- Page 1 EN User Manual | Tumble Dryer TR786T32B aeg.com\register...
-
Page 2: Table Of Contents
FOR PERFECT RESULTS Thank you for choosing this AEG product. We have created it to give you impeccable performance for many years, with innovative technologies that help make life simpler – features you might not find on ordinary appliances. Please spend a few minutes reading to get the very best from it. -
Page 3: Safety Information
SAFETY INFORMATION Before beginning the installation and use of this appliance, carefully read the supplied instructions. The manufacturer is not responsible for any injuries or damage that are the result of incorrect installation or usage. Always keep the instructions in a safe and accessible location for future reference. -
Page 4: General Safety
• Keep children and pets away from the appliance when the door is open. • If the appliance has a child safety device, it should be activated. • Children shall not carry out cleaning and user maintenance of the appliance without supervision. 1.2 General Safety •... - Page 5 • Connect the mains plug to the mains socket only at the end of the installation process. Make sure that the mains plug is accessible after installation. • Ensure good air ventilation in the room where the appliance is installed to avoid the backflow of unwanted gases into the room from appliances burning gas or other fuels, including open fires.
-
Page 6: Safety Instructions
• Fabric softeners, or similar products, should only be used as specified by the product manufacturer’s instructions. • Remove all objects from items that could be a source of fire ignition such as lighters or matches. • WARNING: Never stop a tumble dryer before the end of the drying cycle unless all items are quickly removed and spread out so that the heat is dissipated. - Page 7 2.5 Compressor Warning: Risk of fire / Flammable WARNING! materials. The appliance contains flammable gas, propane (R290), a gas with a high level Risk of damage to the appliance. of environmental compatibility. Keep fire and ignition sources away from the appliance. Be •...
-
Page 8: Product Description
3. PRODUCT DESCRIPTION Water container Airflow slots Control panel Condenser lid Appliance door Condenser cover Filter Adjustable feet Rating plate For ease of loading laundry or ease of installation the door is reversible (see the separate leaflet). The rating plate reports: model name Mod. -
Page 9: Control Panel
4. CONTROL PANEL auto-off function Program dial On/Off button with Display Programs Start/Pause button Options 4.1 Display Symbol on the display Symbol description cycle time indication maximum load delay start selection (30min-20h) ENGLISH... -
Page 10: Program
Symbol on the display Symbol description + Anti Crease option on Silent option on buzzer off child lock on laundry dryness: iron dry, cupboard dry, extra dry Time Dry option on drain the water container indicator: clean the filter indicator: check the condenser indicator: drying phase... - Page 11 Load 1) Properties / Fabric mark 2) Program Preserves the shape of delicate machine and hand-washable silk clothes, minimizing 0,5 kg creases by using gentle warm air and soft Silk movements. Dries up to three bed linen sets at once. Minimises twists and tangles of large items Bedlinen XL 4,5 kg...
-
Page 12: Consumption Data
Options Dryness + Anti Programmes 1) Silent Time Dry Level Crease Outdoor Hygiene Together with the programme you can set 1 or more options. Set by default See chapter OPTIONS: Time Dry on Wool programme 5.2 Consumption data Stated values are obtained in laboratory conditions with relevant standards. Different pa‐ rameters can change the data, for example: the quantity of laundry, the type of laundry and the ambient conditions. -
Page 13: Options
6. OPTIONS 6.1 Dryness Level TIME DRYING RECOMMENDATION This option helps to achieve requested laundry dry‐ full drying of the small laundry loads up > 40 min ness. You can select the level of dryness: to 4 kg, well spun (>1200 rpm). 6.5 Time Dry on Wool program ready to iron - iron dry level Option applicable to Wool program to adjust... -
Page 14: Before First Use
7. BEFORE FIRST USE Working compressor. Rear drum locks are removed automatically when dryer is activated for Brrrr the first time. Possible to hear some noise. To unlock the rear drum locks: 1. Switch on the appliance. 2. Set any programme. 3. -
Page 15: Daily Use
8. DAILY USE 8.1 Preparing the laundry • Always set the programme suitable for the type of laundry. • Do not put light and dark colours together. • Use suitable programme for cottons, Very often the clothes after washing jersey and knitwear to reduce shrinkage. cycle are kneaded and tangled •... -
Page 16: Turning On The Appliance
8.3 Turning on the appliance Real drying time will depend on type of the load (quantity and composition), the room temperature and the humidity of your laundry after spin drying phase. 8.6 Options Together with the programme you can set 1 or more special options. -
Page 17: Hints And Tips
3. Touch and hold down + Anti Crease If the drying cycle is finished, the symbol button by around 3 seconds. appears on the display. If the Buzzer option is The symbol appears on the display. activated, the acoustic signal sounds 4. -
Page 18: Adjustment Of Default Dryness Level
textile fibres (simple coffee filter is 5. To memorise the setting touch and hold suitable). down the Dryness Level and + Anti • Always keep the airflow slots at the bottom Crease buttons at the same time for of the appliance clear. approximately 2 seconds. -
Page 19: Emptying The Water Container
1. Open the door. Pull the filter up. inside the filter socket. 2. Push the hook to open the filter. 10.2 Emptying the water container Empty the condensed water container after each drying cycle. If the condensed water container is full, the programme stops automatically. -
Page 20: Cleaning The Condenser
10.3 Cleaning the condenser 4. Lower the condenser lid. Heat exchanger flashes on If the symbol the display, inspect the condenser and its compartment. If it is dirty, clean it. Do the check not less than once a 6 months. WARNING! Do not touch the metal surface with bare hands. -
Page 21: Troubleshooting
2. Clean the surfaces of the humidity sensor CAUTION! wiping off the metal surface several times. Do not use abrasive materials or steel wool to clean the drum. 10.6 Cleaning the control panel and housing Use a standard neutral soap detergent to clean the control panel and housing. - Page 22 Error code Possible cause Remedy Internal fail. No communication between The programme was not finished properly electronic elements of the appliance. or the appliance stoped too early. Switch E90 or E91 the appliance off and on again. If the error code appears again, contact the Authorised Service Centre.
-
Page 23: Technical Data
Problem Possible cause Remedy It is not possible to After a cycle starts it is not possible to Turn the tumble dryer off and on. Change change the program change the program or option. the program or option as required. or option. - Page 24 Max. depth with the appliance door open 1108 mm Max. width with the appliance door open 958 mm Adjustable height 850 mm (+ 15 mm - feet regulation) Drum volume 118 l Maximum load volume 8,0 kg Voltage 230 V Frequency 50 Hz Sound power level...
-
Page 25: Product Information Sheet In Reference To E.u. Regulation 1369/2017
13. PRODUCT INFORMATION SHEET IN REFERENCE TO E.U. REGULATION 1369/2017 Product Information Sheet Trade Mark Model TR786T32B PNC916099698 Rated capacity in kg Air vented or condenser tumble dryer Condenser Energy efficiency class A+++ Energy consumption in kWh per year, based on 160 drying cycles of the standard... -
Page 26: Environmental Concerns
14. ENVIRONMENTAL CONCERNS appliances marked with the symbol with Recycle materials with the symbol . Put the the household waste. Return the product to packaging in relevant containers to recycle it. your local recycling facility or contact your Help protect the environment and human municipal office. - Page 28 136202760-A-282023...
