- Page 1 Cordless Horse Clippers User Manual ON-D131...
-
Page 2: Safety Instructions
Safety Instructions 1.Read Before Use: Before using the clippers, read all safety and operating instructions. 2.Electrical Safety: Ensure that the voltage indicated on the rating label matches your electrical outlet. Do not immerse the appliance in water or any other liquids to avoid electric shock. -
Page 3: What You Have
What You Have Main Unit Charging Base Replacement Blades (3mm) Wrench Blade Protector Backup Battery Shims x2 Cleaning Brush Lubricating Oil... - Page 4 Display of Machine Components...
- Page 5 Introduction of Machine Components 1. Battery Pack 2. Body 3. Clipper Head 4. Screw Clipper head (Including Clipping Blades) 5. Jump Ring 6. Gear 7. Deflection Collar 8. Axis of Deflection 9. Screw 10. Adjustment Screw 11. Adjustment Cap 12. Regulation Spring 13.
-
Page 6: Before We Start
Before We Start 1. If the machine is not installed blade, won't be used. 2. Please clean the blade regularly and maintain the blade with oil. 3. Avoid placing the machine in direct sunlight and keep it away from any potential sources of ignition. 4. - Page 7 2. How to Assemble Ⅰ. Remove/Replace the 3mm blade 1） Disassembly Method: 2） Use a tool wrench to loosen the knob 22 part. rotate the nut 29 part, remove the cutter head. 3） Fixed the flat holes 4） Tighten the knob 22 of the 28, 33 blade part and test the horse part,then rotate the nut...
- Page 8 Ⅱ. If the shim is deformed/the shim bushing is broken, replace the spare shim promptly. 1） Removing the blade as 2） Put in the new shim, StepⅠ, then unscrew the tighten the screws. screws on both sides to remove shims . 1）...
-
Page 9: Product Parameters
Product Parameters Horse Clippers Model NO. 2601 Voltage 100-240V~ Motor Power Speed 2400rpm Amplitude of swing 6.5mm Approx 72mm*80mm*281mm Dimensions(W/H/L ) (including battery cartridge) Weight 1.1kg (including battery cartridge) Battery Pack Battery Specification 14.4V Li-ion battery cells Voltage 14.4V Capacity... -
Page 10: Maintenance And Cleaning
Maintenance & Cleaning Ⅰ. Daily Cleaning 1. Wipe off oil stains on 2. Use a cleaning brush the blade with a dry cloth to remove hair from the blade 3. Finally, drop oil to the blade to prevent rust Note: It is not recommended to clean the blade with running water. -
Page 11: Troubleshooting
Troubleshooting MALFUNCTION CAUSE RECTIFICATION Not connected to Plug into a power supply a power supply Charging If you can still charge the clipper indicator normally,it is not necessary to not on repair it. If you reallly need to Indicator damaged repair this problem,please return the appliance to a service centre. - Page 12 15 minutes Clipping tension Add pressure by tightening the too low adjustment cap (Figure 3) The animal’s hair Only clip when dry is wet Any problems, Possible Other please contact us our email: malfunction support@oneisall.com 11 EN...
- Page 13 E-Mail: Info@apex-ce.de GPSR-Manufacturer info： Business Name: chuzhouguanyidianzishangwuyouxiangongsi Manufacturer Address: CN, 239200, anhui, chuzhoushi, laianxian, xinanzhenqingliuxilu, taixinxiangzhangyuan1dong1danyuan2403shi Telefonnummer: +86 130 4980 3796 E-Mail: oneisallofficial@hotmail.com Product Name: Horse Clippers Brand: oneisall Product Model: 2601 Li-ion14.4V 2500mAh 36wh Made in China 12 EN...
- Page 14 WE ARE READY TO HELP Oneisall offers a standard 2 years warranty. If you have any issues with your Oneisall product, please do not hesitate to contact us. Be sure to include your proof of purchase, model number, and any relevant photos or videos in your message to expedite the process.
