MaxilM IM608
Maxi1Mm111
[ Quick Reference Guide ]
1. 10.1-inch LCD Capacitive Touchscreen
2. Ambient Light Sensor - detects ambient brightness.
3. Power LED - indicates battery level & charging or system
status.
4. Microphone
5. Collapsible Stand - extends from the back to allow hands-free
viewing of the Display Tablet.
6. Built-in Battery
7. Loudspeaker
8. Camera Lens
9. Camera Flash
10. DC Power Supply Input Port
11. Headphone Jack
12. USB Port
13. HDMI (high-definition multimedia interface) Port
14. USB Port
15. Mini USB Port
16. Lock/Power Button - turns the device on & off with long
press, or locks the screen with short press.
MaxiFlash JVCI
1. Power Port - connects the device and the power source with
the adapter.
2. Vehicle Connector - connects the device to the vehicle's DLC
via a standard high density DB-26 MVCI - OBDII cable.
3. USB Port
4. Vehicle LED
5. Connection LED
6. Power LED
MaxilM IM608
MaxlFlash JVCI
J2534ECU
R-anuner
