Summary of Contents for AquaCal AutoPilot AQUACLEAN AC1000 PRO
- Page 1 CLEAN Cordless Robotic Pool Cleaner Owner’s Manual AC1000 PRO Read through the entire manual before running your new AquaClean cordless robotic pool cleaner, and keep this manual handy for future reference.
- Page 2 We are not responsible for any loss or injury caused by improper use. If you encounter a problem with your AquaClean product, please contact our customer ® service for assistance. AquaCal AutoPilot, Inc. Customer Service: Email: customersupport@aquacal.com Web: www.AquaCal.com...
-
Page 3: Table Of Contents
CLEAN CONTENTS Important Precautions ..............01 Product Overview ................. 03 Charging Instructions ..............04 Setting Up ..................05 Running the Device ..............06 Cleaning the Filter ................ 07 Device Specifications ..............08 Device Maintenance ..............09 FAQ & Troubleshooting ..............09 Troubleshooting Chart .............. -
Page 4: Important Precautions
CLEAN IMPORTANT PRECAUTIONS READ AND FOLLOW ALL DIRECTIONS • Follow all state, local, and National Electrical Code(s) (provincial and Canadian Electrical Code(s) if applicable) unless local guidelines supersede. • For personal safety, and to avoid damage to equipment, follow all safety instructions displayed on the equipment and within this manual. - Page 5 CLEAN CAUTION - Failure to heed the following may result in equipment damage. • Use the accessories recommended or sold by the manufacturer only. • Dry the charging port after removing the cleaner from out of the water. Ensure the cleaner is switched off (the indicator should be off) before charging. •...
-
Page 6: Product Overview
CLEAN Product External Overview HANDLE PUMP SCRUBBING BRUSH Use to remove and transport Vacuums debris and pumps Use to loosen dirt and debris, the device easily. out water. then roll them into the device. LED INDICATOR ON/OFF BUTTON CHARGING PORT Different light colors to Turn on/turn off the device. -
Page 7: Charging Instructions
CLEAN Charge your new AquaClean Robotic Pool Cleaner The device has a lithium-ion rechargeable battery. Charge the battery before first use and when the battery is low. Connect your device to a power outlet using the included cable and adaptor. CHARGING IN PROGRESS BATTERY IS FULL •... -
Page 8: Setting Up
CLEAN Set up your new AquaClean Robotic Pool Cleaner Turn on the device by pressing the on/off button. The LED indicator on the front will display a solid blue when the device is on. Below is the LED indicator guide to help you understand the device’s different status. -
Page 9: Running The Device
CLEAN Run your new AquaClean Cordless Robotic Pool Cleaner Turn on the device, hold the handle Let it sink down to the floor to empty of the cleaner and place it into the trapped air inside. pool vertically. NOTE: To achieve an optimal cleaning performance, you should ensure the water depth of the pool is at least 19.5 in (50 cm) high from the top of the device. -
Page 10: Cleaning The Filter
CLEAN Do a Filter Cleaning CAUTION - Failure to heed the following may result in equipment damage. Do not attempt to clean the filter while the unit is in the pool. Hold the filter cover handle, press and open it. NOTE: Ensure the device is powered off before opening the top cover. -
Page 11: Device Specifications
CLEAN DEVICE SPECIFICATIONS AquaClean AC1000 Pro Model ® 10.8V Rated Working Voltage Power Max. 110min for one cycle Run Time 100-240V, 50-60Hz Charger Input Charger Output 9200mAh Battery Capacity 3-4 hours Charging Time Up to 1300 ft / 120 m Pool Size approx. -
Page 12: Device Maintenance
CLEAN HOW TO MAINTAIN YOUR DEVICE To maintain optimal performance of your cleaner, follow these steps for storage: Always ensure the device is powered off before performing maintenance. Thoroughly dry the cleaner and filter basket. Fully charge the battery. Store the cleaner in a cool, well-ventilated area away from direct sunlight, heat sources, and frost. -
Page 13: Troubleshooting Chart
CLEAN Issue Details Possible Causes Suggested Solution Device does A solid red Impeller is stuck Check the impeller and not work light remove any foreign objects A flashing Motor protection Restart red light A flashing The device is out of the Restart and place it into the red light water or the pool water... -
Page 14: Floating Block Installation
CLEAN Floating Block Installation Attention: The following diagrams are limited to use of the floating blocks when the robot cannot climb the pool walls. If your cleaner is performing well, please bypass these instructions. Open the filter Remove the protective cover and remove film from the back of the filter basket. - Page 15 Contact AquaCal AutoPilot ® ® customer service about your warranty at +1 727.823.5642 CLEAN AquaCal AutoPilot, Inc • 2737 24th Street North, St. Petersburg, FL 33713, USA • +1 727.823.5642...
- Page 16 CLEAN...
