P/N : MFL63282702
REV.07
Service Manual
Model : T380/TB380/TV380 Series
2010. 11. 11
Copy Rightⓒ2010 LG Electronic inc, DigitalMate Co,.Ltd.
(LGE Internal use only)
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the T380 Series and is the answer not in the manual?

Questions and answers

Related Manuals for LG T380 Series

Summary of Contents for LG T380 Series

  • Page 1 P/N : MFL63282702 REV.07 Service Manual Model : T380/TB380/TV380 Series 2010. 11. 11 Copy Rightⓒ2010 LG Electronic inc, DigitalMate Co,.Ltd. (LGE Internal use only)

  • Page 2: Table Of Contents

    Contents Ch 1. Service information Ch 2. Locations Ch 3. System information · Specification · Model configuration System Block Diagram · Fn key combinations · Status indicators · BIOS Flash · BIOS Setup · Ch 4. Symptom-to-part index Power system checkout ·...

  • Page 3: Ch1. Service Information

    Ch1. Service information Chapter 1. Service information 1-1. Important service information Strategy for replacing parts (FRU-Field Replaceable Units) Before replacing parts Make sure that latest BIOS and drivers are installed before replacing any parts (FRUs) listed in this Use the following strategy to prevent unnecessary expense for replacing and servicing parts 1.

  • Page 4: Safety Notices

    Ch1. Service information 1-2. Safety notices Warning Before the computer is powered-on after part (FRU) replacement, make sure all screws, springs, and other small parts are in place and are not left loose inside the computer. Verify this by shaking the computer and listening for rattling sounds. Metallic parts or metal flakes can cause electrical shorts.
  • Page 5 Ch1. Service information 1-3. Safety information General safety Follow these rules to ensure general safety · Observe good housekeeping in the area of the machines during and after maintenance. · When lifting any heavy object 1. Ensure you can stand safely without slipping. 2.

  • Page 6: Electrical Safety

    Ch1. Service information Electrical safety Observe the following rules when working on electrical equipment. Important Use only approved tools and test equipment. Some hand tools have handles covered with a soft material that does not insulate you when working with live electrical currents. Many customers have, near their equipment, rubber floor mats that contain small conductive fibers to decrease electrostatic discharges.
  • Page 7 Ch1. Service information · Stand on suitable rubber mats (obtained locally, if necessary) to insulate you from grounds such as metal floor strips and machine frames. · Observe the special safety precautions when you work with very high voltages. These instructions are in the safety sections of maintenance information.

  • Page 8: Safety Inspection Guide

    Insulation must not be frayed or worn. 4. Remove the cover. 5. Check for any obvious non-LG alterations. Use good judgment as to the safety of any non-LG alterations. 6. Check inside the unit for any obvious unsafe conditions, such as metal filings, contamination, water or other liquids, or signs of fire or smoke damage.

  • Page 9: Grounding Requirements

    Ch1. Service information Handling devices that are sensitive to electrostatic discharge Any computer part containing transistors or integrated circuits (ICs) should be considered sensitive to electrostatic discharge (ESD). ESD damage can occur when there is a difference in charge between objects.

  • Page 10: Laser Compliance Statement

    Ch1. Service information 1-4. Laser compliance statement When a CD-ROM drive, DVD drive or the other laser product is installed, note the following : Caution Use of controls or adjustments or performance of procedures other than those specified here in might result in hazardous radiation exposure.

  • Page 11: Read This First

    1-6. Read this first Before you go to the checkout guide, be sure to read this section. Important Notes Only trained personnel certified by LG should service the computer. · Read the entire FRU removal and replacement page before replacing any FRU.
  • Page 12 Ch1. Service information The followings are not covered under warranty : CD panel cracked from the application of excessive force or from being dropped · Scratched (cosmetic) parts · Distortion, deformation, or discoloration of the cosmetic parts · Cracked or broken plastic parts, broken latches, broken pins, or broken connectors caused by excessive ·...

  • Page 13: Ch2. Locations

    Ch2. Locations Chapter 2. Locations ■ Left View 1. Power Port 2. Fan louvers 3. VGA Port 4. HDMI Port 5. USB Port 6. Multi Card Slot ■ Right View 7. Microphone Port 8. Headphone Port 9. USB Port 10. LAN Port 11.

  • Page 14: Front View

    Ch2. Locations ■ Front View ④ ② ① ③ 12. Cam LED 13. Built-in Microphone (May vary depending onmodel.) 14. Smart Cam (May vary depending onmodel.) 15. Smart ON Button 16. Power Button 17. Keyboard 18. Touch pad 19. Stereo Speaker...

  • Page 15: Ch3. System Information

    Ch3. System information Chapter 3. System information Specification Available Processors • Intel® Core™2 Duo / Pentium® Dual-Core / Celeron® Dual-Core / Celeron® Processors (L2 Cache Size: 1MB/ 2MB/3MB/6MB, FSB:800/1066MHZ ) are supported. ※ The user must not replace or expand the CPU capacity arbitrarily. The CPU capacity differs depends on model type Main Memory •...

  • Page 16: Ch3. System Information

    Ch3. System information External I/O Interface • External VGA Monitor Port: 1 • Microphone: 1 • Microphone Input Port (Mic in): 1 • Headphone Port: 1 • HDMI Port: 1 • USB 2.0 Ports: 3 • Multi‐card Slot: 1 • RJ 45 (LAN) Port: 1 Video •...

  • Page 17: System Block Diagram

    Chapter 3. System information ■ System Block Diagram...

  • Page 18: Fn Key Combinations

    Chapter 3. System information Fn key combinations The following table shows the function of each combination of Fn with a function key. Function of Fn keys has nothing to do with Operating System. Fn + F1 Customizable hot keys. (Configurable through OSD settings) Fn + F2 Customizable hot keys.

  • Page 19: Status Indicators

    Ch3. System information Status indicators The system status indicators show the status of the computer 1 . Power Lamp: • Blinking: System Standby • On: The system is running on the AC power or battery. • Off: The system is turned off or in Hibernates. 2.

  • Page 20: Bios Flash

    2. Copy BIOS Flash software to the flash update USB Device (FDD/USB Memory). 3. Connect the USB Device for USB Port. 4. Press F12 Key while the "LG LOGO" appears. 5. A while later, the system setup home screen appears.
  • Page 21 Ch3. System information 10. Press [F2] Key, then you can see the BIOS SETUP UTILITY screen as below. 11. It selects the :“Start Easy Flash”. 12. It selects the :” Load Optimal Dafault” and it summons a BIOS settings at initial value. 13.
  • Page 22 Ch3. System information 12. BIOS Flash screens appear. 13. BIOS, after selecting USB systems (FDD/USB Memory) where files are copied presses Enter.
  • Page 23 Ch3. System information BIOS Release Process and Making Bootable CD 1. LGE(Korea) will upload BIOS Image(*.iso) to GCSC(Global Cyber Service Center:http://biz.lgservice.com) when BIOS should be updated. 2. BIOS will include both System BIOS and EC(Embedded Controller) BIOS. 3. Service center can download BIOS file from GCSC and update BIOS according to below procedure. 4.
  • Page 24 Ch3. System information c. Select “Disc Image or Saved Project” d. Select File Format as "Image Files(*.iso)".
  • Page 25 Ch3. System information e. Open Image File(*.iso) which is sent from LGE f. Tab Burn then burning will be started...
  • Page 26 Ch3. System information g. Burn process completed as below, and tab “OK...
  • Page 27 2. Copy BIOS Flash software to the flash update USB Device (FDD/USB Memory). 3. Connect the USB Device for USB Port. 4. Press F2 Key while the "LG LOGO" appears. 5. It selects the :”Hard Disk Drives” and it summons a BIOS settings at initial value.
  • Page 28 Ch3. System information 7. Press [F2] Key, then you can see the BIOS SETUP UTILITY screen as below. 8. It selects the :” Start Easy Flash” and it summons a BIOS settings at initial value. 9. It selects the “OK”.
  • Page 29 Ch3. System information 10. You can see the BIOS flash process as below. 11. BIOS, after selecting USB systems (FDD/USB Memory) where files are copied presses Enter.
  • Page 30 Ch3. System information 12. “Do you want to update BIOS?” Yes or No or Yes selsct. 13. With afterwords the same screen appears.
  • Page 31 Ch3. System information 14. After flashing is completed, The computer turn off with automatic movement. 15. Press [F2] Key, then you can see the BIOS SETUP UTILITY screen as below. 16. It selects the :” Load Optimal Dafault” and it summons a BIOS settings at initial value.

  • Page 32: Bios Setup

    2. to replace the backup battery 3. system configuration error occurs 4. to change the boot order 5. to set/change a password Press the power button. When the LG logo appears on the screen, press and enter the BIOS Setup Utility.

  • Page 33: Using The Keys

    Ch3. System information Using the keys The keys used in the BIOS Setup Utility and their functions are described at the bottom. · : General Help Display the descriptions of the keys used in the setup utility. · : Select Item Navigate and select items in the setup utility.
  • Page 34 Ch3. System information Main menu · AMI BIOS Version · System Time This shows the AMIBIOS Version of BIOS. Current time. To change the value, press <+> or <−> key. · VGA BIOS Version This shows the VGA BIOS Version of BIOS. ·...

  • Page 35: Advanced Menu

    Ch3. System information Advanced menu · No Execute Mode Mem Protection Disables No Execute Mod Mem Protection. SATA Controller Mode Set SATA (Serial ATA) Controller Mode. · Core Multi-Processing Enables the Dual-Core technology. · Legacy USB Support There are two options to this field: Enabled, and Disabled. This field allows you to enable or disable the legacy USB support.

  • Page 36: Security Menu

    Ch3. System information Security menu · Supervisor Password This shows the system’s supervisor password has been set, or not. · User Password Set User Password is for setting the password lower than the one set in Set Supervisor Password. Set User Password is active only when the supervisor password is set.
  • Page 37 Ch3. System information Boot menu · Boot Device Priority Select the desired device drive by using the arrow buttons and change its booting sequence by using the [+] or [-] key. · Hard Disk Drives HDD of the system inside and external USB HDD etc., the father [thing] there is a possibility of deciding HDD orders which are the possibility of doing.

  • Page 38: Discard Changes

    Ch3. System information Exit menu Save Changes and Exit · Save the changes you have made and exit the utility. Discard Changes and Exit · Exit the utility without saving the changes you have made. Load Optimal Defaults · This changes the parameters in the Setup menu to the factory default settings. When it is selected or [F9] key is pressed, the confirmation message appears.

  • Page 39: Emergency Recovery

    Ch3. System information ■ Backup and Restore Security Platform Data Security Platform Backup includes all data required in case of emergency. After a hardware or storage media failure or a Trusted Platform Module failure, Security Platform Restoration reestablishes access to Security Platform Features for all users.
  • Page 40 Ch3. System information Personal Secure Drive Backup Contents A copy of the PSD encrypted data and configuration settings. Purpose Restoration of PSD encrypted data and configuration settings after a hardware or storage media failure. Otherwise users could not decrypt their PSD data anymore. Notes: •...
  • Page 41 Ch3. System information ■ How to Backup and Restore How to configure automatic backups Software Component to use ("System Backup") Administrative Task: Configure automatic If Security Platform is not yet initialized: backups for all users (including Security Initialization Wizard Platform Credentials and Settings, If Security Platform is already initialized: Settings Emergency Recovery and PSD configuration Tool - Backup - Configure...
  • Page 42 Ch3. System information ■ Infineon Platform Security Backup With this page you can backup and restore Security Platform credentials, Security Platform settings and Personal Secure Drives. If Enhanced Authentication is enabled, you can also create backups of your authentication device. Availability of page: This page is only available on an initialized Security Platform, if one of the following conditions is fulfilled: •...

  • Page 43: Ch4. Symptom-To-Part Index

    Ch4. Symptom-to-part index Chapter 4. Symptom-to-part index The symptom-to-part index in this section lists symptoms and errors and their possible causes. The most likely cause is listed first. Note If replacing a part (FRU) does not solve the problem, put the original part back in the computer. Do not replace a non-defective FRU.

  • Page 44: Ch4. Symptom-To-Part Index

    Ch4. Symptom-to-part index To check the AC adapter, do the following : 1. Unplug the AC adapter cable from the computer. Voltage (V dc) 2. Measure the output voltage at the plug of the +18.05 ~ +19.95 AC adapter cable. See the following figure : Ground 3.
  • Page 45 Ch4. Symptom-to-part index · If the voltage is not correct, replace the AC adapter. · If the voltage is acceptable, do the following : 1. Replace the system board. 2. If the problem persists, check the AC adapter whether it is correct product or not. Note Noise from the AC adapter does not always indicate a defect.
  • Page 46 Ch4. Symptom-to-part index · The Characteristics of the battery pack 1. Self-discharge The battery gradually loses its power over time without ever being used. 2. Periodic full discharge / charge Frequent recharge of the battery pack can reduce the capacity of the battery pack. When this happens, you can perform the full discharge / charge to improve the capacity.
  • Page 47 Ch4. Symptom-to-part index · To check the battery pack, do the following : 1. Power off the computer. 2. Remove the battery pack and measure the voltage between battery terminals 7(+) and 9(-). See the following figure : Terminal Voltage (V dc) Ground(-) 1(+) 2 3 4 5 6...

  • Page 48: Numeric Error Codes

    Ch4. Symptom-to-part index Numeric error codes Symptom / Error FRU or action, in sequence 0200 1.Reset the hard-disk drive. Fixed disk failure 2.Load Setup Defaults in BIOS Setup Utility. (The hard disk is not working) 3.Hard-disk drive. 4.System board. 0210 1.Check the keyboard if it is pressed.
  • Page 49 Ch4. Symptom-to-part index Symptom / Error FRU or action, in sequence 0251 Replace the backup battery and run BIOS Setup System CMOS checksum bad Utility – System CMOS checksum is not correct. to reset the time and date. – Default configuration used. 0252 Reset the password by running BIOS Setup Utility.
  • Page 50 Ch4. Symptom-to-part index Symptom / Error FRU or action, in sequence 02F7 1. DIMM Fail – Safe timer NMI failed 2. System board 0611 1. Load Setup Defaults in BIOS Setup Utility. IDE configuration changed 2. System board. 0612 1. Load Setup Defaults in BIOS Setup Utility. IDE configuration error 2.

  • Page 51: Error Messages

    Ch4. Symptom-to-part index Error message Symptom / Error FRU or action, in sequence Device address conflict. 1. Load Setup Defaults in BIOS Setup Utility. 2. Backup battery. 3. System board. Allocation error for device. 1. Load Setup Defaults in BIOS Setup Utility. 2.

  • Page 52: Lcd-Related Symptoms

    Ch4. Symptom-to-part index LCD-related symptoms Note Before removing or disassembling LCD, power off the computer, unplug all power cords from electrical outlets, remove the battery pack also. Symptom / Error FRU or action, in sequence LCD screen becomes dark suddenly. Check out Battery Miser.

  • Page 53: Indeterminate Problems

    1. Power off the computer 2. Visually check each FRU for damage. Replace any damaged FRU. 3. Remove or disconnected all of the following devices : a. Non-LG devices. b. Printer, mouse, and other external devices. c. Battery pack. d. PC cards.

  • Page 54: Chapter 5. Removing And Replacing A Part (Fru)

    Ch5. Removing and replacing a part Chapter 5. Removing and replacing a part (FRU) Danger Before removing any FRU, power off the computer, unplug all power cords from electrical outlets, remove the battery pack, and then disconnect any interconnecting cables. Caution Before the computer is powered on after FRU replacement, make sure that all screws, springs, and other small parts are in place and are not loose inside the computer.

  • Page 55: 1010 Battery Pack

    Ch5. Removing and replacing a part ■ 1010 Battery Pack 1. 1. Push the battery latch in the direction shown below; then slide the battery pack out of the slot. 2. Remove the Battery Pack.
  • Page 56 Ch5. Removing and replacing a part ■ 1020 Memory cover ※ Remove the following parts in order before replacing this part a. Battery Pack(1010) 1. Remove the 2 screw. FRU No. Specification 2. Remove the Memory cover.
  • Page 57 Ch5. Removing and replacing a part ■ 1030 Wi-Fi ※ Remove the following parts in order before replacing this part a. Battery Pack(1010) 1. Remove the 2 Antenna cable. Cable Cable 2. Remove the 2 screw. FRU No. Specification...
  • Page 58 Ch5. Removing and replacing a part 3. Remove the Wi-Fi.
  • Page 59 Ch5. Removing and replacing a part ■ 1040 Turbo Memory ※ Remove the following parts in order before replacing this part a. Battery Pack(1010) 1. Remove the 2 Antenna cable. Cable Cable 2. Remove the 2 screw. FRU No. Specification...
  • Page 60 Ch5. Removing and replacing a part 3. Remove the Turbo Memory.
  • Page 61 Ch5. Removing and replacing a part ■ 1050 Memory ※ Remove the following parts in order before replacing this part a. Battery Pack(1010), b. Memory Cover(1030) 1. Remove the Hook. Hook Hook Hook Hook 2. Remove the Memory.
  • Page 62 Ch5. Removing and replacing a part ■ 1060 Keyboard ※ Remove the following parts in order before replacing this part a. Battery Pack(1010) 1. Remove the 17 screw. FRU No. Specification 13EA 2. Pushes separates with arrow ticket direction.
  • Page 63 Ch5. Removing and replacing a part 3. Remove the Keyboard Cable. Cable...
  • Page 64 Ch5. Removing and replacing a part ■ 1070 Keydeck / Hinge Cap ※ Remove the following parts in order before replacing this part a. Battery Pack(1010), b. Keyboard(1020) 1. Remove the 2 Screw. FRU No. Specification 2. Uses sharp Pinset separates the both sides sticker.
  • Page 65 Ch5. Removing and replacing a part 3. Remove the sticker. 4. Remove the 4 screw. FRU No. Specification...
  • Page 66 Ch5. Removing and replacing a part 5. Remove the Hinge Cap. 6. Remove the 3 Cable and 3 screw. Cable Cable Cable FRU No. Specification...
  • Page 67 Ch5. Removing and replacing a part 7. Remove the Keyboard deck.
  • Page 68 Ch5. Removing and replacing a part ■ 1080 Touch Pad ※ Remove the following parts in order before replacing this part a. Battery Pack(1010), b. Keyboard(1020), c. Keydeck / Hinge Cap(1070) 1. Remove the 6 screw. FRU No. Specification 2. Remove the 1 connector. Connector...
  • Page 69 Ch5. Removing and replacing a part 3. Remove the Touch Pad Frame. 4. Remove the Touch Pad Cable.
  • Page 70 Ch5. Removing and replacing a part ■ 1090 Power Bottom ※ Remove the following parts in order before replacing this part a. Battery Pack(1010), b. Keyboard(1020), c. Keydeck / Hinge Cap(1070) 1. Remove the 1 screw. FRU No. Specification 2. Remove the Power Bottom.
  • Page 71 Ch5. Removing and replacing a part ■ 1100 Smart Link button ※ Remove the following parts in order before replacing this part a. Battery Pack(1010), b. Keyboard(1020), c. Keydeck / Hinge Cap(1070) 1. Remove the 1 Screw. FRU No. Specification 2.
  • Page 72 Ch5. Removing and replacing a part ■ 1110 HDD ※ Remove the following parts in order before replacing this part a. Battery Pack(1010), b. Keyboard(1020), c. Keydeck / Hinge Cap(1070) 1. Remove the 4 screw. FRU No. 규 격 수 량 2.
  • Page 73 Ch5. Removing and replacing a part 3. Remove the HDD Shield.
  • Page 74 Ch5. Removing and replacing a part ■ 1120 SD ※ Remove the following parts in order before replacing this part a. Battery Pack(1010), b. Retainer/Keyboard (1090), c. Keydeck / Hinge Cap(1070) 1. After pressing as the arrow professing direction unit, remove the SD Card. 2.
  • Page 75 Ch5. Removing and replacing a part ■ 1130 Bluetooth Module ※ Remove the following parts in order before replacing this part a. Battery Pack(1010), b. Keyboard(1020), c. Keydeck / Hinge Cap(1070) 1. Remove the 1 Cable. Cable 2. Remove the Bluetooth.
  • Page 76 Ch5. Removing and replacing a part ■ 1140 Sub Board ※ Remove the following parts in order before replacing this part a. Battery Pack(1010), b. Keyboard(1020), c. Wi-Fi(1030), d. Turbo Memory(1040) e. Keydeck / Hinge Cap(1070) 1. Remove the 2 cable and 1 screw. Cable Cable FRU No.
  • Page 77 Ch5. Removing and replacing a part ■ 1150 Mainboard ※ Remove the following parts in order before replacing this part a. Battery Pack(1010), b. Keyboard(1020), c. Wi-Fi(1030), d. Turbo Memory(1040) e. Keydeck / Hinge Cap(1070) , f. Sub Board(1140) 1. Remove the 3 cable and 3 screw. Cable FRU No.
  • Page 78 Ch5. Removing and replacing a part ■ 1160 CPU/GPU Fan Assembly ※ Remove the following parts in order before replacing this part a. Battery Pack(1010), b. Keyboard(1020), c. Wi-Fi(1030), d. Turbo Memory(1040) e. Keydeck / Hinge Cap(1070), f. Sub Board(1140), g. Mainboard(1150) 1.
  • Page 79 Ch5. Removing and replacing a part ■ 1170 Display Assembly ※ Remove the following parts in order before replacing this part a. Battery Pack(1010), b. Keyboard(1020), c. Wi-Fi(1030), d. Turbo Memory(1040) e. Keydeck / Hinge Cap(1070), f. Sub Board(1140), g. Mainboard(1150) 1.
  • Page 80 Ch5. Removing and replacing a part ■ 1180 AC Connector ※ Remove the following parts in order before replacing this part a. Battery Pack(1010), b. Keyboard(1020), c. Wi-Fi(1030), d. Turbo Memory(1040) e. Keydeck / Hinge Cap(1070), f. Sub Board(1140), g. Mainboard(1150), h. Display Assembly(1170) 1.
  • Page 81 Ch5. Removing and replacing a part ■ 1190 LCD Front case ※ Remove the following parts in order before replacing this part a. Battery Pack(1010), b. Keyboard(1020), c. Wi-Fi(1030), d. Turbo Memory(1040) e. Keydeck / Hinge Cap(1070), f. Sub Board(1140), g. Mainboard(1150), h. Display Assembly(1170) 1.
  • Page 82 Ch5. Removing and replacing a part ■ 1200 LCD Assembly ※ Remove the following parts in order before replacing this part a. Battery Pack(1010), b. Keyboard(1020), c. Wi-Fi(1030), d. Turbo Memory(1040) e. Keydeck / Hinge Cap(1070), f. Sub Board(1140), g. Mainboard(1150), h. Display Assembly(1170) I, LCD Front case(1190) 1.
  • Page 83 Ch5. Removing and replacing a part ■ 1210 LCD Panel Bracket ※ Remove the following parts in order before replacing this part a. Battery Pack(1010), b. Keyboard(1020), c. Wi-Fi(1030), d. Turbo Memory(1040) e. Keydeck / Hinge Cap(1070), f. Sub Board(1140), g. Mainboard(1150), h. Display Assembly(1170) I, LCD Front case(1190) 1.
  • Page 84 ■ 1220 LCD Cable ※ Remove the following parts in order before replacing this part a. Battery Pack(1010), b. Keyboard(1020), c. Wi-Fi(1030), d. Turbo Memory(1040) e. Keydeck / Hinge Cap(1070), f. Sub Board(1140), g. Mainboard(1150), h. Display Assembly(1170) I, LCD Front case(1190), j. LCD Assembly(1200), k. LCD Panel Bracket(1210) 1.
  • Page 85 Ch5. Removing and replacing a part ■ 1230 Web Cam Module ※ Remove the following parts in order before replacing this part a. Battery Pack(1010), b. Keyboard(1020), c. Wi-Fi(1030), d. Turbo Memory(1040) e. Keydeck / Hinge Cap(1070), f. Sub Board(1140), g. Mainboard(1150), h. Display Assembly(1170) I, LCD Front case(1190), j.

  • Page 86: Ch 6. Part List

    Ch6. Part lists Chapter 6. Part lists REV.07 Category Loc. No. LG P/N Description Remark 69N0W7M10B02-> 69N0W7M10B03(Pega NMLB01 EBR64728901 MAIN_BD._GS40 p/n separated from fan.) Mainboard 69N0W7M11B02-> 69N0W7M11B03(Pega NMLB01 EBR64728902 MAIN_BD._GS45 p/n separated from fan.) NSUB01 EBR64728903 Audio / USB suboard assy...
  • Page 87 EAD60956901 DC-Jack Cable NBOTM03 EAD60957001 SPEAKER NBOTM04 MCQ66585501 Bottom rubber - black 11/5 add(10') NLCD01 ABQ73002102 Rear Case Assy-BLACK LG-3G NLCD01 ABQ73002103 Rear Case Assy-BLACK XNOTE-WL NLCD01 ABQ73002101 Rear Case Assy-BLACK LG-WL NLCD01 ABQ73002105 Rear Case Assy-ORANGE LG-WL 1/4 add(10')
  • Page 88 NLAB01 MEZ62416603 NAME PLATE TV380 NLAB01 MEZ62416602 NAME PLATE TB380 NLAB02 MEZ62390402 POP LABEL GLOBAL LG CPU Label All model Intel Pentium Processor (2009) NLAB03 MEZ62085802 320797-001 CPU Label All model Intel Centrino 2 Processor NLAB03 MEZ62085201 Technology (2009) 320817-001...
  • Page 89 NLCD07 NLCD07 NLCD02 NLCD07 NLCD07 NLAB01 NLCD03 NLCD04 NLCD08 NLCD10 NLCD06 NLCD09 NLCD05 NRTN02 NWEBC01 NRTN01 NLCD01 NRTN03 NRTN01...
  • Page 90 1/4 add(10') NRTN03 MCK62973502 LCD Hinge Cap rubber-right NRTN03 MCK62973504 LCD Hinge Cap rubber-right-ORANGE 1/4 add(10') NLCD01 ABQ73002102 Rear Case Assy-BLACK LG-3G NLCD01 ABQ73002103 Rear Case Assy-BLACK XNOTE-WL NLCD01 ABQ73002101 Rear Case Assy-BLACK LG-WL NLCD01 ABQ73002105 Rear Case Assy-ORANGE LG-WL...
  • Page 91 NSUB02 NKDECK01 NKEYBD01...
  • Page 92 Key deck Category Loc. No. LG P/N Description Remark NSUB01 EBR64728903 Audio / USB suboard assy SUB B/D NSUB02 EAD60956701 Touch pad cable NKEYBD01 AEW72909801 KEYBOARD (KOR) NKEYBD01 AEW72909802 KEYBOARD (US) NKEYBD01 AEW72909803 KEYBOARD (GERMAN) NKEYBD01 AEW72909804 KEYBOARD (CB) NKEYBD01...
  • Page 93 NMINI02 NMRY01 NMINI03 NMINI01 NMINI04 NMRY01 NFAN01 NSUB01 NMLB01...
  • Page 94 Main Category Loc. No. LG P/N Description Remark 69N0W7M10B02-> NMLB01 EBR64728901 MAIN_BD._GS40 69N0W7M10B03(Pega p/n separated from fan.) Mainboard 69N0W7M11B02-> NMLB01 EBR64728902 MAIN_BD._GS45 69N0W7M11B03(Pega p/n separated from fan.) NSUB01 EBR64728903 Audio / USB suboard assy SUB B/D NSUB02 EAD60956701 Touch pad cable...
  • Page 95 NCVR01 NBATT01 NBOTM01 NHDD02 NDSO01 NBOTM02 NHDD01 NBOTM03...
  • Page 96 Etc. Category Loc. No. LG P/N Description Remark NCVR01 ACQ75432801 MEMORY DOOR COVER-BLACK Cover NCVR01 ACQ75432802 MEMORY DOOR COVER-ORANGE 1/4 add(10') NHDD01 EAZ60666904 SATA HDD 500G 5400R 2.5' NHDD01 EAZ50165402 SATA HDD 320G 5400R 2.5' NHDD01 EAZ60666902 SATA HDD 250G 5400R 2.5'...
