Instructions
an LDI Company
INSTRUCTIONS
Minneapolis, MN 55428
www.safcoproducts.com
INSTRUCCIONES
Mobile Aisle 1000 Floor Lock
Mobile Aisle 1000 Serrure de sol
Mobile Aisle 1000 Bloqueo de piso
KEEP OUT OF REACH OF CHILDREN
⚠
UNTIL ASSEMBLY IS COMPLETE, DUE TO THE PRESENCE OF SMALL OR SHARP PARTS.
ADULT ASSEMBLY REQUIRED
⚠
⚠
TENIR HORS DE PORTÉE DES ENFANTS
MANTENER FUERA DEL ALCANCE DE LOS NIÑOS
JUSQU'À CE QUE
HASTA QUE SE
L'ASSEMBLAGE SOIT TERMINÉ, EN RAISON DE LA
COMPLETE EL MONTAJE, DEBIDO A LA
PRESENCIA DE PIEZAS PEQUEÑAS O AFILADAS.
PRÉSENCE DE PIÈCES PETITES OU TRANCHANTES.
SE REQUIERE MONTAJE DE ADULTOS
ASSEMBLAGE ADULTE REQUIS
PRODUCT WARRANTY is available online at: www.safcoproducts.com
LA GARANTIE DU PRODUIT est
LA GARANTÍA DEL PRODUCTO está
•
•
disponible sur l'Internet : www.safcoproducts.com
disponible en la Internet: www.safcoproducts.com
1-888-971-6225
For questions or concerns, please call
available Monday-Friday 7:30 AM to 5:00 PM (Central Time) (English-speaking operators)
Si vous avez des questions pour poser ou les préoccupations
Si usted tiene preguntas o preocupaciones,
pour exprimer, connecter au 1-888-971-6225
por favor llame 1-888-971-6225
de 7H30 à 17H00 (Heure centrale) (Opérateurs de langue anglaise)
de 7:30 AM a 5:00 PM (Hora Central) (Operadores que hablan inglés)
990000578: 1 990000578:of 4; Rev A; Rev Date 20-MAR-2025
Safco Products Company, Minneapolis, MN 55428
Advertisement
Summary of Contents for LDI Safco Aisle 1000
- Page 1 Instructions an LDI Company INSTRUCTIONS Minneapolis, MN 55428 www.safcoproducts.com INSTRUCCIONES Mobile Aisle 1000 Floor Lock Mobile Aisle 1000 Serrure de sol Mobile Aisle 1000 Bloqueo de piso KEEP OUT OF REACH OF CHILDREN ⚠ UNTIL ASSEMBLY IS COMPLETE, DUE TO THE PRESENCE OF SMALL OR SHARP PARTS.
- Page 2 5/16” Drill bit (provided), Drill, 3/16” X 6” T Handle Allen Wrench, Marker TOOLS REQUIRED: OUTILS REQUIS : Foret de 5/16 po (fourni), perceuse, clé Allen à poignée en T de 3/16 po x 6 po, marqueur HERRAMIENTAS REQUERIDAS: Broca de 5/16” (incluida), taladro, llave Allen con mango en T de 3/16” x 6”, marcador Floor Lock / Serrure de sol / Bloqueo de piso Floor Lock Template/ Modèle de serrure de sol / Plantilla de bloqueo de piso Floor Lock Plate / Plaque de verrouillage au sol / Placa de bloqueo del suelo...
- Page 3 Once the lock location has been determined, hold the template against the vertical face of the skirt and mark the 4 mounting holes with a marker. Then drill 4 holes with the provided drill bit through the face of the skirt. Une fois l’emplacement du verrou déterminé, maintenez le gabarit contre la face verticale de la jupe et marquez les 4 trous de fi...
- Page 4 After the Floor Lock is mounted to the vertical surface of the skirt, compress all Mobile Systems to the closed position. Let the 1/2” bolt of the fl oor lock drop to the deck panels of the Mobile 1000 system. Draw a circle around the perimeter of the bolt.
