Xo XOU24WDZGOASS Manual

All purpose dual zone wine cooler
Hide thumbs

Advertisement

Table of Contents

XOU24WDZGOA
ALL PURPOSE DUAL ZONE WINE COOLER
I worked really hard
on this manual -
so please read it.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XOU24WDZGOASS and is the answer not in the manual?

Questions and answers

Related Manuals for Xo XOU24WDZGOASS

Summary of Contents for Xo XOU24WDZGOASS

  • Page 1 XOU24WDZGOA I worked really hard on this manual - ALL PURPOSE DUAL ZONE WINE COOLER so please read it.
  • Page 2 Before you proceed, take just a moment to register your XO at: www.xoappliance.com/register-your-product/ REGISTRATION HELPS YOU BY - Ensuring warranty coverage should you need service Providing ownership verification for insurance purposes Let’s XO notify you in the event of product changes or recalls.

  • Page 3: Where Things Are

    8 - 1 9 Reversing the Door Swing Sizes and Installation Dimensions Integrated Panel Dimensions Optional Stainless Overlay Panel Leveling Your XO O p erating Instruc tions 20 - 26 Product Over view Control System Over view Set ting the Temperature...
  • Page 4 the job isn’t done until To ensure that the installation process is successfully completed, here are few things to review... Is the unit plugged in? Are the controls on? (Panel will illuminate.) Are the controls operating correctly? Has the unit been properly leveled - both side to side and front to back - with all 4 leveling feet securely making contact with the floor? This is an OVERLAY unit - have the panels been securely attached and properly aligned? After installation, does the door open sufficiently to fully extend the shelves?

  • Page 5: Wine Cooler

    this is the model covered in this book WINE COOLER XOU24WDZGOA ACCOMMODATES EUROPEAN | ADA | AMERICAN STANDARD CABINETRY record your serial number here in case you need it later...
  • Page 6 For maximum efficiency, keep the door tightly shut unless loading or unloading and never overload your XO unit. Before installing, allow your XO unit to sit upright for 2 hours at the install site. This will allow the cooling system to stabilize after transportation. Failure to follow this step may cause problems.
  • Page 7 Damages caused by ambient extremes are not covered by the warranty Your XO unit is built to operate on 115V 60Hz and should be plugged directly into a dedicated 15 amp 3 prong outlet. If you are uncertain as to the...

  • Page 8: Right Or Left

    Your XO arrives with a right hand hinged door - but it is easily to reverse if you choose. To reverse the hinge on your unit, follow the directions below: Fig.A Fig.B...
  • Page 9 ( or small, as the case would be depth height, width & XOU24WDZGOA 24” WINE COOLER 21-11/16” 550mm 23-7/16” 595mm 19-15/16” 507mm 3-3/8” 85mm 2-3/16” 2-3/16” 27-15/16” 55mm 55mm (710mm) Minimum 32-1/4” 820mm Maximum 34-13/16”...
  • Page 10 European page 12 US Standard installation under ada counter continues on page 13 rough in dimensions ALL XO UNDERCOUNTER NEED MORE SPACE - UNITS ARRIVE PRE-WIRED CUT INTO AN ADJOINING WITH LOW PROFILE PLUGS CABINET TO REACH AN FOR EASY INSTALLATION OUTLET THERE 32 1/2”...
  • Page 11 US Standard installation european cabimets continues on page 13 rough in dimensions (720mm door height and 150mm plinth) ALL XO UNDERCOUNTER NEED MORE SPACE - UNITS ARRIVE PRE-WIRED CUT INTO AN ADJOINING WITH LOW PROFILE PLUGS CABINET TO REACH AN...
  • Page 12 European page 12 US Standard installation us standard height cabinets continues on page 13 rough in dimensions ALL XO UNDERCOUNTER NEED MORE SPACE - UNITS ARRIVE PRE-WIRED CUT INTO AN ADJOINING WITH LOW PROFILE PLUGS CABINET TO REACH AN FOR EASY INSTALLATION OUTLET THERE 34 1/2”...
  • Page 13 talking toe kicks TOE KICKS CAN VARY IN SIZE DEPENDING ON THE STYLE OF CABINETRY. THE MOST COMMON ARE 3” DEEP AND 4” TALL. THE DRAWING BELOW IS BASED ON THAT. EXTEND THE LEVELING FEET AT LEAST 2”. INSTALL YOUR OVERLAY PANEL, FOLLOWING THE INSTRUCTIONS IN THIS MANUAL ALLOWING THE APRON TO EXTEND BELOW THE DOOR.
  • Page 14 installation under a counter - 4” toe kick SIDE VIEW UNDER COUNTER A OVERLAY PANEL TOE KICK Door finish panel extends below the door. Toe kick can visually hide the vents without obstructing them The XOU24 GOA series is 32 1/4" Tall. The standard US undercounter refrigerator is 34" Tall. Allow the additional panel length to extend as an apron below the door.
  • Page 15 BEFORE BEGINNING: Attach any handle hardware before mounting the panel to the door frame. 1. Fully open the door and starting at one corner pull the gasket out of the gasket channel. 2. After removing the gasket lay it out on a flat surface to retain its shape. 3.
  • Page 16 optional stainless steel door panel kit p/n: The stainless door panel mounts in the same fashion as a wooden cabinet door. 23-7/16” Place the handle (B) over the 595mm 2 mounting studs (A) on the door frame with the set screws (C) pointing down.

  • Page 17: Using The Foot Sliders

    2-9/16” 65mm FRONT To compensate for different height cabinetry, your XO has leveling legs that can extend as much as 2-9/16” (65mm). When installing your XO with the leveling legs extended, use the FOOT SLIDERS provided under the feet on each side to help avoid catching and...
  • Page 18 it’s like zen - but cooler get your level out DO NOT NEGLECT THIS IMPORTANT STEP Rotate to raise or lower the LEVELING LEGS located at each of the four corners until all four legs are seated firmly on the floor and the interior floor of the unit is level both front to back and side to side.

  • Page 19: Finishing Touches

    - then screw the flange of the bracket to the cabinet. TOE KICK | PLINTH Your XO comes with a 4” (100mm) toe kick | plinth. It can accommodate up to a 6” (150mm) toe kick | plinth.
  • Page 20 LEVELING LEGS WHAT’S THAT NOISE... You new XO is designed for quiet operation but you may hear some sounds your old unit didn’t make. Because they are new you might be concerned, but they are usually normal. Sounds can also be amplified by hard surfaces like flooring or tiles. Here is a description of the types of sounds you might hear and what might be causing them.

  • Page 21: Take Control

    take control temperature Dual Zone Wine Coolers maintain two different temperature zones from one control panel. Dual Zone Wine Cooler Temp. Settings Adjustable Range: 41 F to 50 F (upper) 50 F to 64 F (lower) Your Wine Cooler remembers your last temperature settings in the event of a power failure and automatically adjusts to the previous setting(s) when power is restored.
  • Page 22 Press the icon again and the lights will change to honey amber. When you turn you XO Unit on, it is set to work in Standard Mode. Press and ECO Mode is turned on, ECO Mode is an energy saver function.
  • Page 23 dual zone control 2 zone wine coolers ON /OFF But ton Press & Hold for 1 Second to turn ON Press & Hold for 3 Seconds to turn OFF Press to Silence Alarm Light Function But ton Toggle Bet ween 3 Light Functions L1, L2, L3 Indicator Light TEMPER ATURE D ISPL AYS...
  • Page 24 how many wine bottles can this hold Wine bottles come in many shapes and sizes. The following MAXIMUM capacities are based on two of the most popular types in 750 ml. MODEL WIDTH ZONES BORDEAUX BURGUNDY 4 Racks of 6 4 Racks of 5 XOU24WDZGO 24”...
  • Page 25 Door Surface - Use only mild, non-abrasive detergents applied with a clean sponge or soft cloth. Rinse well with damp cloth. NOTE: Do not use cleaners containing ammonia or alcohol on your XO unit. Ammonia or alcohol can damage the appearance of the appliance.
  • Page 26 a breathe of fresh air for best results change every 3 to 6 months Your Air Refresh Ch arcoal Filter s Located H ere P/N: XOUAIRFILTER Rotate the filter 1/4 turn to un lock Pull straight out to remove Align the tabs and inser t the new filter Rotate filter 1/4 turn to lo ck in plac e...
  • Page 27 This may be a sensor malfunction. Unplug the unit and call for service. more “q & a” Why does condensation form on the inside or outside of my XO unit? It may be that the door is either opened repeatedly or not closed completely. It may also be due to an excessive ambient humidity, in which case it will clear when the humidity drops.

  • Page 28: Warranty

    OUTSIDE U.S. This warranty does not apply to, and XO is not responsible for, any warranty claims made on products sold or used outside the 48 continental United States.

This manual is also suitable for:

Xou24wdzgoa
