LGE Internal Use Only

Service Manual

Notebook

15U530 Series

REV. 12

reproduced, modified, distributed, displayed, stored in a retrieval

system, or transmitted in any form by any Means (electronic,

2014. 08. 18

photocopying, recording or otherwise), without the Prior written

Retention period until : 2018-01

authorization of LG Electronics.

Table of Contents

Need help?

Do you have a question about the 15U530 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for LG 15U530 Series

Page 1 Notebook 15U530 Series REV. 12 Copyrightⓒ 2014 LG Electronics, Digital Mate Co., Ltd . All rights reserved. No part of this manual may be used, copied, reproduced, modified, distributed, displayed, stored in a retrieval system, or transmitted in any form by any Means (electronic, 2014.
Page 2: Table Of Contents
Recovering from Boot Failure Backup and Restore Security Platform Data Symptom-to-part index Problems regarding System Shutdown and Booting Power system checkout LCD-related symptoms Indeterminate problems Removing and replacing a part (FRU) Part lists Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 3: Important Service Information
The drive startup sequence in the computer you are servicing may have been changed. Be extremely careful during write operations such as copying, saving, or formatting. If you select an incorrect drive, data or programs can be overwritten. Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 4: Safety Notices
Though the main batteries have low voltage, a shorted or grounded battery can produce enough current to burn personnel or combustible materials. WARNING Before removing any part (FRU), turn off the computer, unplug all power cords from electrical outlets, remove the battery pack, and then disconnect any interconnecting cables. Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 5: Safety Information
3 Removing or installing main units Before you start to work on the machine, unplug the power cord. If you cannot unplug it, ask the customer to power-off the wall box that supplies power Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 6: Safety Inspection Guide
This guide addresses only those items. You should use good judgment to identify potential safety hazards due to attachment of non-LG features or options not covered by this inspection guide. If any unsafe conditions are present, you must determine how serious the apparent hazard could be and whether you can continue without first correcting the problem.
Page 7: Handling Devices That Are Sensitive To Electrostatic Discharge
4 Check the power cord for : 5 Check for any obvious non-LG alterations. Use good judgment as to the safety of any non-LG alterations. 6 Check inside the unit for any obvious unsafe conditions, such as metal filings, contamination, water or other liquids, or signs of fire or smoke damage.
Page 8: Laser Compliance Statement
Emits visible and invisible laser radiation when open. Do not stare into the beam , do not view directly with optical instruments, and avoid direct exposure to the bean. Backup (Standby) RTC battery safety information When replacing or disposing of the backup (standby) RTC battery, note the following : Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 9: Read This First
Before you go to the checkout guide, be sure to read this section. IMPORTANT NOTE Only trained personnel certified by LG should service the computer. Read the entire FRU removal and replacement page before replacing any FRU. Use new nylon-coated screws when you replace FRUs.
Page 10: Name Of Each Part
The fast charge USB port complies with USB specifications. This function may not work properly in products that do not comply with the USB specifications. The 4-pole ear microphone port supports US type 4-pole standards and the European 4-pole ear microphone may not work properly. Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 12: System Information
Wireless LAN Intel®7260HMW Intel®7260HMWBN Manufacturers and installers cannot provide services related to human safety as this wireless device may cause radio interference. Web Camera 1.3 M / HD Webcam Gigabit Ethernet Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 13: Product Weight
System information Product Weight Approx. 1.95 kg (a battery and ODD included) The weight may differ according to the model. Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 15: Using Hot Keys
Fn + F2 hotkey only works after LG Easy Stater is installed through LG Update Center. To enable OSD3 Guide message to appear, update the OSD from [LG Update Center]. Then run [LG Control Center] > [System Settings] > [On Screen Display] tile.
Page 16: Operation Status Lamps
The lamp is turned on when the HDD is running. Do not turn off the power forcibly while the hard disk drive lamp is on or blinking. Otherwise, the disk or its data may get damaged. Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 17: Bios Flash
To boot into DOS, you must disable “Secure Boot option”. To boot from a USB device, use [F2] key to move the USB device to the top of the list in Boot menu after entering BIOS Setup, or press [F10] key to display Boot menu while the LG logo is being displayed, and the select a device you want to use.
Page 18 In Security, in “Secure Boot Configuration," Secure Boot values are right. (For details, refer to [Check Secure Boot].) It selects the :” Load Setup Defaults” on the “Exit” menu or [F9] Key and it summons a BIOS settings at initial value. Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 19: Check Secure Boot
Upon the system rebooting, enter BIOS Setup again and check if Secure Boot has the values in the following figure. (Check UEFI Secure Boot, Protected Signatures, CertNames and Secure Boot Option.) Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 20: Bios Setup
Downgrading from Windows 8 to Windows 7 (SecureBoot Disable) In Windows 8, select “Restart”. Once the system restarts and “LG” Logo appears, press [F2] key. The booting speed is faster than the existing models. You’d better press it as soon as the system restarts.
Page 21 This shows the size of L2 Cache RAM for the CPU. Total Memory This shows size of system memory. System Date / Time Drag the Date or Time button to change the system date/time. Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 22: Advanced Menu
This swaps Fn and with Ctrl keys. USB Charger Support It is available to charge USB Device(Phone, etc.) with USB Charge Port though system is on “sleep mode/ hibernate / Shutdown" in case of Enable. Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 23: Security Menu
Reset the Protected Signatures option to Enable (User Mode) if it is Disabeld (Setup Mode) Change to Customization Set the Protected Signatures option to Disabled (Setup Mode). Once you do so, the Secure Boot option stays Disabled until you click the Reset to Default option. Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 25 This changes the parameters in the Setup menu to the factory default settings. When it is selected or [F9] key is pressed, the confirmation message appears. Click [Yes] to change the settings. Discard Changes This returns to the factory default settings for each parameter in the Setup menu. Save Changes Save change value. Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 26: Using Lg Recovery Center
System information Using LG Recovery Center If the system has an error, you can use Windows LG Recovery Center to recover or restore the system to its initial purchase state. CAUTION If you have deleted the restoration data in the protected area of the hard disk, or have arbitrarily installed another operating system, the restore function may not work.
Page 27 When the following screen appears, select the USB flash drive and click [Next]. CAUTION This process deletes all the data on the storage device designated as a recovery drive. Make sure to back up its data in advance. Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 28 Select [Delet the recovery patition] while creating a recovery drive to remove the recovery partition in the PC. Once the recovery partition is removed, you cannot use the recovery function of the PC. You can only recover the system using the recovery media. Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 29: Recovering From Boot Failure
System information Recovering from Boot Failure If booting is impossible due to a serious error with the system, you can recover the system through LG Recovery Center RE. CAUTION If you have deleted the restoration data in the protected area of the hard disk, or have arbitrarily installed another operating system, the restore function may not work.
Page 30 System information When the [Choose your keyboard layout] screen appears, select [US]. When the [Choose an option] screen appears, select [Troubleshoot]. Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 31 System information Select [LG Recovery Center RE] in the [Troubleshoot] screen. Select the operating system to restore in the [Recovery Tools] screen. When the following screen appears, select the [I Agree] button and then click the Next button. For recovery, the power adapter must be connected. Connect the system power and then recover the system.
Page 32 If it is impossible to recover by using [F11], you can recover the system through a recovery drive. To recover by using a recovery drive, you must have the recovery drive made through LG Recovery Center [Create Recovery Drive]. Connect the recovery drive to the USB port of the computer.
Page 33: Backup And Restore Security Platform Data
PSD configuration settings are included in both automatically written Backup Archives and manually written Backup Archives. y PSD backup file (e.g. SpPSDBackup.fsb): A backup copy of the PSD image file may be created during a Security Platform User's manual backup. Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 34 Please note that automatic backups are only executed if your PC is not shut down at the scheduled time.Please note that the user account chosen for the scheduled backup must be member of the group “Administrators” or “Backup Operators”. Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 35 This button is disabled, if the Infineon Security Platform is disabled or not yet set up. Click here to create a backup authentication device. This feature is only available, if Enhanced Authentication is enabled. Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 36: Symptom-To-Part Index
Check that power is supplied when you power on the computer. Power off the computer. Disconnect the AC adapter and install the charged battery pack. Check that the battery pack supplies power when you power on the computer. Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 37 If the charge indicator still does not turn on, replace the system board. Then reinstall the battery pack. NOTE Do not charge battery pack, when its temperature is below 0 or above 75. Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 38: Lcd-Related Symptoms
Battery is an expendable supplier, so its capacity and used time can be reduced by using the computer. LCD-related symptoms NOTE Before removing or disassembling LCD, power off the computer, unplug all power cords from electrical Outlets. Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 39: Indeterminate Problems
If the problem remains, replace the following FRUs one at a time. (do not replace a non-defective FRU) a. LCD Assembly (Check external monitor whether the same problem recurs or not). b. Keyboard. c. Keydeck (TouchPad and Scroll Button Assembly). d. System board. Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 40 As for the screw, every Torque 3 ± 0.2Kgfcm(0.196Nm) * The system hinge part apply to 2.5 ㎏fcm. For further information on Removing and Replacing a Part(FRU), refer to Explore view Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 43 Removing and replacing a part (FRU) 1020 Memory Cover Remove the screw. FRU No. Specification 1SZZBA4017F M2.0 x L3.5 Remove the Memory cover. Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 44 Removing and replacing a part (FRU) 1030 Bottom Case NOTE Remove the following parts in order before replacing this part. a. ODD(1010) Remove the 2 rubbers. Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 45 Removing and replacing a part (FRU) Remove the 13 screws. FRU No. Specification 1SZZBA4039D M2.5 X L8.0 13EA Remove the hooks using ZIC. Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 47 Remove the following parts in order before replacing this part. a. ODD(1010), b. Memory Cover(1020), c. Bottom Case(1030) Disconnect the cable after removing the 5 screws. Cable FRU No. Specification 1SZZBA4023A M2.0 X L3.5 Remove the battery. Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 48 Remove the following parts in order before replacing this part. a. ODD(1010), b. Memory Cover(1020), c. Bottom Case(1030), d. Battery(1040) Disconnect the cable after removing the 4 screws. Cable FRU No. Specification 1SZZBA4023A M2.0 X L3.5 Remove the HDD. Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 49 Removing and replacing a part (FRU) Disconnect the HDD cable after removing the 4 screws. Cable FRU No. Specification 1SZZBA4011K M3.0 X L3.0 Remove the HDD bracket. Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 50: 1060 Sub Board
Removing and replacing a part (FRU) 1060 Sub Board NOTE Remove the following parts in order before replacing this part. a. ODD(1010), b. Memory Cover(1020), c. Bottom Case(1030), d. Battery(1040) Remove the Sub board cable. Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 52 NOTE Remove the following parts in order before replacing this part. a. ODD(1010), b. Memory Cover(1020), c. Bottom Case(1030), d. Battery(1040) Disconnect the hooks. HOOK HOOK HOOK HOOK Remove the Memorys. Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 53 Removing and replacing a part (FRU) 1080 WLAN NOTE Remove the following parts in order before replacing this part. a. ODD(1010), b. Memory Cover(1020), c. Bottom Case(1030), d. Battery(1040) Remove the Gasket. Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 54 Disconnect the screw after removing the 2 antenna cables. CAUTION Do not intersect both sides Antenna Cable. MAIN FRU No. Specification 1SZZBA4019J Screw, M2.0 X L3.0 X D4.0 Silver (H:1t) Remove the WLAN. Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 55 Remove the following parts in order before replacing this part. a. ODD(1010), b. Memory Cover(1020), c. Bottom Case(1030), d. Battery(1040) Remove the screw. FRU No. Specification 1SZZBA4023A M2.0 X L3.5 Remove the SDD. Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 56: 1100 Fan Assembly
Remove the following parts in order before replacing this part. a. ODD(1010), b. Memory Cover(1020), c. Bottom Case(1030), d. Battery(1040) Disconnect the cable after removing the 8 screws. Cable FRU No. Specification 1SZZBA4023A M2.0 X L3.5 Remove the FAN Assembly. Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 58 ODD(1010), b. Memory Cover(1020), c. Bottom Case(1030), d. Battery(1040), e. HDD(1050), f. Sub Board(1060), g. WLAN(1080), h. FAN Assem- bly(1100) Disconnect the 6 cables after removing the 2 screws. Cable Cable Cable Cable Cable Cable FRU No. Specification 1SZZBA4023A M2.0 X L3.5 Remove the Mainboard. Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 59 ODD(1010), b. Memory Cover(1020), c. Bottom Case(1030), d. Battery(1040), e. Mainboard(1110) Disconnect the cable after removing the 2 screws. Cable FRU No. Specification 1SZZBA4023A M2.0 x L3.5 Remove the Touchpad module. Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 60 Remove the following parts in order before replacing this part. a. ODD(1010), b. Memory Cover(1020), c. Bottom Case(1030), d. Battery(1040), e. HDD(1050), f. Sub Board(1060), g. WLAN(1080), h. FAN Assem- bly(1100), i. Mainboard(1110) Remove the speakers. Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 61 ODD(1010), b. Memory Cover(1020), c. Bottom Case(1030), d. Battery(1040), e. HDD(1050), f. Sub Board(1060), g. WLAN(1080), h. FAN Assem- bly(1100), i. Mainboard(1110), j. Speaker(1130) Remove the 2 screws. FRU No. Specification 1SZZBA4023A M2.0 x L3.5 Remove the Power sub board. Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 62 ODD(1010), b. Memory Cover(1020), c. Bottom Case(1030), d. Battery(1040), e. WLAN(1080), f. Mainboard(1110) Remove the 4 screws. FRU No. Specification FAB31781701 M2.5 x L5.5 Remove after opening and folding 1/3 to the keyboard deck. Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 64 Remove the following parts in order before replacing this part. a. ODD(1010), b. Memory Cover(1020), c. Bottom Case(1030), d. Battery(1040), e. WLAN(1080), f. Mainboard(1110), g. Keyboard deck(1150) Remove the LCD Front Case. Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 65 ODD(1010), b. Memory Cover(1020), c. Bottom Case(1030), d. Battery(1040), e. WLAN(1080), f. Mainboard(1110), g. Keyboard deck(1150), h. LCD Front Case(1160) After removing 2 screws, remove by pressing the middle of Hinge caps. FRU No. Specification 1SZZBA4041J M2.0 x L3.0 Remove the Hinge caps. Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 66: 1180 Lcd Assembly
ODD(1010), b. Memory Cover(1020), c. Bottom Case(1030), d. Battery(1040), e. WLAN(1080), f. Mainboard(1110), g. Keyboard deck(1150), h. LCD Front Case(1160), i. Hinge Cap(1170) Remove the 4 screws. FRU No. Specification 1SZZBA4041J M2.0 x L3.0 Disconnect the cable to the back of the LCD. Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 68 ODD(1010), b. Memory Cover(1020), c. Bottom Case(1030), d. Battery(1040), e. WLAN(1080), f. Mainboard(1110), g. Keyboard deck(1150), h. LCD Front Case(1160), i. Hinge Cap(1170), j. LCD Assembly(1180) Remove the 6 screws. FRU No. Specification 1SZZBA4041J M2.0 x L3.0 Remove the Hinges. Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 69 ODD(1010), b. Memory Cover(1020), c. Bottom Case(1030), d. Battery(1040), e. WLAN(1080), f. Mainboard(1110), g. Keyboard deck(1150), h. LCD Front Case(1160), i. Hinge Cap(1170), j. LCD Assembly(1180) Remove the Aux/Main antenna. Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 70 ODD(1010), b. Memory Cover(1020), c. Bottom Case(1030), d. Battery(1040), e. WLAN(1080), f. Mainboard(1110), g. Keyboard deck(1150), h. LCD Front Case(1160), i. Hinge Cap(1170), j. LCD Assembly(1180) Disconnect the Cable. Disconnect the LCD Cable. Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 71 ODD(1010), b. Memory Cover(1020), c. Bottom Case(1030), d. Battery(1040), e. WLAN(1080), f. Mainboard(1110), g. Keyboard deck(1150), h. LCD Front Case(1160), i. Hinge Cap(1170), j. LCD Assembly(1180), k. LCD Cable(1210) Disconnect the Web cam module. Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 72: Part Lists
Power SUB B/D Cable NHDD01 EAZ61563602 HDD 2.5INCH 500GB SATA3 INNER 5400RPM TSDK HDD 2.5INCH 750GB SATA3 INNER 5400RPM NHDD01 EAZ61524701 HITACHI NHDD01 EAZ61563603 HDD 2.5INCH 750GB SATA3 INNER 5400RPM TSDK Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 73 Speaker - LEFT NKDECK06 EAB62810002 Speaker - RIGHT NBOTM01 ABQ74163502 Bottom case Assy (With Memory cover) 7/3 pn add (13') Bottom NBOTM02 MDP62486801 Bottom Rubber Rear (top) NBOTM03 MDP62486701 Bottom Rubber front (bottom) Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 74 Screw, M2 x L3.0 x D4.0 x H1 SCREW NSCR03 FAB31781701 Screw, M2.5 X L5.5 NSCR04 1SZZBA4011K Screw, M3 X L3 NSCR05 1SZZBA4023A Screw, M2.0 X L3.5 X D4.0 Silver (H:1t) (RJ45 Holder) Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 75 16.077 x 22.501 mm ) NLAB08 3858BZ9833F 700M GeForce Monochrome Sticker (Nvidia) NLAB09 MEZ65046201 SVC Call Label Black (Korea) NLAB09 MEZ65046202 SVC Call Label White (Korea) Pouch NPOUCH01 MAF63108501 Carrying BAG 14-15inch Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 76 NWEBC01 NLCD04 NLCD12 NLCD01 NLCD08 NLCD03 NLCD07 NLCD10 NLCD02 NLCD09...
Page 77 NLCD09 MBL65400101 Hinge cap - LEFT NLCD09 MBL65400102 Hinge cap - LEFT_white NLCD10 MBL65400201 Hinge cap - RIGHT NLCD10 MBL65400202 Hinge cap - RIGHT_white NLCD12 EAA63064501 Antenna Assembly (Main + Aux) Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 78 NKDECK01 NSUB03 NKDECK02 NSUB04 NKDECK04 NKDECK06 NKDECK03 NKDECK05...
Page 79 22.501 mm ) NLAB08 3858BZ9833F 700M GeForce Monochrome Sticker (Nvidia) NLAB09 MEZ65046201 SVC Call Label Black (Korea) NLAB09 MEZ65046202 SVC Call Label White (Korea) Pouch NPOUCH01 MAF63108501 Carrying BAG 14-15inch Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 80 NMLB01 NSUB01 NMRY01 NSUB02 NFAN02 NFAN01 NHDD03 NHDD01 NMINI02 NMINI01 NHDD02 NBATT01...
Page 81 7260.HMWBNG INTEL IEEE 802.11bgn 300Mbps 2x2 8 NMINI01 EBM61381202 7/15 pn add (14') MiniCard 02.11bgn + BT Combo INTEL CORPORATION NMINI02 EAZ61522904 SSD 128G HYNIX Memory NMRY01 EAN62661601 Memory DDR3L-1600MHz 4GB - Hynix Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 82 EAN62661501 Memory DDR3L-1600MHz 2GB - HYNIX Battery NBATT01 EAC62058401 BATTERY NFAN01 EAL60881103 FAN module Thermal NFAN02 MED62231209 Heat pipe module 7/3 pn change (13') Module NFAN02 MED62231210 Heat Sink (Samjin Tech) Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
Page 83 NBOTM02 NBOTM02 NBOTM03 NBOTM03 NBOTM01 NODD03 NODD01 NADT02 NODD02 NADT01 NPWCD01...
Page 84 Window8 OS Label ALL Windows 8 Logo ( GML, 16.077 NLAB07 MEZ64720301 x 22.501 mm ) NLAB08 3858BZ9833F 700M GeForce Monochrome Sticker (Nvidia) NLAB09 MEZ65046201 SVC Call Label Black (Korea) NLAB09 MEZ65046202 SVC Call Label White (Korea) Copyrightⓒ2014 LG Electronics Co., Ltd. LGE Internal Use Only...
