wanneer het gebruikt wordt in 5 GHz. Ad-hoc mode is directe peer-to-peer communicatie tussen twee klantenapparaten zonder een toegangspunt.. • Raadpleeg de handleiding of de datasheet om te controleren of uw product gebruik maakt van 2.4 GHz en/of 5 GHz. D-Link G403C User Manual...
- Page 112 • Halten Sie das Produkt von Heizkörpern und anderen Quellen fern, die Wärme erzeugen. • Trennen Sie das Produkt immer von der Stromzufuhr, bevor Sie es reinigen und verwenden Sie dazu ausschließlich ein trockenes fusselfreies Tuch. D-Link G403C User Manual...
- Page 113 • Mantenga el producto alejado de los radiadores y de otras fuentes de calor. • Desenchufe siempre el producto de la alimentación de red antes de limpiarlo y utilice solo un paño seco sin pelusa. D-Link G403C User Manual...
- Page 114 • Houd het product uit de buurt van radiators en andere warmtebronnen. • U dient het product steeds los te koppelen van de stroom voordat u het reinigt en gebruik uitsluitend een droge pluisvrije doek. D-Link G403C User Manual...
- Page 115 D-Link designs and builds its products to be as environmentally friendly as possible, by using recyclable, low toxic materials in both products and packaging. D-Link recommends that you always switch off or unplug your D-Link products when they are not in use. By doing so you will help to save energy and reduce CO2 emissions.
- Page 116 D-Link et l’environnement Chez D-Link, nous sommes conscients de l'impact de nos opérations et produits sur l'environnement et nous engageons à le réduire. Pour limiter cet impact, D-Link conçoit et fabrique ses produits de manière aussi écologique que possible, en utilisant des matériaux recyclables et faiblement toxiques, tant dans ses produits que ses emballages.
- Page 117 D-Link zijn producten zo milieuvriendelijk mogelijk, door het gebruik van recycleerbare producten met lage toxiciteit in product en verpakking. D-Link raadt aan om steeds uw D-Link producten uit te schakelen of uit de stekker te halen wanneer u ze niet gebruikt. Door dit te doen bespaart u energie en beperkt u de CO2-emissies.
- Page 118 D-Link a životní prostředí Ve společnosti D-Link jsme si vědomi vlivu našich provozů a výrobků na životní prostředí a snažíme se o minimalizaci těchto vlivů. Proto své výrobky navrhujeme a vyrábíme tak, aby byly co nejekologičtější, a ve výrobcích i obalech používáme recyklovatelné a nízkotoxické materiály.
- Page 119 D-Link produkter som er så miljøvennlig som mulig, ved å bruke resirkulerbare, lav-toksiske materialer både i produktene og forpakningen. D-Link anbefaler at du alltid slår av eller frakobler D-Link-produkter når de ikke er i bruk. Ved å gjøre dette hjelper du å spare energi og å redusere CO2-utslipp.
- Page 120 D-Link sine produkter, så de er så miljøvenlige som muligt, ved at bruge genanvendelige materialer med lavt giftighedsniveau i både produkter og emballage. D-Link anbefaler, at du altid slukker eller frakobler dine D-Link-produkter, når de ikke er i brug. Ved at gøre det bidrager du til at spare energi og reducere CO2-udledningerne.
- Page 121 D-Link och miljön På D-Link förstår vi och är fast beslutna att minska den påverkan våra verksamheter och produkter kan ha på miljön. För att minska denna påverkan utformar och bygger D-Link sina produkter för att de ska vara så miljövänliga som möjligt, genom att använda återvinningsbara material med låg gifthalt i både produkter och förpackningar.
