- Page 1 Duo Fire Pit Manual T H E D U O C O L L E C T I O N...
- Page 3 Duo Fire Pit Manual...
-
Page 4: Installation
IMPORTANT This document contains essential information for the safe installation and operation of this fire product. Instructions are modified or updated as needed. Before Installation, it is the installer’s responsibility to periodically review the current version of instructions for applicable updates. The instructions must be strictly followed to qualify for a product warranty. -
Page 5: Maintenance & Service
WARNING: Never use any material that is non-po- IMPORTANT rous and holds moisture, such as gravel, pebbles, etc. This material is not sufficiently porous to allow Please consult your burner manual. heated steam to readily escape. When heated, any moisture inside this material will boil and fracture unexpectedly, which can cause personal injury or Refer to the burner manual damage. -
Page 6: Table Of Contents
Contents Required Tools Included with Your Fire Pit Accessories Unpacking Base Placement Leveling the Fire Pit Securing Top & Bottom of Fire Pit Ignition System Installation Gas Connections Fire Media Installation Operating Instructions Warranty Information Routine Cleaning, Maintenance & Repair Required Tools Before you start assembling your fire pit make sure you have the following:... -
Page 7: Included With Your Fire Pit
Included with Your Fire Pit Burner - Please refer to your burner installation manual for included parts. Top of Fire Pit Bottom of Fire Pit Fire Media Flexible Gas Line - 1/2-inch National Pipe Thread Tapered (NPT) - 36 inches in length Key Valve and Mounting Plate Duo Side View (cut in half) -
Page 8: Unpacking
Unpacking • Do not discard any packaging until assembly is complete and your fire pit has been tested. • Keep your Duo Fire Pit installation manual and your burner installation manual in a safe place for future reference. Base Placement Please consult your burner manual for clearance requirements before choosing the location of your fire pit. -
Page 9: Ignition System Installation
Gas Connections Ignition System Installation Please consult your burner manual for hooking up gas line connections and clearance to combustible materials. All fire pits, match-lit kits, safety pilot, and electronic ignition systems are designed and intended for outdoor Before You Begin: use only. - Page 10 Gas Connections Continued Propane Configurations: iii. Use two open-ended wrenches to For Propane tank installations, your unit tighten all connection points. After the will come with a gas regulator hose. connections are finger-tight, make an ii. Connect the regulator hose to the Pro- additional quarter-inch turn with your Propane tank, then tighten it by hand.
-
Page 11: Fire Media Installation
Fire Media • For lava rock installation, apply the media only deep enough to cover Instructions the burner ring and pan — less than 2 inches above the fire ring. • For decorative fire glass, cover the Please refer to your burner manual burner with ⅛... -
Page 12: Operating Instructions
Operating Instructions IMPORTANT Before operating your Duo Fire Pit, ensure all gas connections are properly tightened and thoroughly checked for leaks. IMPORTANT Refer to your burner manual for information on proper leak detection and other critical information. IMPORTANT All fire pits with electronic ignition systems must be turned OFF via wall switch when not in operation. - Page 13 Match-Lit Ignition Configurations • With the valve on the fire pit in the OFF position, open the valve on your Propane tank or Natural Gas supply. • Double-check to make sure there are no gas leaks at the regulator or inlet side of the valve.
-
Page 14: Warranty Information
Warranty Information Except as noted herein, this FlameCraft product is warranted to the original purchaser as follows: Concrete: 1 year (defects in material and workmanship) Electronics, Gas Valves, & Pilot Assembly: Commercial - 6 months; Residential - 1 year Stainless Steel & Aluminum Pans: Commercial - 1 year;... - Page 15 Please check with your local authorities or standards. governing agencies for proper approvals • FlameCraft is not liable for any direct or before purchasing and installing. indirect costs associated with the repair • FlameCraft is not responsible for damage...
-
Page 16: Routine Cleaning, Maintenance & Repair
Routine Cleaning & Maintenance Mild cleansers are the best way to clean your product. Generally, warm, soapy water applied with a clean sponge or microfiber cloth is all that is necessary to keep your Duo in tip-top shape. ii. Avoid harsh chemicals, such as lacquer-based thinners, acetone, denatured alcohol, ammonia, or bleach, as well as abrasive cleaners and scrubbing pads. - Page 18 Notes: _________________________________________________________________________________________ _________________________________________________________________________________________ _________________________________________________________________________________________ _________________________________________________________________________________________ _________________________________________________________________________________________ _________________________________________________________________________________________ _________________________________________________________________________________________ _________________________________________________________________________________________ _________________________________________________________________________________________ _________________________________________________________________________________________ _________________________________________________________________________________________ _________________________________________________________________________________________ _________________________________________________________________________________________ _________________________________________________________________________________________ _________________________________________________________________________________________ _________________________________________________________________________________________ _________________________________________________________________________________________ _________________________________________________________________________________________ _________________________________________________________________________________________ _________________________________________________________________________________________ _________________________________________________________________________________________ _________________________________________________________________________________________...
