ST-FBR01 Barcode Reader Operation Manual
Product Name: ST-FBR01 Barcode Reader
Brand: Hoefer Inc.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ST-FBR01 and is the answer not in the manual?

Questions and answers

Summary of Contents for Hoefer ST-FBR01

  • Page 1 ST-FBR01 Barcode Reader Operation Manual Product Name: ST-FBR01 Barcode Reader Brand: Hoefer Inc.
  • Page 2 ★ Reproduction of any part of this guide without prior written consent from the company is prohibited. The information in this guide and the described products may change without notice. ★ Hoefer is a registered trademarks and the property of our company. Thank you for your support of Hoefer and for purchasing Hoefer products.

  • Page 3: Table Of Contents

    Table of Contents 1. Product Introductions 2.. Product Features and Specifications 3.. Unpacking and Accessories Checklist 4.. Installation the Software 5. User Guide 6.. Maintenance and Care 7.. After-Sales Service...

  • Page 4: Product Introductions

    1. Product Introductions This manual aims to provide detailed information and operating instructions for the ST-FBR01 Barcode Reader to help users use the device correctly. 2. Product Features and Specifications： Dimensions (W x L x H) 146mm x146mm x 200mm Weight 1350g (2.98 lbs)
  • Page 5 Install VisionSystem 1.0 into the drive D folder.

  • Page 9: User Guide

    5. User Guide 5.1 Device Setup 5.1.1 Connecting the Barcode Reader Place the scanner on a stable and level workbench and connect it to the computer (the port must be USB 3.0 or higher). 5.1.2 Orienting the SBS Rack Place the entire box of sample tubes to be scanned on the scanner, ensuring they are correctly positioned horizontally...
  • Page 10 5.2.1.3 Once successfully launched, the you will see the software Homepage 5.2.2 Connecting the Camera Click on “Setting”, then click on “Camera” to connect the camera. Ensure "Enable" is checked. When the main interface (Homepage) shows a green highlight in the upper right corner next to "Camera", it indicates the connection is successful.
  • Page 11 corresponding IP address, then click "Save" to save. Return to the main interface and click "Connect" to refresh the connection status. If not using, select "Nonuse", then click "Save" to save. Click "Connect" to refresh the connection status. The connection status will be displayed in the upper right corner of the homepage: green indicates a successful connection, gray indicates a failed connection or Nonuse.
  • Page 12 5.2.4.2 Table Header Customization Customize the header of the output table according to your experimental needs. 5.2.4.3 Automatically saves the original image of the code scanning photo and selects the format for saving the image. 5.2.4.4 Automatically save the image of the scanning photo result and select the format of the saved image.

  • Page 13: Software Operation

    5.2.4.5 Automatically clean up the images, there are two ways to choose "time" and "hard disk capacity". If you select "time", you can also set the number of days to clear the previously saved pictures. Setting the number of cached images 5.3 Software Operation 5.3.1 Create/launch a Project Click "Project"...
  • Page 14 This will bring you to "Project Management". 5.3.2 Select Rack Configuration To adapt the rack configuration specification for tube scanning, under “Project name” select the corresponding configuration, then click "Set project" to complete the setting. After completion, click "Save" to save the settings and close the current window. 5.3.3 Begin Scanning Click "Run", input the operator name or ID in the pop-up window, then click "Confirm".
  • Page 15 Click "Go" to complete the scan. 5.3.4 Adjusting and Calibrating Exposure Value Click Project to enter and set the appropriate exposure value. After the exposure value is set, click “Save” to save.
  • Page 16 If the exposure value is too high, the rack bottom code may not be recognized. In this case, the exposure value needs to be appropriately lowered. (See red square in the comparison below.) Exposure: 8000 us Exposure: 4000 us 5.3.5 Adjust QR Code Scanning Area Select “Project”...
  • Page 17 5.3.6 Positioning query. After scanning (as described in 5.3.3), click "Search" and input the QR code information to query.
  • Page 18 Search complete 5.4 Additional Software Settings 5.4.1 Password management settings. From the Homepage, select “Settings” and then the “Password” tab to manage and reset user passwords. 5.4.2 For other Settings, select the corresponding function under the “Other” tab.

  • Page 19: Maintenance And Care

    5.4.3 Query Log Select “Log” from the Homepage to query the log. 6. Maintenance and Care To maintain the device in good condition and ensure normal operation, please observe the following maintenance and care requirements: 1. Daily maintenance: use alcohol to wipe the outer shell. 2.
  • Page 20 Hoefer Inc. 32 Scotland Boulevard, Suite 9, Bridgewater MA 02324, United States Tel: +1 (800) 813-0488 Email: info@hoeferinc.com Web: www.hoeferinc.com...
