ＭＥＴＡ－ＨＡＷＫ

METAL DETECTOR

INSTRUCTION MANUAL

ＳＱＵＡＲＥ

Table of Contents

Need help?

Do you have a question about the META-HAWK and is the answer not in the manual?

Questions and answers

Summary of Contents for Square META-HAWK

Page 1 ＭＥＴＡ－ＨＡＷＫ METAL DETECTOR INSTRUCTION MANUAL ＳＱＵＡＲＥ...
Page 2: Table Of Contents
Thank you for purchasing META-HAWK. Read this instruction manual well, and use it properly. Contents Page To use it for safety ---------------------------------------------------------------------------- Check the installation of the metal detector and daily life operation ---------- The way of operating and using The basis of knowledge 1.1.1 Indication screen---------------------------------------------------------- 1-1...
Page 3: To Use It For Safety
To use it for the safety The item in this instruction manual that want to comply with to use it for the safety is mentioned. The meaning of the indication and the sign is as the following. Understand contents well, and read the text. The explanation of the sign in the instruction manual, the inside of the machine and around.
Page 4 To use it for the safety Warning ◆ Don’t touch a rotation part and a driving belt during the use. ◆ Don’t operate with taking a machine apart. ◆ Don’t operate with removing a safety cover. ◆ There are a DRY specification and a WET specification. Don’t do washing in water because a DRY specification doesn’t have a waterproof function.
Page 5 To use it for the safety Attention Please pull out a plug with holding it when you pull out a power ◆ supply plug. If you pull out a cord, the cord is injured and causes a fire, an electric shock. ◆...
Page 6 To use it for the safety Request Don’t install a machine in the following places. ・ The place where gets the direct sunlight. And the place where has a heart source near. And outdoors. ・ The place where nearby has mobile metal. ・...
Page 7: Check The Installation Of The Metal Detector And Daily Life Operation
Check the installation of the metal detector and daily life operation. The check on the installation 1. Metal fragment make not adhere to the conveyor part and the belt. In addition construction, be careful especially. 2. Don’t put metal around the inspection head of the metal detector. 3.
Page 8: The Way Of Operating And Using
1. The way of operating and using 1.1 The basis of knowledge 1.1.1 Indication screen METAL DETECTOR Button Function ① ・It uses for ON/OFF of the main power. (When you turned on, power LED lights up.) ※When you turned on/off, you keep pushing this button more than 2 seconds.
Page 9 Button Function ⑤ ・It uses for the choice of a item. ・It uses for UP/DOWN of the parameter value. １－２...
Page 10: The Definition Of The Masterwork
META-HAWK has the function of operating conveyor belt automatic go and return. So it is easy to set the sensitivity or NG level. 1.1.4 The function of automatic following META-HAWK has the function of keeping up to high sensitivity by automatic following changing of the goods influence. １－３...
Page 11: A Table Of Screen
1.1.5 A table of screen POWER ON PUSH Screen of examination Screen of goods choice ☆the goods are examined. ☆Choose the goods of being exmined. Refer to ‘1.2.3 The inspection’ Refer to ‘1.2.2 The choice of the goods’ KEEP PUSHING Screen of setting PUSH Next page...
Page 12 Previous page １ Name ☆A name of the goods is input. Refer to ‘1.3.2 A name of a goods setting’ ２ Sensitivity ☆Set up information of goods. Refer to ‘1.3.3 The setting of sensitivity’ ３ Level of NG ☆Set up the NG level. Refer to ‘1.3.4 The setting of NG level’...
Page 13 Previous page １Conv reverse ☆Set up the conveyor operation. Refer to ‘1.3.5 The conveyor going and returning’ ２ Inspection ☆Set up the way of examination. ４Common Refer to ‘1.3.6 The way of examination’ ３ Two prevention ☆Set up for prevent the passage sensor error. Refer to ‘1.3.7 The setting of prevent the passage sensor reacting some times’...
Page 14: The Operation
1.2 The Operation 1.2.1 The way of turning on the power Please clean the top of the conveyor belt. ① Keep pushing more than 2 seconds after confirm that an ② emergency stop switch is canceled. Use after turning on the power and passing for 30 minutes. ③...
Page 15: The Choice Of The Goods
1.2.2 The choice of the goods Choose the goods of being examined. Process Indication Operation Turn on the power Refer to ‘1.2.1 The way of turning on the １ power’. Move on the screen of the ２ choice of the goods Push to move on the screen of the choice of the goods at the screen of the...
Page 16: The Inspection
1.2.3 The inspection In the inspection screen, it displays the level meter that shows information of the goods and the influence of the goods. ④ ① ⑤ ⑥ ② ⑦ ⑧ ③ ⑨ Item Contents number The number of the goods that it be chosen at present ①...
Page 17 ・ When the influence of the goods exceeds the limit of NG detection, the goods are divided as NG goods by way of divide. ※ When the machine operates with ‘oxygen absorber’ mode, the influence of the goods exceeds the limit of NG detection is normally operation. So when the influence of the goods doesn’t exceed the limit of NG detection, the goods are NG goods.
Page 18: The Screen Of Count
1.2.4 The screen of count It shows total examination number, the number of NG goods. Process Indication Operation . Move on the screen of count １ Push to move on the screen of count at the screen of examination. The screen of count ２...
Page 19: The Basis Of Operating
1.3 the basis of operating 1.3.1 Move on the screen of the setting Move on the screen of the setting to set the sensitivity, the divide NG goods and so on. Process Indication Operation Turn on the power Refer to ‘1.2.1 The way of turning on the １...
Page 20: A Name Of A Goods Setting
1.3.2 A name of a goods setting A name of the goods is input. By so doing, the mistake of the goods number change and examination by un-setting can be prevent. Process Indication Operation The choice of the goods Refer to ‘1.2.2 The choice of the goods’. １...
Page 21 ・When you want to change of input position of a letter, do it with the following process. Process Indication Operation Enter the input position １ Push to enter the blinking position at the extreme upper step of the choice letter line. The change of input position ２...
Page 22: The Setting Of Sensitivity
1.3.3 The setting of sensitivity The information which is necessary for the examination is set automatically from the goods and the mode. Choose the mode in accordance with the character of the goods. Model Mode Dryness thing solids The thing that contains much water, the thing that salt concentration is thick.
Page 23 Process Indication Operation The setting of a master work The master work is put on the conveyor in ４ accordance with the definition. Push begin setting sensitivity. During setting Wait a moment. ５ sensitivity The memory of the setting ６ Push to memorize the value of the setting.
Page 24: The Setting Of Ng Level
1.3.4 The setting of NG level Normally, the function that the automatic setting of sensitivity sets NG detection limit automatically in about 3 times point of the influence of the goods. (When it is examined with ‘Oxygen absorber’, it is set automatically in about 0.5 times point.) Setup the NG level with the following process when you want to increase sensitivity and when it exceeds limit because of dispersion in the influence of the goods.
Page 25: The Conveyor Going And Returning
1.3.5 The conveyor going and returning Setting of a function that the conveyor operates going and returning automatically. When it is set the conveyor doesn’t going and returning, the conveyor rotates one way at the time of the speed detection, the setting of NG level. Process Indication Operation...
Page 26: The Way Of Examination
1.3.6 The way of examination Set the way of examination adapt to the shape of the goods and the environment of examination. When the goods are wrapped to individually and pass in a regularly pace, you set ‘the examination of one goods’. When the goods aren’t wrapped and pass irregularly, you set ‘the examination of loose goods’.
Page 27: The Setting Of Prevent The Passage Sensor Reacting Some Times
1.3.7 The setting of prevent the passage sensor reacting some times This item is set when the passage sensor reacts some times to one goods. This error happens when the sensor doesn’t have the size of the goods caught precisely. Process Indication Operation...
Page 28: The Setting Of The Divide Ng Goods
1.3.8 The setting of the divide NG goods How to sort NG goods is set. The way of the divide NG goods Sorter Conveyor stop When an NG goods is detected, the conveyor stops. Flipper When an NG goods is detected, the flipper operates. You must set parameter ‘on time’...
Page 29 Process Indication Operation The setting of a sorter (Ex. ５ Flipper) Push to choose ‘2 Flipper’ and push to move on a screen of the item. The setting of time ６ Push to choose the item and push to set the value of parameter.
Page 30: External Input Alarm
1.3.9 External input alarm It is the function that finishes automatic operation forcibly by using external input warning. Process Indication Operation The choice of the goods Refer to ‘1.2.2 The choice of the goods’. １ Move on the screen of ‘The Refer to ‘1.3.1 Move on the screen of the ２...
Page 31: The Setting Of Passage
1.3.10 The setting of passage You use the machine only for convey goods. Process Indication Operation Move on the screen of ‘The Refer to ‘1.3.1 Move on the screen of the １ setting setting’. Move on the screen of ‘The ２...
Page 32: The Conveyor Speed
1.3.11 The conveyor speed Process Indication Operation Move on the screen of the Refer to ‘1.3.1 Move on the screen of the １ others setting’ Move on the screen of the ２ conveyor speed Push to choose ‘2 Conveyor speed’ and push to move on a screen of the item.
Page 33 Process Indication Operation During the speed measurement Wait a moment. ６ ※Please confirm that the object pass right angle toward passage sensor during measurement. The memory of the setting ７ Push to memorize the value of the setting. ※Please confirm a result. ・...
Page 34: The Goods Copy
1.3.12 The goods copy Information of the goods is copied from No. into No. Process Indication Operation The choice of the goods Refer to ‘1.2.2 The choice of the goods’ １ Move on the screen of the Refer to ‘1.3.1 Move on the screen of the ２...
Page 35: The Setting Of Time
1.3.13 The setting of time It uses when printing out the log data about the NG goods. Please set a time at present. Process Indication Operation The choice of the goods Refer to ‘1.2.2 The choice of the goods’ １ Move on the screen of the Refer to ‘1.3.1 Move on the screen of the ２...
Page 36: The Display Of Balance
1.3.14 The display of balance A balance of the magnetic coil is indicated. Process Indication Operation The choice of the goods Refer to ‘1.2.2 The choice of the goods’ １ Move on the screen of the Refer to ‘1.3.1 Move on the screen of the ２...
Page 37: Auto Checker With Metal Detector
Auto checker with metal detector Auto checker with metal detector don’t have the following functions. Item Value of setup １.３.５ The conveyor going and returning One goods １.３.６ The way of examination Please setup with auto １.３.８ The setting of the divide NG goods checker Please setup with auto １.３.１１...
Page 38: Circular Type Auto Sensitivity Adjustment
Circular type auto sensitivity adjustment The information that is necessary for the examination is set automatically from the goods and the mode. The conveyor can’t go and return. When the setting of Auto Sensitivity is ‘No’, substitute for a sensor. While is being pushed, a sensor is the condition of ON.
Page 39: Trouble Shooting
1.6 Trouble shooting The troubles, the causes and the solutions are shown during the use. Error message Ex-error The cause and the solution message Interrupt Interrupt error Interrupt exceptional processing is generated. Turn off power, turn it on again, and then check. ｘｘｘ...
Page 40: After-Service
※ It sometimes has repair expenses even if it is a guarantee period when a guarantee is lost. Address Please contact the nearest agent or our company. ※ System Square Inc. 3-5-2 SINSAN, NAGAOKA-SHI, NIIGATA-PREF. 940-2127 JAPAN TEL +81-258-47-1677 FAX +81-258-47-0161 E-mail info@system-square.co.jp...
Page 42 The guarantee META-HAWK The term of a guarantee is one year. And the object of guarantee is the body of the machine. When a trouble occurred in the term of a guarantee, you ask a store that you purchase to repair.
Page 43 ２０００.１０ The second edition ２００２.０３ The third edition ２００２.１１ The fifth edition ２００３．０５ The sixth edition ２００３．０６ The seventh edition The book with missing pages are exchanged. SYSTEM SQUARE INC. 3-5-2 SHINSAN NAGAOKA-shi NIIGATA-pref. 940-2127 JAPAN TEL ８１－２５８－４７－１３７７ FAX ８１－２５８－４７－０１６１...
