BEFORE YOU START
• It is important that you contact your local government authority to determine if building approval is required.
• Refer to the 'Use of Gas Appliances' and 'Heat Shield Installation' sections for important safety information when using gas
appliances and managing heat build up. Ensure the Warning Sticker is installed in an adequate location as per Figure 10.8.
• Stratco offer an optional Gas Safety Shut-Off System which has been specifically designed for use with gas appliances within the shed.
This safety system provides additional safety when operating gas appliances in the shed. Refer to the 'Gas Safety Shut-Off System' section.
• An optional Strip Lighting Kit can be installed within the shed, providing an integrated and effective lighting solution. The Lighting
Kit must be installed during the installation steps as outlined within the guide.
•
There are two options for fixing the The Umbra
The concrete slab or post holes must be set prior to assembling the Shed. The options for fixing The Umbra
ground are:
Option 1: Fixing posts to a concrete slab with Masonry Anchors. Footings and Fasteners will be supplied with this option.
Option 2: Fixing posts into the ground with post holes and a concrete slab.
• The Umbra
Awning Shed is suitable for wind classifications N1,N2 & N3. The Umbra
®
wind classifications. Check with Stratco staff for the wind classification of the location The Umbra
• Care must be taken when determining the location of The Umbra
with sources of pollution or environmental factors that could affect the life of the steel.
• It is essential to clear and level the site prior to assembling your Awning Shed.
• There are different types and colours of screws used. Ensure the correct type and colour screw is being used at each location.
• Do not traverse or hang from any part of The Umbra
• The door must remain in the open position when operating a gas appliance within the shed. Never operate a gas appliance inside
the shed with the door closed.
• Use heavy gloves and safety glasses when handling steel and never attempt to install a shed in windy conditions.
• Parts of the installation require two people.
• For further detail please refer to the installation video on the Stratco website.
TOOLS AND HARDWARE REQUIRED
•
Rivet Gun
•
Tin Snips
•
Pliers
•
Large Flathead Screwdriver
•
13, 15 and 18mm Spanner
•
6mm & 8mm Allen Key
•
Rubber Mallet
•
Grinder with Cutting Disk or Hacksaw
THE UMBRA
Awning Shed to the ground. Determine the ground fixing method prior to assembly.
®
®
Awning Shed.
®
•
Cordless Drill
•
Hammer Drill (if Cordless Drill has no
Hammer function)
•
Masonry Drill Bit to suit provided
Masonry Anchors
•
5/16 Hex-head Bit
•
PH2 Phillips-head Bit
•
T20 Torx Bit (provided in box)
AWNING SHED
®
INSTALLATION GUIDE
Awning Shed is not suitable for N4 or Cyclonic
®
Awning Shed will be erected.
®
Awning Shed as to not place the shed in close contact
•
3.5mm Drill Bit
•
20mm Step Drill Bit
•
Tape Measure
•
Set Square
•
Trestles or Work Table
•
Ladder
•
Safety Glasses
•
Cut Resistant Gloves
Awning Shed to the
®
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Summary of Contents for Stratco UMBRA
- Page 1 Ensure the Warning Sticker is installed in an adequate location as per Figure 10.8. • Stratco offer an optional Gas Safety Shut-Off System which has been specifically designed for use with gas appliances within the shed.
- Page 2 THE UMBRA AWNING SHED INSTALLATION GUIDE ® COMPONENTS Drip Flashing Front Wall Corner Wall Side Door Bottom Door Top Door Side Barge Front Barge Flashing Flashing Flashing Flashing Flashing Flashing Flashing Gutter Downpipe Cavity Roof End Roof Wall Sheet Wall Sheet -...
- Page 3 2740mm Vented 2740mm Frame 2575mm Frame 900mm Frame 900mm Double 2190mm Frame 2920mm Frame Frame Brace Frame Height Frame Strut Pull Strap Door Handle Door Lock Downpipe Strap Downpipe Outlet Stop End and Spacer LH Strut Bracket End Cap Lower Strut Bracket Internal Strut Bracket Door Stop Bracket RH Strut Bracket...
-
Page 4: Heat Shield
THE UMBRA AWNING SHED INSTALLATION GUIDE ® COMPONENTS - OPTIONAL ADD-ONS STRIP LIGHTING KIT Light Flashing Strip Light Torx-Head Screw Light Switch Panel Connector Cable 2570mm x1 2560mm x1 Light Flashing Strip Light Torx-Head Screw Light Switch Panel Connector Cable... - Page 5 DIMENSIONS 2930mm - OVERALL WIDTH 2720mm - FRONT OPENING 3050mm 2200mm 1130mm - OVERALL DEPTH 875mm - INTERNAL DEPTH (with door closed) FIGURE 1.0...
-
Page 6: Main Frame Assembly
THE UMBRA AWNING SHED INSTALLATION GUIDE ® MAIN FRAME ASSEMBLY 1) 900mm Frame 2) 900mm Double Height Frame 3) 2920mm Frame 4) 2740mm Frame 5) 2740mm Vented Frame FIGURE 1.1... - Page 7 DOOR FRAME ASSEMBLY 6) 2190mm Frame 7) 2575mm Frame Outside Face Hinge End Inside Face FIGURE 1.2...
-
Page 8: Main Assembly
THE UMBRA AWNING SHED INSTALLATION GUIDE ® MAIN ASSEMBLY 8) 2190mm Sheet 13) End Roof Sheet 20) Stop End 27) Internal Strut Bracket 9) 2190mm Sheet 14) Cavity Roof Flashing 21) Gutter 28) Lower Strut Bracket - Double Overlap 15) Corner Wall Flashing... -
Page 9: Door Assembly
DOOR ASSEMBLY 33) LH Hinge Bracket 37) Strut 41) Top Door Flashing 45) Pull Strap 34) RH Hinge Bracket 38) 2190mm Sheet 42) Drip Flashing 46) Door Handle 35) LH Strut Bracket 39) 2190mm Sheet 43) Bottom Door Flashing 47) Door Lock - Double Overlap 36) RH Hinge Bracket 44) Frame Brace... - Page 10 THE UMBRA AWNING SHED INSTALLATION GUIDE ® 2800mm GROUND FIXING OPTION 1 Fit the Footing into the 2920mm Frame. Fasten the Frame to the Footing using four 12Gx20mm Plain Hex-Head Self- ANCHORING POSTS TO A CONCRETE SLAB Drilling Screws through the pilot holes. Assemble the...
- Page 11 Assemble the Frame as per Figure 4.0 to 4.1 and then return to this step. Once the concrete is set, position the Frame Assembly onto the Concrete Slab in the final anchoring position. 1) Drill two holes through all four Footings and into the Concrete Slab using a Masonry Drill Bit. 2) Fasten the Footings using two M10 Masonry Anchors through the holes in each of the four Footings (Figure 2.3).
- Page 12 THE UMBRA AWNING SHED INSTALLATION GUIDE ® GROUND FIXING OPTION 2 - FIXING POSTS INTO THE GROUND WITH A SLAB Follow this step if fixing Posts into the ground with post holes and a slab, otherwise skip this step. Assemble the Frame as per Figure 4.0 to 4.1 and then return to this step.
-
Page 13: Frame Assembly
FRAME ASSEMBLY The Frame components are assembled using a ‘Slot & Lock’ connection. To lock Frame components together, fit the Rivets into the Slot & Lock Keyholes and push down. Assemble the 900mm and 2740mm Frames to the 2920mm Frames, ensuring correct Frame orientation as shown (Figure 4.0). - Page 14 THE UMBRA AWNING SHED INSTALLATION GUIDE ® Attach the 2740mm Vented Frame and 900mm Frame to the 2920mm Frames (Figure 4.1). Once steps in Figure 4.0 to 4.1 are complete, return to and complete the GROUND FIXING OPTION step. 2920mm Frame...
- Page 15 The front 2740mm Frame, 2740mm Vented Frame and four front 12Gx20mm Plain Hex-Head Self-Drilling Screws were installed to ensure the Frame Assembly was square during the ground fixing steps. These components can now be removed (Figure 4.2). 2740mm Frame 2740mm Vented Frame Remove the 12Gx20mm...
- Page 16 THE UMBRA AWNING SHED INSTALLATION GUIDE ® Attach the 900mm Double Height Frames and 2740mm Vented Frame to the 2920mm Frames (Figure 4.3). 2740mm Vented Frame 900mm Double Height Frame 2920mm Frame 900mm Double Height Frame FIGURE 4.3...
- Page 17 Attach the 900mm Frames to the 2920mm Frames. Note: Use a Large Flathead Screwdriver to pry the 900mm Frame ends into the key-holes. Attach the 2740mm Frame to the 900mm Double Height Frames (Figure 4.4). 900mm Frame 2920mm Frame 2740mm Frame 900mm Frame 900mm Double Height Frame...
-
Page 18: Lighting Kit (Optional)
THE UMBRA AWNING SHED INSTALLATION GUIDE ® LIGHTING KIT (OPTIONAL) Follow this step if installing a Lighting Kit, otherwise skip this step. Drill two 14mm holes into the 2920mm Frame for the Light Switch Controller cables. These holes are to be 100mm from the Double Height Frame and 100mm apart. - Page 19 Follow this step if installing a Lighting Kit, otherwise skip this step. Fasten the 2735mm Light Flashing to the 2740mm Frame using four Torx-Head Screws. Back off the four Torx-Head Screws so that the Light Flashing is loose. Connect one of the Splitter Cable ends to the Strip Light Cable Connector. Push the 2725mm Strip Light into the Light Flashing, tightening the Torx-Head Screws to lock the Strip Light into the Light Flashing (Figure 4.6).
- Page 20 THE UMBRA AWNING SHED INSTALLATION GUIDE ® Fasten three Torx-Head Screws through the pilot holes of the Internal Strut Bracket and into the pilot holes of the 2920mm Frame (Figure 4.7). Internal Strut Bracket 2920mm Frame Internal Strut Bracket 2920mm Frame...
- Page 21 DOOR FRAME ASSEMBLY Assemble two 2575mm Frames to the 2190mm Frames (Figure 5.0). 2575mm Frame 2575mm Frame 2190mm Frame 2190mm Frame FIGURE 5.0 Assemble two more 2575mm Frames to the 2190mm Frames (Figure 5.1). 2190mm Frame 2575mm Frame 2190mm Frame 2575mm Frame FIGURE 5.1...
- Page 22 THE UMBRA AWNING SHED INSTALLATION GUIDE ® Fit the two Frame Braces into the 2190mm Frames. Ensure the Frame Brace is oriented correctly so that the ‘Hole End’ of the Frame Brace is inserted first. Ensure the End of the Frame Brace is in-line with the end of the 2190mm Frame.
- Page 23 Follow this step if installing a Lighting Kit, otherwise skip this step. The Light Strip can be installed at the middle or end of the Door Frame. Remove the Removable Tab from the 2190mm Frame. Fit the Extension Cable into the 2190mm Frame (Figure 5.3). Extension Cable Cable - Male End Cable - Female End...
- Page 24 THE UMBRA AWNING SHED INSTALLATION GUIDE ® Before installing the Drip Flashing place the Frame Assembly on trestles or a work table. Fit the Drip Flashing to the Frame Assembly ensuring that it is centred on the frame. Fasten the Drip Flashing to the Frame using four Torx-Head Screws.
- Page 25 CLADDING/ SHEET ASSEMBLY NOTE: Two people are required to ensure ease and accuracy of the Cladding/ Sheet Assembly. Use a Set Square to ensure the Frame Assembly is square when fastening the Cladding to the Frame Assembly. Remove the plastic protective film and fit the Side Door Flashings onto the Door Frame Assembly. Fasten each Side Door Flashing to the Door Frame Assembly using two 10Gx16mm Hex-Head Self-Drilling Screws 45mm from each end (Figure 6.0).
- Page 26 THE UMBRA AWNING SHED INSTALLATION GUIDE ® Trim 125mm from both Front Wall Flashings, as to ensure they don’t interfere with the Frame (Figure 6.1). Fit both Front Wall Flashings to the Frame Assembly. Fasten both Front Wall Flashings to the Frame Assembly using six 10Gx16mm Hex-Head Self- Drilling Screws (Figure 6.1).
- Page 27 Trim 125mm x 80mm from both Corner Wall Flashings, as to ensure they don’t interfere with the Roof Sheets later in the assembly (Figure 6.2). Fit both Corner Wall Flashings to the Frame Assembly. Fasten both Corner Wall Flashings to the Frame Assembly using six 10Gx16mm Hex-Head Self-Drilling Screws (Figure 6.2).
- Page 28 Installing the Sheets requires two people. Fit a 2190mm Sheet to the Front Wall Flashing and Frame. Ensuring the Frame is square, fasten the Sheet to the Frame using six 10Gx16mm Hex-Head Self-Drilling Screws. Fit another 2190mm Sheet and 2190mm Sheet - Double Overlap to the Frame and fasten in the same manner (Figure 6.3). Double Overlap 2190mm Sheet - Double Overlap...
- Page 29 THE UMBRA AWNING SHED INSTALLATION GUIDE ® Ensuring the Frame is square, fasten the remaining Sheets in the order indicated below using six 10Gx16mm Hex-Head Self- Drilling Screws in each Sheet. Ensure the first 2060mm Sheet is approximately 40mm from the edge of the Corner Wall Flashing (Figure 6.4).
- Page 30 Before installing the Roof Sheets, turn-up each Roof Sheet 15mm along the front edge to prevent water ingress. Trim 30mm diagonally from the overlap on each sheet so the turn-up does not interfere when lapping sheets. Position the Roof Flashings and Roof Sheets on the Frame Assembly (Figure 6.5). Roof Flashing Roof Flashing 2740mm Frame...
- Page 31 THE UMBRA AWNING SHED INSTALLATION GUIDE ® Fit the End Roof Sheets over the Frame and Roof Flashings. Ensuring the Frame is square, fasten the Sheets to the Frame using four 10Gx16mm Hex-Head Self-Drilling Screws with Neoprene Washers in each Sheet (Figure 6.6).
- Page 32 THE UMBRA AWNING SHED INSTALLATION GUIDE ® BARGE FLASHINGS Fit the two Side Barge Flashings to the Unit so that they are flush with the Front Wall Flashings. Fit the End Caps into the Side Barge Flashings. Fasten the End Caps to the Side Barge Flashings using two 10Gx16mm Hex-Head Self-Drilling Screws with Neoprene Washers (Figure 7.0).
- Page 33 Trim 65mm x 15mm from both ends of the Front Barge Flashing. To prevent water ingress in extreme weather conditions, apply a bead of silicone where the Front Barge Flashing meets the Side Barge Flashings. Fit the Front Barge Flashing over the Frame and Roof Sheets (Figure 7.1).
- Page 34 THE UMBRA AWNING SHED INSTALLATION GUIDE ® GUTTER ASSEMBLY 1) Cut a 90mm x 50mm hole in the Gutter. The hole will fit the Downpipe Outlet and can be cut in either Gutter end. 2) Fit the Downpipe Outlet into the Gutter hole. Using the holes in the Downpipe Outlet as a guide, drill four 3.5mm holes into the Gutter.
- Page 35 1) Fit the Gutter onto the Side Barge Flashings. Fasten the Gutter to the Side Barge Flashings using two 10Gx16mm Hex-Head Self-Drilling Screws with Neoprene Washers at each end. 2) Fasten the Downpipe Strap and Spacer through the Sheet and into the Frame 220mm from the bottom edge of the Sheet with a 12Gx35mm Coloured Hex-Head Self-Drilling Screw (Figure 8.2).
- Page 36 THE UMBRA AWNING SHED INSTALLATION GUIDE ® 1) Downpipes are supplied at 3000mm lengths. Cut back the downpipe to the desired length (Approx. 1900mm). Fit the Downpipe over the Downpipe Outlet. Drill two 3.5mm holes through the Downpipe and into the Downpipe Outlet. Fasten the Downpipe to the Downpipe Outlet using two Rivets through the 3.5mm holes.
- Page 37 DOOR ASSEMBLY Note: It is recommended to position the Door onto Trestles or a Work Table to assist in assembling components and gain access to the underside of the Door. Remove the Lock Clips (1), Lock Pin (2) and Screw Covers (3). Reinstall the Lock Clips (4). Fit the two Door Locks onto the Door Assembly.
- Page 38 THE UMBRA AWNING SHED INSTALLATION GUIDE ® Fit the LH and RH Strut Brackets to the Door Frame Assembly. Fasten the Strut Brackets to the Frame using four Torx-Head Screws through the pilot holes provided in the top leg of the bracket (1), then use four Torx-Head Screws through the pilot holes in the side of the Bracket (2) (Figure 9.1).
- Page 39 Fit the LH and RH Door Hinge Brackets to the Door Assembly. Ensure the holes of the Strut Bracket and Door Hinge Bracket are aligned. Fasten the Door Hinge Brackets to the Frame using only ten Torx-Head Screws through the pilot holes on the side of the Bracket (Figure 9.2).
- Page 40 THE UMBRA AWNING SHED INSTALLATION GUIDE ® Fit the Struts to the Strut Brackets and Door Hinge Brackets. Ensure a 14mm Spacer is positioned either side of the Strut Eyelet and an M10 Washer is positioned on the outside of the Brackets. Fit the Shoulder Bolt through the Washers, Brackets, Spacers and Strut Eyelet.
- Page 41 1) Fit an Internal Hinge Bushing into the LH and RH Wall Hinge Brackets. 2) Fit the Wall Hinge Brackets to the Unit. Fasten the Wall Hinge Brackets to the Frame Assembly using eighteen Torx-Head Screws through the pilot holes. Fit an External Hinge Bushing onto both Internal Hinge Bushings (Figure 9.4).
- Page 42 THE UMBRA AWNING SHED INSTALLATION GUIDE ® Fit two Lower Strut Brackets to the Front Wall Flashings. Ensure the pilot holes of the Lower Strut Bracket and Internal Strut Bracket are in-line. Fasten the Lower Strut Brackets to the Front Wall Flashings using ten Torx-Head Screws through the pilot holes (Figure 9.5).
-
Page 43: Door Hanging
DOOR HANGING Warning: If ground fixing with Option 1 (Masonry Anchors) the Shed must be fixed to the concrete slab as per Figure 2.3 before continuing as to prevent the Shed from toppling over. Note: The Door Assembly weighs 57kg and may require three people to safely lift into position. Position the Door on the Main Assembly being careful not to damage the Front Barge Flashing. - Page 44 THE UMBRA AWNING SHED INSTALLATION GUIDE ® Use a large flathead screwdriver to position the Hinge Bracket Hole in the Hinge Bracket over the first External Hinge Bushing at both ends. Fit an External Hinge Bushing over the External Hinge Bushing. Ensure the Bushings and Brackets are assembled in the correct manner.
- Page 45 Ensure the gap between the Door Assembly and Main Assembly is equal on both sides. Fasten the Hinge Brackets to the Door Assembly using four Torx-Head Screws through the pilot holes provided (Figure 10.2). Ensure gap is equal to right hand side Ensure gap is equal to left hand side Torx-Head Screw...
- Page 46 THE UMBRA AWNING SHED INSTALLATION GUIDE ® Mark the location of both Door Lock Shafts against the Front Wall Flashings (Figure 10.3). Door Lock Shaft Mark this point FIGURE 10.3...
- Page 47 Note: The Door Assembly needs to be lifted to a height of 2.4m requiring 30kg of force to lift up. Two people may be required to safely lift the Door Assembly to the required height. Lift the Door Assembly up and into the open position. Fit the M10 Washers over the Strut Bolts. Fit the Strut Bolts into the holes of the Lower Strut Brackets.
- Page 48 THE UMBRA AWNING SHED INSTALLATION GUIDE ® Fit the Bottom Door Flashing up against the 2575mm Frame. Fasten the Bottom Door Flashing onto the 2575mm Frame using 10Gx16mm Hex-Head Self-Drilling Screws 100mm from both ends and the remaining three screws 630mm apart. The underside face of the Bottom Door Flashing is angled to facilitate drainage (Figure 10.5).
- Page 49 Fit the Pull Strap up against the mid-point of the 2575mm Frame. Fasten the Pull Strap to the 2575mm Frame using a 12Gx20mm Plain Hex-Head Self-Drilling Screw and an M8 Stainless Steel Washer (Figure 10.6). 12Gx20mm Plain Hex-Head Self-Drillling Screw M8 Stainless Steel Washer Pull Strap...
- Page 50 THE UMBRA AWNING SHED INSTALLATION GUIDE ® 1) Using the mark from Figure 10.3 as a guide, measure and mark the location of the Door Lock Shaft hole 15mm from the front edge of the Front Wall Flashings (Figure 10.7) Use a Step Drill Bit to drill a 20mm hole through the Front Wall Flashings.
- Page 51 Adhere both Door Closing Labels to the inside of the Shed in a location near the Struts. Adhere the Safety Warning Label in a clearly visible location inside the Shed. The optimal location may be determined after any internal insulation panels, appliances or kitchen units have been installed (Figure 10.8).
- Page 52 THE UMBRA AWNING SHED INSTALLATION GUIDE ® LIGHTING KIT (OPTIONAL) Follow this step if installing a Lighting Kit, otherwise skip this step. Close the door, referring to the ‘Door Closing Label’ if required. Fasten the 2570mm Light Flashing to the 2575mm Frame using four Torx-Head Screws.
- Page 53 Follow this step if installing a Lighting Kit, otherwise skip this step. Use the Step Drill Bit to drill a 12mm hole through the LH Roof Sheet 100mm from the Double Height Beam and 40mm from the front 2740mm Frame. Connect the male end of the Panel Connector Cable to the Splitter Cable (Figure 10.10). Remove the Nut and one O-ring from the Panel Connector Cable.
- Page 54 THE UMBRA AWNING SHED INSTALLATION GUIDE ® Close the door, referring to the ‘Door Closing Label’ if required. Ensuring the Frame is square, fasten the remaining Sheets in the order indicated below using six 10Gx16mm Hex-Head Self-Drilling Screws in each Sheet. Ensure the first 2190mm Sheet is approximately 240mm from the edge of the Side Door Flashing (Figure 10.11).
- Page 55 Position the Top Door Flashing over the Hinge Brackets. Fasten the Top Door Flashing to the Hinge Bracket using two 10Gx16mm Hex-Head Self-Drilling Screws at each end (Figure 10.12). Hinge Bracket Top Door Flashing 10Gx16mm Hex-Head Self-Drilling Screw FIGURE 10.12...
- Page 56 THE UMBRA AWNING SHED INSTALLATION GUIDE ® Position the Door Handle to the mid-point of the Door Assembly, and 30mm from the bottom of the door, ensuring the Door Handle is in-line with the 2575mm Frame and mark the mounting hole locations. Drill through the Frame using a 9mm drill bit.
- Page 57 Visit the Gas Technical Regulators Committee website at www.gtrc.gov.au for information pertaining to relevant standards and requirements for safe use of gas appliances. Alternatively visit your local Stratco store or consult a certified gas fitter for more Gas Detector - Natural Gas Installations 12v Cable information.
- Page 58 THE UMBRA AWNING SHED INSTALLATION GUIDE ® SYSTEM LAYOUT Gas Detector - Natural Gas Installations 12v Cable Door Switch Controller Door Switch 12v Cable 12v Cable 12v Cable Gas Line Gas Line Solenoid Valve Gas In Gas to Appliance 12v Cable...
- Page 59 OPTIONAL ADD-ON - HEAT SHIELD INSTALLATION The use of gas appliances in close proximity to the Wall Sheets may cause a build up of heat in excess of the maximum allowable heat exposure (100° C). It is recommended to install a Heat Shield to facilitate heat insulation in instances where a gas appliance will be used within the shed.
- Page 60 OPTIONAL ADD-ON - PEGBOARD INSTALLATION Pegboards can be installed anywhere along the back or side walls. Up to six Pegboards can be installed along the rear wall and one on each side. Align the base of the Pegboard with the Frame and push into place so that the tab has clipped into the Frame channel. Fasten through the Pegboard pilot holes and into the Frame with three Wafer-Head Screws (Figure 12.0).
-
Page 61: Maintenance
Stratco.com.au website for more information. « SCAN THIS QR CODE TO FIND A STRATCO NEAR YOU 1300 155 155 stratco.com.au All brands and logos/images accompanied by ® or ™ are trade marks of Stratco (Australia) Pty Limited. ® Copyright October 2024...
