Handler 26105SSWCG Manual

Gas boilout – washout - curing unit
Hide thumbs

Advertisement

Table of Contents

Shown as Model 26105SSWCG WGRAY
!
For Your Safety:
IMPORTANT
Thank you for purchasing this Handler product! Please read
these Instructions prior to installation and operation of this unit.
THIS UNIT MUST BE INSTALLED BY A LICENSED ELECTRICIAN.
FAILURE TO FOLLOW THESE INSTRUCTIONS WILL VOID YOUR
WARRANTY.
26105SSWCG
GAS BOILOUT – WASHOUT - CURING UNIT
MANUAL
CAUTION!
NEVER INSTALL THIS UNIT IN A WOODEN CABINET OR NEAR
COMBUSTIBLES.
All service work (plumbing and electrical) must be done by
licensed professionals in compliance with local codes.
Always wear eye protection and use caution with hot water.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 26105SSWCG and is the answer not in the manual?

Questions and answers

Summary of Contents for Handler 26105SSWCG

  • Page 1 Shown as Model 26105SSWCG WGRAY For Your Safety: IMPORTANT CAUTION! Thank you for purchasing this Handler product! Please read NEVER INSTALL THIS UNIT IN A WOODEN CABINET OR NEAR these Instructions prior to installation and operation of this unit. COMBUSTIBLES.

  • Page 2: Installation

    2. Shut Off the Gas Supply (If Safe to Do So) using the unit again to ensure there are no further leaks or risks. • The main gas valve for the 26105SSWCG is located underneath the tanks inside 7. Preventive Steps After Installation: the cabinet in the rear of the unit and is generally marked with a yellow or red handle.
  • Page 3 You must take precautions not to damage the thermocouple. note how long it takes for the water to reach a rolling boil. NOTE: The 26105SSWCG is meant to achieve a rolling boil only. It is not meant to achieve a vigorous boil.
  • Page 4 Parts sourced from P26102-06 Pilot Light With Thermocouple elsewhere will void any warranty or may P26105-04 Stainless-Steel Washout Tray not work. Authentic Handler parts can P26105-04S Stainless-Steel Mesh Filter be ordered from www.handlermfg.com. P26105-06T Large Boil Out Tank Cover, Stainless-Steel...

  • Page 5: Troubleshooting

    TROUBLESHOOTING Problem Possible Cause Possible Solution Water is not heating up Thermocouple connection is broken Check the connection of the thermocouple wiring from the control to the thermocouple. Is it intact? If it is broken, you must order a new part and have it installed.
  • Page 6 Color Table Color Table Power Switch Switch Box BK = Black WH = White GN = Green Junction Box YW = Yellow Gas Control #1 RD = Red Transformer Gas Control #2 3/8 Green Field BX Cable Circulator Pump GND Power Cord Set 16/3 Grey X 7' SJT 110V Inside Motor Connections Ground Terminal Wire Connectors (White) CAPACITOR Wiring Diagram (Main Circuit) P/N 26105 DWG No.: 30B01502 Gas Boil-Out Rev B Date 5-30-24 MANUFACTURING, LLC 159 GRASSY PLAIN STREET BETHEL, CT 06801, USA A SUBSIDIARY OF BLACKSTONE INDUSTRIES, LLC...

  • Page 7: Pump Maintenance

    PUMP MAINTENANCE CAUTION – MAKE SURE UNIT IS DISCONNECTED FROM ALL POWER SOURCES PRIOR TO THIS OR ANY MAINTENANCE TO AN ELECTRICAL PRODUCT. MAINTENANCE SHOULD BE PERFORMED BY A LICENSED PLUMBER OR ELECTRICIAN. DRAIN TANK PRIOR TO TAKING THE STEPS BELOW. 1.

  • Page 8: Instruction Sheet

    Instruction Sheet 102-054 “00” Cartridge Circulators SUPERSEDES: May 1, 2010 EFFECTIVE: July 1, 2015 Plant I.D. 001-934 ApplICATION: 1. Maximum operating pressure is 125 psi (862 kPa). 2. Maximum water temperature not to exceed nameplate rating. 3. Cast iron circulators are to be used for closed loop systems. Bronze or stainless steel circulators are to be used for open loop, fresh water, or potable water systems.

  • Page 9: Limited Warranty Statement

    WArNINg: To avoid electrical shock, disconnect the power supply to the circulator and the main electrical unit. replACINg mOTOr Assembly: 1. Disconnect the electrical supply. 2. Reduce system pressure to 0 psi and allow system to return to room temperature. Isolate the circulator by closing the service valves or draining the system.

  • Page 10: Specifications

    GS SERIES THERMOSTATS 4290 SERIES The Robertshaw GS thermostat is a snap-acting hydraulic ® thermostat and is used to provide temperature control by interrupting gas flow to the burner. The GS gas thermostat is available for a wide variety of applications including small ovens, griddles, brooders, warming cabinets and fryers.
  • Page 11 GS SERIES 4290 SERIES THERMOSTATS PRODUCT DIMENSIONS Dimensions are inches and [millimeters]. GS Front View GS Right View IN 1/2 PSI Available Bulb Diameters inches 0.187* 0.250 0.312 0.375 [millimeters] 4,8 * Most common diameter For Technical Service www.robertshaw.com Customer Service Telephone 1.800.304.6563 Telephone 1.800.445.8299 www.Uni-Line.com Robertshaw®...
  • Page 24 Handler Manufacturing and the customer after diagnosis and thorough technical consult with Handler Manufacturing. Any unauthorized repair by Handler Manufacturing or any use of non- Handler factory parts may void the warranty. Handler Manufacturing will not pay any shipping or transportation charges.
