Jensen VM8013HD - Screen MultiMedia Receiver Quick Start Manual

SAT BUS
Satellite Radio Tuner
(sold separately)
(Sold Separately)
Jensen VM8013HD Receiver Quick Start Guide
IMPORTANT: Incorrect wiring connections can damage the unit. Follow the wiring
instructions carefully, or have the installation handled by an experienced technician.
SAT R (Red)
SAT L (White)
Antenna
Battery
-
Connect the yellow wire to the battery
or 12 volt power source that is always
live. This wire MUST be connected
for the radio to work.
Yellow
Black
Chassis Ground
Connect the black wire to the factory ground wire. If a
factory ground wire is not provided, locate a clean,
unpainted metal part of the dash and secure the ground
wire with a "ring" terminal and a sheet metal screw.
iPod
White/Black
Gray/Black
White
Stripe
Stripe
Left Speaker Right Speaker
(Front)
Subwoofer Out
Parking/Active Low Level Input (Pink)
Camera In
Video Out 1
Video Out 2
Fuse (15A)
Camera/Active High Level Input (Green/White)
SWC (Steering Wheel Control)
(Requires PAC SWI-PS Interface Adapter)
Rear Line Out
Gray
Front Line Out
Black
FILTER
BOX
Power Antenna
Connect to power antenna or amplifier.
If not used, tape bare end of wire.
Blue
Accessory/Ignition
Connect to existing radio wire
or radio fuse.
Red
FRONT REAR
Purple/Black
Green/Black Green
Gray
Stripe
Left Speaker
(Front) (Rear)
Printed in China
(Blue)
(Yellow)
(Yellow)
(Yellow)
+
R (Red)
External Power Amplifier
L (White)
R (Red)
L (White)
Purple
Stripe
Need help?
For technical assistance,
call the Jensen customer
support line at
1-800-323-4815.
Right Speaker
(Rear)
IMPORTANT!
The pink parking
wire MUST be
connected to the
switched side of
the parking break
circuit (the part that
becomes grounded
when the brake is
applied).
