WINE COOLER
COS-24BIWCS
COS-24BIWCS-BK
2-BOTT LE WINE COOLER
USER & INSTALLATION
MANUAL
IMPORTANT:
READ AND SAVE THESE INSTRUCTIONS.
FOR RESIDENTIAL USE ONLY.
INSTALLER:
PLEASE LEAVE THESE INSTRUCTIONS WITH THIS UNIT FOR
THE OWNER.
OWNER:
PLEASE RETAIN THESE INSTRUCTIONS FOR FUTURE
REFERENCE.
Rev.25.01
Advertisement
Table of Contents
Related Manuals for Cosmo COS-24BIWCS
Summary of Contents for Cosmo COS-24BIWCS
- Page 1 WINE COOLER COS-24BIWCS COS-24BIWCS-BK 2-BOTT LE WINE COOLER USER & INSTALLATION MANUAL IMPORTANT: READ AND SAVE THESE INSTRUCTIONS. FOR RESIDENTIAL USE ONLY. INSTALLER: PLEASE LEAVE THESE INSTRUCTIONS WITH THIS UNIT FOR THE OWNER. OWNER: PLEASE RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE.
- Page 2 COSMO Appliances are designed according to the strictest safety and performance standard for the North American market. We follow the most advanced manufacturing philosophy.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Wine Cooler Safety ..................4 Important Safety Instructions ................5 Before Loading & Plugging In ................7 Recommendations .................... 8 Specifications ....................9 Installation Instructions .................. 10 Defrosting / Condensation ................12 Adjusting Wooden Shelves ................13 Reversibility of the Door ................. -
Page 4: Wine Cooler Safety
WINE COOLER SAFETY READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE Your safety and the safety of others are very important. We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety messages. This is the safety alert symbol. -
Page 5: Important Safety Instructions
To reduce the risk of fire, explosion, electric shock, or injury when using your wine cooler, follow these basic safety precautions: • COSMO offers no guarantee for our • Please don’t put acidic items, wine cooler if it is being used for any... - Page 6 IMPORTANT SAFETY INSTRUCTIONS WARNING To reduce the risk of injury when using your refrigerator, follow these basic safety precautions: For your safety observe the following • When disposing of the appliance, do recommendations: so only at an authorized waste • This appliance contains a small disposal center.
-
Page 7: Before Loading & Plugging In
GROUNDING INSTRUCTIONS: COSMO wine cooler must be grounded in case of wire leakage. Grounding reduces the risk of electrical shock. The wine cooler is equipped with a power cord having a grounding wire and plug. The wine cooler plug must be plugged into a properly affixed and grounded electrical outlet. -
Page 8: Recommendations
RECOMMENDATIONS • COSMO wine coolers are front venting but are not designed to be fully integrated behind a joinery door. • The units draws air from right of ventilation frame 110V from the rear and expel through left of ventilation frame under the front door. -
Page 9: Specifications
SPECIFICATIONS DOOR TYPE: Stainless Steel Door Frame ELECTRIC SUPPLY: 110V / 60Hz NET CAPACITY: 147L CABINET SIZE (WXDXH): 23.4"x 25.1" x 34.1" NET WEIGHT: 95 lbs... -
Page 11: Install Limitations
Minimum space required for COS-24BIWCS Model Allow enough space in the front of the unit to open the door to 120°. COS-24BIWCS Model uses side anti-dew tube and Independent cooling system... -
Page 12: Defrosting / Condensation
DEFROSTING / CONDENSATION Your wine cooler is designed with “Auto-cycle” defrost system. During “Off- cycle” the refrigerated surfaces of the wine cooler defrost automatically. Defrost water from the wine cooler storage compartment drains automatically and part of it goes into a drainage container, which is located at the back of the wine cooler next to the compressor. -
Page 13: Adjusting Wooden Shelves
ADJUSTING WOODEN SHELVES Adjusting and removing the shelves For easy access to the storage content, you must pull the shelves approximately 1/3 of its depth out of the rail compartment. These wine cabinets, however, are designed with a notch on each side of the shelf tracks to prevent bottles from falling. -
Page 14: Reversibility Of The Door
REVERSIBILITY OF THE DOOR Warning: To avoid accidents during the process of changing the door, we recommend that you get assistance. The glass door is heavy and may cause injury if dropped. • Depending on to the model and the type of handle your wine cabinet is equipped with, you may have to rotate the door through 180 degrees. - Page 15 6. Installing the Door Switch Press Plate and Metal Cap: After completing all the previous steps, locate the door switch press plate, which is currently positioned at the top middle part of the door. Carefully unscrew the press plate and relocate it to the bottom of the door.
-
Page 16: Handle Installation Method
Handle Installation Method 1. Take the handle out of the cabinet and remove the gasket on the inner side of the door to access the screws already attached to the door. 2. Align the handle with the screws and tighten them securely using a Phillips screwdriver. -
Page 17: Turning On Your Wine Cooler
TURNING ON YOUR WINE COOLER Plug in and switch on the cooler. When you use the wine cooler for the first time (or restart the wine cooler after having it shut off for a long time), there will be a few degrees variance between the temperature you have selected and the one indicated on the LED readout. -
Page 18: Temperature Settings
WARNING • Do not over load your wine cooler to facilitate air circulation. • Do not stack more than 1.5 rows of standard 0.75L bottles per shelves to facilitate air circulation • Avoid obstructing the internal fans (located inside on the back panel of the wine cooler). -
Page 19: Display Operation Instructions
DISPLAY OPERATION INSTRUCTIONS ° C ° F After the unit is power on, press for 3 seconds to turn ON or OFF the unit. • ℃/℉ switch: Press ℃/℉ button to change the temperature display between • Celsius and Fahrenheit. Press before adjust temperature. -
Page 20: Wine Serving Temperature Chart
WINE SERVING TEMPERATURE CHART All wines mature at the same temperature, which is a constant temperature set between 12ºC to 14ºC (54 to 57°F). The below chart is an indicative temperature chart to indicate the best temperature for drinking purposes. 6°C 43°F Champagne NV, Sparkling, Spumante... -
Page 21: Power Failures
POWER FAILURES In the event of a power interruption, all previous temperature settings are automatically preservation and it will revert to a preset temperature setting. (See preset chart) Most power failures are corrected within a short period of time. An hour or two’s loss of power will not affect wine cooler’s temperatures. - Page 22 The light does not work. Not plugged in. The circuit breaker tripped or a blown fuse. The bulb is out of order. The light button is “OFF”. Vibrations. Check to assure that the Wine cooler is level. The Wine cooler seems to The rattling noise may come from the make too much noise.
-
Page 23: Limited Warranty
LIMITED WARRANTY WARRANTY AND SERVICE TO RECEIVE WARRANTY SERVICE, YOUR PRODUCT MUST BE REGISTERED. TO REGISTER AND REVIEW FULL WARRANTY DETAILS, VISIT: WWW.COSMOAPPLIANCES.COM/WARRANTY SCAN TO REGISTER CUSTOMER SUPPORT TO CHAT WITH US LIVE FOR ASSISTANCE, VISIT: WWW.COSMOAPPLIANCES.COM/CHAT SCAN TO CHAT... - Page 24 IMPORTANT Do Not Return This Product To The Store If you have a problem with this product, please contact COSMO Customer Support at +1 (888) 784-3108 DATED PROOF OF PURCHASE, MODEL #, AND SERIAL # REQUIRED FOR WARRANTY SERVICE. IMPORTANT Ne pas Réexpédier ce Produit au Magasin...
- Page 25 MEMO...
- Page 26 MEMO...
- Page 27 MEMO...
- Page 28 APPLIANCES Cosmo is constantly making efforts to improve the quality and performance of our products, so we may make changes to our appliances without updating this manual. Electronic version of this manual is available at: www.cosmoappliances.com...
