EN User manual
L 58547 SL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the L 58547 SL and is the answer not in the manual?

Questions and answers

Related Manuals for AEG L 58547 SL

Summary of Contents for AEG L 58547 SL

  • Page 1 EN User manual L 58547 SL...

  • Page 2: Table Of Contents

    13. INSTALLATION ............28 FOR PERFECT RESULTS Thank you for choosing this AEG product. We have created it to give you impeccable performance for many years, with innovative technologies that help make life simpler –...

  • Page 3: Safety Information

    ENGLISH 1. SAFETY INFORMATION Before the installation and use of the appliance, careful- ly read the supplied instructions. The manufacturer is not responsible if an incorrect installation and use cau- ses injuries and damages. Always keep the instructions with the appliance for future reference. 1.1 Children and vulnerable people safety WARNING! Risk of suffocation, injury or permanent disability.

  • Page 4: Safety Instructions

    • If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly quali- fied persons in order to avoid a hazard. • The operating water pressure (minimum and maxi- mum) must be between 0,5 bar (0,05 MPa) and 8 bar (0,8 MPa) •...

  • Page 5: Technical Information

    ENGLISH Water connection • Do not put a container to collect pos- sible water leakage under the appli- • Make sure not to cause damage to the ance. Contact the Service to ensure water hoses. which accessories can be used. •...

  • Page 6: Product Description

    Water supply pressure Minimum 0,5 bar (0,05 MPa) Maximum 8 bar (0,8 MPa) Cold water Water supply Maximum load Cotton 6.5 kg Spin speed Maximum 1400 rpm 1) Connect the water inlet hose to a water tap with a 3/4'' thread.

  • Page 7: Control Panel

    ENGLISH 4.1 Accessories Spanner To remove the transit bolts. Plastic caps To close the holes on the rear side of the cabinet after the removal of the transit bolts. Anti-flood inlet hose To prevent possible leakage Plastic hose guide To connect the drain hose on the edge of a sink.

  • Page 8: Programme Knob

    • After 5 minutes from the end of the 5.2 Programme knob washing programme. Refer to 'At the end of programme'. Turn this knob to set a programme. The related programme indicator comes on. 5.3 Display The display shows:...
  • Page 9 ENGLISH The detergent overdosing comes on at the end of the cy- cle when the appliance detects too much detergent. You cannot open the appliance door when the symbol is You can open the door only when the symbol goes off. If the programme is completed but the symbol stays •...
  • Page 10 10 www.aeg.com The extra rinse symbol comes on when this function is acti- vated. The value shows the total number of the rinses. The indicator bar is fully filled when you set to the maxi- mum number of rinses. The Stain symbol comes on when you activate the function.

  • Page 11: Temperature Button

    ENGLISH • To activate the function, press button 5.10 Temperature button and button at the same time Press button to change the default until the display shows the symbol temperature. When the display shows • To deactivate the function, press but- - -, the appliance does not heat the wa- and button at the same...
  • Page 12 12 www.aeg.com Programme Type of load Cycle de- Functions Temperature Max. weight of scription load Синтетика Synthetic or mixed Wash SPIN REDUC- 60° - Cold fabric items with Rinses TION normal soil. Short spin RINSE HOLD max. load 3 kg...
  • Page 13 ENGLISH Programme Type of load Cycle de- Functions Temperature Max. weight of scription load Антиаллергенная White cotton Wash SPIN REDUC- 60° items. Rinses TION This programme Long spin RINSE HOLD removes micro-or- PREWASH ganisms thanks to STAINS the washing by 60° EXTRA RINSE C and adds on rinse.
  • Page 14 14 www.aeg.com Programme Type of load Cycle de- Functions Temperature Max. weight of scription load Быстрая интесив Quick washing Wash SPIN REDUC- 60° - 40° programme, to be Rinses TION used for lightly Long spin RINSE HOLD soiled white/fast EXTRA RINSE coloured cottons and mixed fabrics.

  • Page 15: Consumption Values

    ENGLISH 7. CONSUMPTION VALUES At programme start the display shows the duration programme for the max- imum load capacity. During the washing phase the programme duration is automatically calcula- ted and can greatly be reduced if the laundry load is lower than the maxi- mum load capacity (e.g.

  • Page 16: Using The Appliance

    16 www.aeg.com removes all possible dirt from the drum and the tub. 9. USING THE APPLIANCE Open the water tap. 9.1 Loading the laundry Connect the mains plug to the mains Open the appliance door. socket. Put the laundry in the drum, one...
  • Page 17 ENGLISH The detergent compartment for the washing phase. If you use a liquid detergent, put it immediately before you start the programme. Liquid additives compartment (fabric conditioner, starch). Put the product in the compartment before you start the pro- gramme. This is the maximum level for the quantity of liquid additives.
  • Page 18 18 www.aeg.com To use liquid detergent, turn the flap down. With the flap in the position DOWN: – Do not use gelatinous or thick liquid detergents. – Do not put more liquid deter- gent than the limit showed in the flap.

  • Page 19: Open The Door

    ENGLISH • The acoustic signals operate. Press button , the appliance starts the countdown of the delay • In the display comes on. start. • The indicator of the Start/Pause but- When the countdown is completed, goes off. the programme starts automatically. •...

  • Page 20: Helpful Hints And Tips

    20 www.aeg.com 10. HELPFUL HINTS AND TIPS 10.1 The laundry load 10.3 Detergents and additives • Divide the laundry in: white, coloured, • Only use detergents and additives synthetics, delicates and wool. specially made for washing machines. • Obey the washing instructions that are •...

  • Page 21: Care And Cleaning

    ENGLISH Water hardness table Water hardness Level Type °dH °T.H. mmol/l Clarke soft 0-15 0-1.5 medium 8-14 16-25 1.6-2.5 10-16 hard 15-21 26-37 2.6-3.7 17-25 very hard > 21 > 37 >3.7 >25 11. CARE AND CLEANING WARNING! CAUTION! Do not use alcohol, solvents or chemical products.

  • Page 22: Detergent Dispenser

    22 www.aeg.com 11.6 Detergent dispenser To clean the dispenser: Press the lever. Pull the dispenser out. Remove the top part of the liquid additive compartment. Clean all the parts with water. Clean the dispenser recess with a brush. Put back the dispenser in the recess.
  • Page 23 ENGLISH To clean the drain pump: Open the drain pump door. Put a container below the recess of the drain pump to collect the water that flows out. Press the two levers and pull for- ward the drainage duct to let the water flow out.
  • Page 24 24 www.aeg.com Clean the filter under the water tap and put it back in the pump into the special guides. Make sure that you tighten correctly the filter to prevent leakages. Close the drain pump door. 11.8 The inlet hose filter and •...

  • Page 25: Emergency Drain

    ENGLISH Install again the inlet hose. Make sure that the couplings are tight to prevent leakages. Open the water tap. 45° 20° 11.9 Emergency drain 0 °C, remove the remaining water from the inlet hose and the drain pump. Because of a malfunction, the appliance Disconnect the mains plug from the cannot drain the water.
  • Page 26 26 www.aeg.com Problem Possible cause Possible solution The filters in the water Clean the filters. Refer to 'Care inlet hose is blocked . and cleaning'. The water tap is blocked Clean the water tap. or is furred with lime- scale.
  • Page 27 ENGLISH Problem Possible cause Possible solution You did not press but- Press button The delay start is set. To start immediately the pro- gramme, cancel the delay start. The Child Lock function Deactivate the Child Lock func- is activated. tion. There is water on Leakages from the cou- Make sure that the couplings...

  • Page 28: Installation

    28 www.aeg.com 13. INSTALLATION 13.1 Fixing plate kit If you install the appliance on a plinth, secure the appliance in the fixing plates. (4055171146) Follow the instructions supplied with the kit. Available from your authorized dealer. 13.2 Unpacking Use the gloves. Remove the external film.
  • Page 29 ENGLISH Open the door and remove all the items from the drum. Put one of the polystyrene packag- ing elements on the floor behind the appliance. Carefully put down the appliance with the rear side on it. Make sure not to damage the ho- ses.
  • Page 30 30 www.aeg.com Remove the three bolts. Use the key supplied with the appliance. Pull out the plastic spacers. Put the plastic caps in the holes. You can find these caps in the user manual bag. – We recommend that you keep...

  • Page 31: Positioning And Levelling

    ENGLISH 13.3 Positioning and levelling • Install the appliance on a flat hard floor. • Make sure that carpets do not stop the air circulation below the appliance. • Make sure that the appliance does not touch the wall or other units •...

  • Page 32: Water Drainage

    32 www.aeg.com • Connect the water inlet hose to the cold water tap with 3/4 thread. CAUTION! Make sure that there are no leaks from the couplings. Do not use an extension hose if the inlet hose is too short. Con- tact the service centre for the re- placement of the inlet hose.
  • Page 33 ENGLISH • On the edge of a sink. • Make sure that the plastic guide can- not move when the appliance drains. Attach the guide to the water tap or the wall. • To a stand pipe with vent-hole. Refer to the illustration. Directly into a drain pipe at a height of not less than 60 cm and not more than 100 cm.

  • Page 34: Environment Concerns

    34 www.aeg.com 14. ENVIRONMENT CONCERNS Recycle the materials with the appliances. Do not dispose symbol . Put the packaging in appliances marked with the symbol applicable containers to recycle it. with the household waste. Return the Help protect the environment and...
  • Page 35 ENGLISH...
  • Page 36 www.aeg.com/shop...
