Summary of Contents for AiXun F3000
- Page 1 F3000 F���� Farad Capacitor Spot Welder User Manual Operation instruction Please read this manual carefully before use...
-
Page 2: Product Features
Upgrade online remotely: Support to upgrade on PC remotely, continuous update on the parameters of spot welding mode, adjust parameter settings through AiXun Assistant flexibly. Multiple-channel control of MOS: Controlled by 6 MOSFET tubes, support strong output of soldering,... - Page 3 Shenzhen AiXun Intelligent Hardware Co., Ltd. The back side of the product power switch Product Accessories Spot welding tip*2 Type-C charging cable*1 User manual card *1 Spot welder fixture for battery*1 Spot welding probe*2 Certificate*1...
-
Page 4: Product Parameter
Shenzhen AiXun Intelligent Hardware Co., Ltd. Product parameter Product name: Farad Capacitor Spot Welder Model: F3000 Capacitor: 2.8V 3000F*2 Size: 203*127*86mm Charging voltage: 9V Max current: 3.0A Material: Aluminum shell+stainless steel plate Color: Black Accessories: Spot welder fixture for battery+capacitor spot welder probe 495mm x2pcs... - Page 5 "red port" of the host.) 2. Connect Type-C cable to F3000, charging is available after charger is connected. Achieve 90% battery power within 10 minutes, 200 times spot welding is available under full charging status. (Note: Support fast charging of chargers above 9V) 3.
- Page 6 The basic operation of spot welder fixture for battery Connect spot welder fixture for battery to any one of the port of F3000 device Install the cell: Place the cell of battery on the surface of “copper block” of spot welder fixture for battery, adjust “the slide block of spot welder fixture”...
- Page 7 Shenzhen AiXun Intelligent Hardware Co., Ltd. Setting 1、Long press button “M” to enter into the setting interface of F3000 2、“ Spot welding mode, pulse settings, automatic standby, sound settings, language settings” can be adjusted 2.1 Single press button “M” to enter into the interface of spot welding mode, single press button ”-” or “+” to switch “manual mode or automatic mode”, long press button “M”...
- Page 8 Unscrew the nuts in front of the two Place the spot welding tips into spot welding spot welding probes probes and screw the nuts Upgrade operation of the device 1. Unlock the computer and download AiXun Assistant from AiXun official website www.aixun.com.
- Page 9 Shenzhen AiXun Intelligent Hardware Co., Ltd. 2. Log in AiXun Assistant on the computer, connect the device to the computer host with Type-C To A data cable. After turning on the power switch of F3000, long press the "M" key on the device immediately until you hear the "beep"...
-
Page 10: After Sales
AiXun company has the final right to interpret the above regulations for users who do not comply with the above regulations. - Page 11 Phone：(+86) 400-875-9688 Website：www.aixun.com Address：Room 402(403), 4th Floor, Building 2, IOT Industrial Park, 4012 Wuhe Blvd, Bantian Street, Longgang District, Shenzhen 服务热线：400-875-9688 品牌官网：www.aixun.com 地址：深圳市龙岗区坂田街道五和大道4012号 IOT物联网产业园2栋4楼402(403)
