Burcam 450446 Installation Instructions

2190 Dagenais Blvd. West
2190 Dagenais Blvd.West
LAVAL (QUEBEC)
Laval (Quebec)
CANADA
Canada
H7L 5X9
H7L 5X9
see us at
STEP 1
Fix the switch to the discharge
line using the enclosed clamp.
The clamp should be mounted
approximately 9 1/2" to 10'' (25cm)
above the pump discharge.
STEP 2
The minimum and maximum water
level adjustments were done at the
factory, for most of the submersible
sump pumps. You may change the
adjustment by raising or lowering
the position of the metal stoppers.
The upper stopper should be at
approximately 5 1/2'' (14cm) above
the lower stopper.
STEP 3
Plug the switch cable in the recep-
tacle, then plug the pump cable in
the piggy-back of the switch cable.
W W W. B U R C A M . C O M
TEL: 514.337.4415
Tel. : 514.337.4415
FAX: 514.337.4029
Fax : 514.337.4029
info@burcam.com
info@burcam.com
www.burcam.com
INSTALLATION
INSTRUCTIONS
MODEL
450446
VERTICAL
MAGNETIC
SWITCH
Please read these
carefully. Failure
to comply to
instructions and
may void the
9 1/2" to 10''
(25 cm)
Electric pump,
check valve and
pipe not included
instructions
designed
operation of
this system,
warranty.
