INTERCOM 1300
A U D I O
C O N T R A C T O R
Microphone intercom system
MICROPHONE INTERCOM SYSTEM
Installed in different rooms the intercom system allows users to speak and listen at
each end without having to press any buttons. The kit is composed of three separate
modules: control station, power supply, loudspeaker unit with integral microphone.
The devices function in half-duplex (one-at-a-time) mode and activation thresholds are
modified automatically in relation to environmental background noise levels. The
operator station can enable one-way operation, i.e. exclusively automatic listening,
with speak facility at the press of a button.
INTERCOM 1300 composed of:
- SIBK 013 control station
- AASL 012 power supply
- SICK 012 loudspeaker-microphone enclosure with connection cable
OPTIONAL:
- SICK 013 supplementary loudspeaker for operator station headset with microphone
for operator station
INSTRUCTIONS FOR USE
FBT ELETTRONICA S.p.A. - Via Paolo Soprani, 1 - ZONA IND. SQUARTABUE - 62019 RECANATI (MC) - ITALY
Advertisement
Related Manuals for Fbt INTERCOM 1300
Summary of Contents for Fbt INTERCOM 1300
- Page 1 - SICK 012 loudspeaker-microphone enclosure with connection cable OPTIONAL: - SICK 013 supplementary loudspeaker for operator station headset with microphone for operator station INSTRUCTIONS FOR USE FBT ELETTRONICA S.p.A. - Via Paolo Soprani, 1 - ZONA IND. SQUARTABUE - 62019 RECANATI (MC) - ITALY...
-
Page 2: General Warranty Conditions
WARNINGS Please, read this instruction sheet carefully. FBT Elettronica SpA will accept no liability for personal injury and/or damage to property resulting from incorrect installation or improper use of the product. The speaker unit must be set up by trained personnel. Incorrect installation could result in the risk of electric shocks. - Page 3 Kit is composed by three units: control base, power supply and diffuser with integrated microphone. INTERCOM 1300 operates with half-duplex system checking internal and external intensity sound. Is allowed to talk to one person by time and thresholds speech change automatically on the basis of noise in the room.
- Page 4 EXTERNAL DIFFUSER FEATURES Inside the acoustic diffuser there is an electret microphone. DIFFUSER FEATURES - Impedance: 8 Ohm - Power: 2W - Power: 4W peak - Frequency response: 200Hz - 6kHz OMNIDIRECTIONAL MICROPHONE FEATURES - Sensitivity: -44dB - Impedance: 600 Ohm - Frequency response: 50Hz - 15kHz AASI 012 POWER SUPPLY FEATURES To it must be connected the diffuser and the command base.
- Page 5 SIBK 013 FEATURES AND SPECIFICATIONS Commands on the base are: 1) Integral speaker (minimum level of volume doesn't decrease under 50%). 2) Speaker hearing volume set up. 3) Luminous indicator of turned on base 4) On/Off button 5) Button PTT (push to talk). CALIBRATION MODALITY: 1) Disconnect the base from the power supply, control right connection of equipments, insert plug of power supply verifing...
- Page 6 FEATURES OF ACCESSORIES There are two optionals to set up the system optimally even in critical room conditions: A) 1W additional diffuser to put near the user. This diffuser take power directly from AASI 012. Inside there is a tone control, adjustable with a screwdriver. B) Headphone with microphone, to use in rooms excessively noisy.
- Page 8 Le informazioni contenute in questo manuale sono state scrupolosamente controllate; tuttavia non si assume nessuna responsabilità per eventuali inesattezze. La FBT Elettronica S.p.A. si riserva il diritto di modificare le caratteristiche tecniche ed estetiche dei prodotti in qualsiasi momento e senza preavviso.
