Instruction Manual

for Dust Collector

English

DCP 10 PNE

Table of Contents

Need help?

Do you have a question about the DCP 10 PNE and is the answer not in the manual?

Questions and answers

Summary of Contents for Atlas Copco DCP 10 PNE

Page 1 Instruction Manual for Dust Collector English DCP 10 PNE...
Page 3 Instruction Manual for Dust Collector DCP 10 PNE Printed matter No. 9870 0010 00 ATLAS COPCO AIRPOWER NV www.atlascopco.com 12/2018...
Page 4 The manufacturer does not accept any liability for any damage arising for modifications, additions or conversions made without the manufacturer's approval in writing. Copyright 2018, Atlas Copco (India) Ltd. Any unauthorized use or copying of the contents or any part thereof is prohibited.
Page 5: Table Of Contents
Table of contents Preface Maintenance .......... 16 Safety precautions ........16 Please read the following instructions carefully before starting to use your dust Disassembly of the filter unit....17 Safety precautions ........7 collector. Introduction ..........7 Problem solving ........18 It is a solid, safe and reliable machine, General safety precautions ......
Page 6 - 6 -...
Page 7: Safety Precautions
The policy of Atlas Copco is to provide the complete. 3 Replace warning labels if they become users of their equipment with safe, reliable obscured or removed. and efficient products. Factors to be...
Page 8: General Safety Precautions
2 Parts shall only be replaced by genuine 11 Provide adequate space surrounding for maintaining the unit in a safe operating Atlas Copco replacement parts. work area and non-glare, overhead condition. Unit parts and accessories 3 Always replace worn and damaged...
Page 9: Leading Particulars
It can also be mounted on Atlas Copco trolley. The rock cuttings and dust particles that are sucked into the dust collector are collected into a sack.
Page 10: Main Parts
Main parts - 10 -...
Page 11: Functional Description
FUNCTIONAL DESCRIPTION Filter unit Reference Name Filter mounted on filter support (6) with Drive ejector Adjustable belt the help of fasteners. In filtration chamber The drive ejector (4) is located inside the Clamping lock larger particles are separated in the filter unit (5), and is thus well-protected cyclone, while smaller particles are Cover...
Page 12: Operating Instructions
Operating instructions HOSE CONNECTION BEFORE STARTING STARTING 1 There is a 2 way ball valve mounted on 1 Connect the compressed-air hose to the 1 Pull the sack support (1) which is inside cover (1). claw coupling on the cover (1). the housing unit (2) till it comes down completely.
Page 13: Sack Replacement
SACK REPLACEMENT MOVING THE DUST COLLECTOR When suction inlet is closed For specific instruction see below! 1 When the sack has been filled with completely, vacuum 10-20 kg of drill cuttings, it must be Do not carry the dust collector indicator turns red.
Page 14: Tool Holder
Drilling at temperatures below 0°C 3. For bigger diameter working tool adjust the spring (6) to position (5). When drilling in temperatures 4. For Smaller diameter working tool, below 0°C, the compressed air adjust the spring (6) to position (7). line must be equipped with a water separator.
Page 15: Suction Hood
SUCTION HOOD 3. During operation the operator needs to keep his/her legs on the flaps (4), so that To operate dust collector for Rock Drill suction hood (3) is always at ground (1), suction hood needs to be connected on surface (5).
Page 16: Maintenance
Check that there is no leakage in connections, joints, gaskets and hoses Clean the filter Disassemble the filter unit and check the filters for clogging and/or damage Parts shall only be replaced by genuine Atlas Copco replacement parts. - 16 -...
Page 17: Disassembly Of The Filter Unit
Disassembly of the filter unit 1. Loosen the clamping lock (1) at housing (2). 2. Remove filter unit with the help of handle provided on top of filter support (3). 3. Remove the filter (4) from support by unscrewing the Nut. 4.
Page 18: Problem Solving
Problem solving Problem: Reduced suction effect. Possible faults Corrective actions Clogged filter Clean the filter Damp cuttings have blocked the suction hose Clean out the suction hose by starting the ejector and then striking the hose carefully Freezing the ejector Pour approx.
Page 19: Technical Specifications
Technical specifications GENERAL SPECIFICATION Description Units Specification Weight Air Consumption at 6 bar 11-12 Suction hose Filter surface area m² Collection sack, flat dimensions 560 x 700 Diameter of Housing unit Height of Housing unit Height above ground 1310 - 19 -...
Page 20: Dimension Drawing
Dimension drawing - 20 -...
Page 21: Disposal
Support us by When developing products and services, Dispose contaminated substances and disposing professionally. Atlas Copco tries to understand, address, material separately, according to local assuring a correct disposal of the and minimize the negative environmental applicable environmental legislations.
Page 22: Maintenance Log
Maintenance Log Dust Collector ..............Customer ................. Serial number................................Service hours Maintenance action Date By initials - 22 -...
Page 25 DCP-10 Spare Parts List Dust Collector DCP-10 s/n PUN823224 - © 2018 Atlas Copco Airpower NV | No. 9870 0000 00 | 2018-10...
Page 26: General Information
F1700C Spare parts list General information This spare parts list applies to the following: Part number Description 8311032515 DCP-10 Use only authorized parts. Any damage or malfunction caused by the use of unauthorized parts is not covered by Warranty or Product Liability. Any unauthorized use or copying of the contents or any part thereof is prohibited.
Page 27 Mechanical Main Parts Accessories Accessories_dust collector Option Optional parts_dust collector Kits for dust collector...
Page 28 Parts Online DCP-10 s/n PUN823224- Mechanical Main Parts Refer to the Parts Online web page for most up-to-date information. The printed information might be outdated.
Page 29 Parts Online DCP-10 s/n PUN823224- Item Part No. Name 3310100734 Sack holder 3310100764 Housing 3310100766 Top cover 3310100704 Ejector nozzle 3310100722 Ejector tube 3310100756 Gasket 3310100712 Gasket 3310100710 3310100711 Clamping plate 3310100751 Nipple, Hose 3310101147 Hose, Ball valve to cleaning 3310101146 Hose, Ball valve to venturi 3310101012...
Page 30 Parts Online DCP-10 s/n PUN823224- Item Part No. Name 0347610400 Hose clamp 3310101349 Leg clamp complete 3310101116 Stand Support 0301232100 Washer DIN9021 0160608200 Slotted screw M6 x L14 mm 0333210845 Spring washer 0261109171 Hexagon nut M6 3310101202 Flat 3310101350 Leg complete 0261109176 Flange head hex.nut M10 Stand...
Page 31 Parts Online DCP-10 s/n PUN823224- This page intentionally left blank Refer to the Parts Online web page for most up-to-date information. The printed information might be outdated.
Page 32 Parts Online DCP-10 s/n PUN823224- Accessories Accessories_dust collector Refer to the Parts Online web page for most up-to-date information. The printed information might be outdated.
Page 33 Parts Online DCP-10 s/n PUN823224- Item Part No. Name 3310100769 Hose 3310100975 Plastic bag Not Shown For Breaker 3310101108 Tool holder CPL ( For Breaker ) 3310101130 Dust isolator 3310101131 Hose adaptor 3310101351 Sleeve complete 0147124403 Hex. Head screw 0333217450 Spring washer Top sleeve 3310101134...
Page 34 Parts Online DCP-10 s/n PUN823224- Option Optional parts_dust collector Refer to the Parts Online web page for most up-to-date information. The printed information might be outdated.
Page 35 Parts Online DCP-10 s/n PUN823224- Item Part No. Name 8311032514 Trolley Refer to the Parts Online web page for most up-to-date information. The printed information might be outdated.
Page 36 Parts Online DCP-10 s/n PUN823224- Kit Kits for dust collector Refer to the Parts Online web page for most up-to-date information. The printed information might be outdated.
Page 37 Parts Online DCP-10 s/n PUN823224- Item Part No. Name Not Shown Kits for dust collector 3310101353 Plastic bag kit (50 piece per pkt. ) 3310101352 Bellow kit (10 piece per pkt. ) 3310101385 Filter kit (3 piece per pkt. ) Refer to the Parts Online web page for most up-to-date information.
Page 38 F1700C Spare parts list Any unauthorized use or copying of the contents or any part thereof is prohibited. This applies in particular to trademarks, model denominations, part numbers, and drawings. www.atlascopco.com...
