Q-Track Quick Start Card
Thank you for purchasing Quanergy's Q-Track LiDAR sensors. This card summarizes essential instructions for setting up
Sensor Overview
Q-Track is a LiDAR-based solution that provides 3D perception and volumetric sensing. This system detects, tracks, and
classifies (DTC) person and vehicle objects for use in security, smart cities and spaces applications. The Q-Track server
interfaces with Quanergy Q-Track sensors and generates a real-time list of tracked objects that is accessible through the
Q-Track API. The Q-Track client provides visualization and configuration of the Q-Track server
Required Items
Quanergy Components
• Q-Track LR, Q-Track HD, or Q-Track Dome sensors
• Dust cap for Q-Track LR female Ethernet connector (N/A for Q-Track Dome/HD)
• Connector cover for optional Ethernet cable modifications for Q-Track LR (N/A for Q-Track Dome/HD)
• Q-Track Software License
• Q-Track Server & Client package or executable files
• Q-View package or executable file
Additional Items (User-Provided)
•
PoE+ (IEEE 802.3at) compliant power source equipment (PSE)
• Male CAT6 Ethernet sensor cable for Q-Track LR
• Female CAT6 Ethernet sensor cable for Q-Track Dome & Q-Track HD
• PC/Server: Linux® Ubuntu® 20.04 LTS Certified or Windows® 10/11 PC to run Q-View™ and Qortex DTC
software.
Q-View
Ubuntu
1) Download the Q-View installer package to the Ubuntu host computer /Downloads directory.
a)
agree to licensing terms.
b) Click the Ubuntu link and download the Q View Debian package, quanergy-qview_1.x.xxx_amd64.deb. Where
x.xxx is the release number.
2) Open a new terminal on the host computer.
3) In the terminal window, run the installer from the download directory:
a) $ cd ~/Downloads (or to wherever you saved the package)
b) $ sudo dpkg -i quanergy-qview_1.x.xxx_amd64.deb (where x.xxx is the release number)
4) Start the Q-View application, run the command.
a)
$ /opt/quanergy/Q-View/Q-View
To quit Q-View, click the red Close button in the upper right corner of the window.
128 Baytech Drive, San Jose, CA 95134, USA | +1 (408) 245-9500 | info@quanergy.com | quanergy.com
and using the Q-Track LR, Q-Track HD, and Q-Track Dome sensors.
Note: Do not disassemble or modify the sensor.
Unauthorized tampering voids the warranty.
On the Quanergy Download Center URL, https://downloads.quanergy.com/#qview, click to
