Summary of Contents for HOLOWITS HWT-NVR800
- Page 1 HWT-NVR800 Quick Start 192.168.0.100 Default IP Address Issue: 01 BOM: 31500JDT Copyright @HOLOWITS TECHNOLOGIES PTE. LTD.2023. All rights reserved.
- Page 2 1. Included Items and Certificate Item Item HWT-NVR800 device Mouse Power cable Network cable Quick Start Hard disk screws Note: The number of screws varies depending on the HWT-NVR800 model. 2. Hazardous Substance Statement Hazardous Substances Component Hexavalent Polybrominated Polybrominated Diethylhexyl Benzyl Butyl...
-
Page 3: Front View And Rear View
3. Front View and Rear View Front view Power status indicator Hard disk status indicator USB port Rear view HWT-NVR800-A01（1drive bays） HDMI port Power switch VGA port USB port Network port Power port Audio output port Reset switch HW-NVR800-A01-4P（1drive bays）... - Page 4 HWT-NVR800-A02-8P（2 drive bays） Audio input port Power switch HDMI port VGA port USB 3.0 port USB 2.0 port PoE port Audio output port Reset switch Power port Network port HWT-NVR800-A02-16P（2 drive bays） Audio input port Power switch HDMI port VGA port USB 3.0 port...
-
Page 5: Hard Disk Installation
Use HWT-NVR800-dedicated SATA disks as recommended by the vendor. Before installing the disks, ensure that the power supply is disconnected and have a Phillips screwdriver and hard disk screws (that can be found in the HWT-NVR800 packing box) ready. Bottom-Mounted Installation (for the HWT-NVR800 with One or Two Disk Trays) Bottom-mounted installation is applicable to the HWT-NVR800 with hard disks that need securing to the chassis bottom. - Page 6 Close the chassis cover and secure it using the screws removed in Step 1. Installing Hard Disks on the HWT-NVR800 with Two Disk Trays Use a PH1 screwdriver to remove the left, right, and rear screws of the chassis cover, and take off the chassis cover.
- Page 7 Close the chassis cover and secure it using the screws removed in Step 1. Bracket-Mounted Installation (for the HWT-NVR800 with Four Disk Trays) Use a PH1 screwdriver to remove the rear screws of the chassis cover, and take off the chassis cover.
- Page 8 Loosen the screws on the hard disk bracket. Secure one side of the hard disks with screws. Secure the other side of the hard disks with screws. Secure the bracket. Close the chassis cover and secure it using the screws removed in Step 1.
-
Page 9: Device Power-On
HWT-NVR800 has been connected to the Internet. Connect to cameras. (Only for the PoE model) Connect cameras to the PoE port of the HWT-NVR800 or the switch connected to the HWT-NVR800. The HWT-NVR800 automatically discovers the cameras. -
Page 10: Logging In To The App
Download and install the control as prompted upon the first login. Close all browser windows during the control installation. 9. Logging In to the App Before logging in to the app, ensure that the HWT-NVR800 is connected to the Internet. Choose Settings >... -
Page 11: Warranty Card
Unless otherwise stated specifically in writing by HOLOWITS TECHNOLOGIES PTE. LTD. , the following applies: You are entitled to free service of at least 36 months for a device purchased from HOLOWITS TECHNOLOGIES PTE. LTD. The specific warranty duration is subject to the sales contract.
