Summary of Contents for PULSEEIGHT OneIP
- Page 1 USER MANUAL V1.0...
-
Page 2: Table Of Contents
Warranty Terms & Conditions 14 Please note this manual is a setup guide for the physical unit, for a full guide to software, including the web interface please see the Software Guide which can be found at supportpulse-eightcom under the OneIP product page... -
Page 3: Introduction
Plug in anywhere, see it anywhere, manage it centrally All of the current OneIP family of products can be powered via PoE+ from the network switch, or by a local DC power supply (available separately) FEATURES •... -
Page 4: Specifications
25cm x 155cm x 3cm / 98 x 61 x 11 inches Weight 06 kg * 100m max distance between the switch and OneIP unit when using a single ethernet cable You can extend over much longer distances with additional network hardware... -
Page 5: Safety Precautions
• Allow sufficient space for air to circulate around the unit. • Use a compatible PoE+ source or the OneIP power supply (available separately) If you require additional power supplies, please contact your Pulse-Eight representative • Never push any objects into this product through any openings or empty slots as you may damage parts inside and/or cause an electrical shock •... -
Page 6: Panel Descriptions
Eight IR Emitter These ports can also be connected directly to a suitable control system for other use cases In these scenarios, use a suitable IR coupling cable Device ID LED: This LED can be used to help identify OneIP devices by pressing the ‘Locate Device’ button within the web interface... -
Page 7: Cabling
The Ethernet ports on the Pulse-Eight OneIP product are designed to use standard Category (Cat) cables The minimum cable used on a OneIP system is Cat5e, but it is recommended to use a higher tier cable such as Cat6 or Cat6A where possible because they have stricter twisted pair and shielding requirements that can reduce data... -
Page 8: Installation
4 Installing OneIP Unit In A Remote Zone 2 OneIP devices can be mounted on the wall or placed flat on a shelf. OneIP devices have built-in wings for easy wall mounting 3 It is important never to block or limit the air flow to both the fan vent on top of the unit or the vents on the sides... - Page 9 Internet Network Switch 7 Acting as a Receiver, you will need to connect an HDMI sink to this device Connect an HDMI cable from the HDMI output port of the OneIP to your sink device (eg TV) Internet Network Switch...
- Page 10 IR bud over the IR window of the source device (ie Blu-Ray player) 9 If required, connect a compatible IR receiver to the ‘IR RX’ port (black) on the OneIP device and place the IR bud in line of sight of any remote controls to be used...
- Page 11 15. Check the LEDs on the OneIP units. Be aware that other units may have taken a longer time to initialize. If System and Network LEDs are not solid green, please refer to the full user manual for details...
-
Page 12: Wiring Guidelines
WIRING CONCEPT 1080P INTERNET NETWORK SWITCH LEGEND Infrared PoE+ Ethernet Digital Audio Ethernet Speaker HDMI... -
Page 13: Troubleshooting
6 Turn on all sources IR Not Functioning 1 Make sure to only use the compatible OneIP IR emitter/receivers 2. Check and see if the LED beside the IR port is lighting up. It signifies whether the IR connection is working. -
Page 14: Warranty Terms & Conditions
WARRANTY TERMS & CONDITIONS IMPORTANT INFORMATION ABOUT YOUR RIGHTS AND OBLIGATIONS, AS WELL AS LIMITATIONS AND EXCLUSIONS THAT MAY APPLY TO YOU. YOUR RIGHTS AND THIS LIMITED WARRANTY This Limited Warranty gives you specific legal rights. You may also have other legal rights that vary by country, state, province, or jurisdiction. The disclaimers, exclusions, and limitations of liability under this Limited Warranty will not apply to the extent prohibited by applicable law For a full description of your legal rights, you should refer to the laws applicable in your jurisdiction and you may wish to contact a relevant consumer advisory service... - Page 15 5. DISCLAIMER OF WARRANTIES Except as stated previously in this limited warranty, and to the maximum extent permitted by applicable law, Pulse-Eight disclaims all express, implied, and statutory warranties and conditions with respect to the product, including the implied warranties of merchantability, fitness for a particular purpose.
