  • Page 1 KNIDOS USER MANUAL FOR KNIDOS _____________________________________________________________________________________ ISSUE:07.09.2006 - Rev:00...

  • Page 2: Table Of Contents

    KNIDOS USER MANUAL FOR KNIDOS Foreword Introduction Warning And Definition Stickers On The Case Norms And Certificates Installation And Environmental Situations Care And Cleaning Electricity Connection Recycle Parts Loading Goods Technical Details Installation and Assembly _____________________________________________________________________________________ ISSUE:07.09.2006 - Rev:00...

  • Page 3: Foreword

    KNIDOS 1. Foreword Dear Customer, Please be sure to read this operating manual carefully before putting your new device into use. The manual contains important notes on safety and proper installation, use and maintenance of the device. Please keep the manual ready for reference and hand it over to any future new owner of the device. Make sure the manual is read by all staff who may use or work with the cabinets and that they understand and observe the contents.

  • Page 4: Introduction

    KNIDOS 2. Introduction This guide is prepared for the KNIDOS cabinet. The details below are examined in general; How the refrigerator will be used, technical details, installation and assembling infos and suggestions for the users-care operations. KNIDOS is a pool type freezer which preserves frozen foods. It is suitable for use in markets and hypermarkets with its high performance, wide display and loading capacity.

  • Page 5: Warning And Definition Stickers On The Case

    KNIDOS 3. Warning and definition stickers on the case Product Definition Sticker (Fig.1): Product definition sticker is located inside the cabinet on the ceiling and it can includes all technical properties as below: Logo and address info of the producer company, product certificates and quality certificates of the producer, model of the product, article no, serial number of the product, production date of the product, air conditioner class of the product, temperature range of the cabinet, type of refrigerant, test pressure, working pressure,...

  • Page 6: Norms And Certificates

    KNIDOS 4. Norms and Certificates The approved certificates of norms and refrigerators that are using as reference; EN 60204-1; EN 60439-1; EN 60439-2 ENVIRONMENTAL CLIMATIC ATMOSPHERE (EN 441-4) This refrigerator is tested as to atmosphere heat class 3. Dry Air Relative Class Dew Point...

  • Page 7: Care And Cleaning

    KNIDOS 6. Care and Cleaning Long life and satisfactory performance of any equipment is dependent upon the care it receives. To ensure long life, proper sanitation and minimum maintenance costs, these display Cases should thoroughly cleaned, all debris removed and the interiors washed down, weekly. Fan Plenum To facilitate cleaning, the fan plenum is hinged and also fastened with screws at each end.

  • Page 8: Electricity Connection

    KNIDOS Remove screws and lift fan plenum for cleaning. Be sure to reposition the fan plenum after cleaning display cases. Take care to minimize direct contact between fan motors and cleaning or rinse water. Rinse with hot water, but do not flood. Never introduce water faster than the waste outlet can remove it. Allow display cases to dry before resuming operation.

  • Page 9: Loading Goods

    KNIDOS 9. Loading Goods Cabinet loading important rules that should be followed. Locate the goods to the shelves tidy. The overall load does not exceed the capacity of the shelves (160 kg/ m²). Shelves can be adjusted at different angles according to the device type (0°, 10°, 20°).

  • Page 10: Technical Details

    KNIDOS 10. Technical Details _____________________________________________________________________________________ ISSUE:07.09.2006 - Rev:00...
  • Page 11 KNIDOS _____________________________________________________________________________________ ISSUE:07.09.2006 - Rev:00...
  • Page 12 KNIDOS _____________________________________________________________________________________ ISSUE:07.09.2006 - Rev:00...
  • Page 13 KNIDOS _____________________________________________________________________________________ ISSUE:07.09.2006 - Rev:00...
  • Page 14 KNIDOS _____________________________________________________________________________________ ISSUE:07.09.2006 - Rev:00...
  • Page 15 KNIDOS _____________________________________________________________________________________ ISSUE:07.09.2006 - Rev:00...
  • Page 16 KNIDOS _____________________________________________________________________________________ ISSUE:07.09.2006 - Rev:00...
  • Page 17 KNIDOS _____________________________________________________________________________________ ISSUE:07.09.2006 - Rev:00...
  • Page 18 KNIDOS _____________________________________________________________________________________ ISSUE:07.09.2006 - Rev:00...
  • Page 19 KNIDOS _____________________________________________________________________________________ ISSUE:07.09.2006 - Rev:00...
  • Page 20 KNIDOS _____________________________________________________________________________________ ISSUE:07.09.2006 - Rev:00...
  • Page 21 KNIDOS _____________________________________________________________________________________ ISSUE:07.09.2006 - Rev:00...
  • Page 22 KNIDOS _____________________________________________________________________________________ ISSUE:07.09.2006 - Rev:00...
  • Page 23 KNIDOS _____________________________________________________________________________________ ISSUE:07.09.2006 - Rev:00...
  • Page 24 KNIDOS _____________________________________________________________________________________ ISSUE:07.09.2006 - Rev:00...

  • Page 25: Installation And Assembly

    KNIDOS 11. Installation and Assembly This section includes the installation and assembly operations of the product. Before starting the installation and assembly, the user manual of the product should be read thoroughly and the safety- related items specified in the manual should be followed. Joining Two Refrigerators Follow the sequence below to combine two or more refrigerators: Remove sidewalls (if any)
  • Page 26 KNIDOS Front Bumper Connections Fix the refrigerators, which are connected from the side struts, with the help of a cabinet puller piece on the front bumper profiles. Pass the cylinder head bolt through the puller on both refrigerators and tighten with the nut. (Fig.4) Attach the plastic bumper profiles onto the bumper aluminum parts using their lugs.
  • Page 27 KNIDOS Installation of the module joining plastic The module joining piece should be attached to the junction point of the two refrigerators. Attach the module joining upper and lower pieces via inserting them under and above the refrigerator side struts (Fig.
  • Page 28 KNIDOS Installation of Refrigerator Sides Before attaching the refrigerator sides, apply silicone adhesive to the polyurethane section on the side of the refrigerators. (Fig.15) Fix the sides to the refrigerator at the points indicated by the arrows. (Fig.16-17) The fasteners to be used are shown in Fig.20 and Table.4. Connect the corner bumper plastic to the place shown in Figure.18.
  • Page 29 KNIDOS Base Assembly The part under the bottom decoration of the refrigerator cabinets which cover the legs of the refrigerator is called the base. The base is connected to the cabinet legs with the base knob. Install the front base to the refrigerator first. After inserting the plastic of the plinth on the base, insert the front base to the nails on the foot of the cabinet with the plastic part on the bottom.
  • Page 30 KNIDOS Display Shelf Assembly Optionally, you can place single or double rows of uncooled display shelves in Çeşme pool refrigerator. In order to mount the display shelf in the cabinet, first insert the struts to the places indicated by the arrows in Figure 31.
  • Page 31 KNIDOS Figure.32 Figure.33 Figure.34 Figure.35 Figure.36 PIECES PART NAME 2500 3750 Strut assembly right –left Strut assembly middle Strut cover Left shelf arm 250mm (non-perforated) Right shelf arm 250mm (perforated) Left shelf arm 300mm (non-perforated) Right shelf arm 300mm (perforated) Left shelf arm 250mm (non-perforated) Right shelf arm 250mm (perforated) Left shelf arm 300mm (non-perforated)
  • Page 32 KNIDOS Display shelf 300mm Under-the-shelf traverse Lamp socket Fluorescent lamp Display shelf lower shelf cover plate Display shelf top shelf cover plate Table.7 _____________________________________________________________________________________ ISSUE:07.09.2006 - Rev:00...
  • Page 33 ! "# #$% % &' & ' *+ $ ( $$ " "...
  • Page 34 " ) % $*)#+ ),!( ) % $*)#+ ! ! 6 ( " ! ! 6 ( " ! ! 6 ( " ! ! 6 ( " ! ! 6 ( " ! ! 6 ( " ! ! 6 ( " ! ! 6 ( "...
  • Page 35 ! ! ) $ < 8 > $ < ! ) $ ( $$ 9 ;) $< ! - $< $ < ! % < 9 ;) $< ! - $< $ < ! % < 9 ;) $< ! - $<...
  • Page 36 B58B++ " )) B++? " " " " < ! )) < ! )) " " " " " " " " " " . ) $ (< $ < < < < 2 3 4 2 > 4 % ! ) $ 2 ! 4 ! ) $ 2 !4...
  • Page 37 . $" %&& ' @$ ) < ! < < !$ ) @$ ( $$ 8 %$ B++? $$ 8 %$ B5 $ " %" $$ %2 /%2 & ' . ) $ % " $ ! < " $ ! < ! ) $ "...
  • Page 38 ! ) $ %" $$ ( ! ) $ < ( $ % $$ . ) $ " " " " " " ! > ! ) $ " " " " " " . ) $ ! < -! -! ! !! ! !! $ ! ) $...
  • Page 39 ! % ! ) $ $ ! < ( $ % $$ % $ B++ $ $ B5 $ +# $' ! /7 2$ (4 % ! ) $ 2 ! 4 ! ) $ 2 !4 $G @ GHG 2 /4 2 =4 <...
  • Page 40 ;. ! ( < < < $ $$ 8 %$ B++? $$ 8 %$ B5 % ! : < ;. ! ( < ;! ! ( < < $ $< A< - < ( $ % $$ #) 4#" # 2#)&' >...
  • Page 41 > > A# 8C ) 2 % < $ " "! @ ( ) (/ +%. )*. 4#+4%' > /6>7 > < I& < < $< ! I& < I& !LNL@ $ < < < B++ $ 7 /& " 9 "...
  • Page 42 3 $ % < < $ % < $ #B & # : #B & ; #B & #B & #B ) < #B & $< B++ $ B++ $ " 9 " 9 " 9 " 9 " 9 "...
  • Page 43 > " " " " " " )2*7( # * )' # E 6B = ! # $ " @ ! ! $$ ! > ! ) $ < > 3 $$ < $< ! % # $ < $ 7 (<...
  • Page 44 < /=E 7 (< < 7 (< $ $ < $< ! >: ( $$ < ( $$ < 3 $$ < 3 $$ < ! )) ( $$ < ! ( $$ ! ( $$ +# $ + 7' $G 4 "...
  • Page 45 I/ % " " " " " " "1 " < " < < ! % ) < < " < " " / I+ % " " " " " " " 1 " < " < < ! % ) < <...
  • Page 46 !& ! % !& < !& " " " " " " 8< 6>/7 6>/7 6>/7 6>/7 6>/7 6>/7 8< & % ;#> ;#> ;#> ;#> ;#> ;#> 8< & < 6>/7 6>/7 6>/7 6>/7 6>/7 6>/7 ;#> ;#> ;#> ;#>...
  • Page 47 " #$% "&' $()"* & ,' #"+($( ) 70 " &51,5-( " " / " ! & ! ! ( " " " '*+,*-- " # ! $ % & %'$ ! %'$ ( " " # ! " / 0 &...
  • Page 48 > > 0 $ % & %'$ ! %'$ ( $ & " "#& '++" ) 0 *+ ) 0 *-- " " '0 "+( ' <. > ) 70 " " " &3 " " $ ;( & ) 70 "...
  • Page 49 " / ! " ) 70 *1'.()"* ."*( "% 02*.()"* ) 70 / " ) 0 / " 0 *4 )*9 0 51 &$ ( " " & '$% ()#' .%".3 '*-- '*-- 1 "C $ =<3. =<3. =<3. =<3. =<3.
  • Page 50 1 "C $ =<3. =<3. =<3. =<3. =<3. =<3. 2>)< 2>)< 2>)< 2>)< 2>)< 2>)< 1 "C $ =<3. =<3. =<3. =<3. =<3. =<3. 2>)< 2>)< 2>)< 2>)< 2>)< 2>)< 1 "C $ =<3. =<3. =<3. =<3. =<3. =<3. 2>)< 2>)<...
  • Page 51 '= D '= D '= D3 D'= D '=D D '= D1 '= D3 " D'= # '= D3 '= D D'= D- '= D " > > 0 - " & ' ' 7 0 " " " & >...
  • Page 52 " 3"" " & "" " ! " " " > > 0 - " : & & ' " / 0 > 0 " & " / " "- & " " '" & " " & ' 7 0 "...
  • Page 53 " / ) " > 6 " " / " / " " / &<0 0: / " / " " "...
