PROFESSIONAL PRODUCER PPC-T SPEAKERS
11.64in
9.61in
295.56mm
244.00mm
3.94in
100.10mm
8.70in
221.00mm
PPC80T-8
Origin Acoustics
PPC80T
6975 S Decatur Blvd
Suite 140
Las Vegas, NV 89118
SCALE:1:5
844-ORIGIN1 (674-4461)
O R I G I N
www.originacoustics.com
®
A C O U S T I C S
Please visit www.originpro.com or scan the QR code using your smart device
for the most up to date safety information and use instructions for this product.
9.61in
244.00mm
10.02in
254.56mm
3.20in
81.30mm
8.70in
221.00mm
PPC60T-8
Origin Acoustics
PPC60T
6975 S Decatur Blvd
Suite 140
Las Vegas, NV 89118
SCALE:1:5
844-ORIGIN1 (674-4461)
O R I G I N
www.originacoustics.com
®
A C O U S T I C S
10.02in
254.56mm
8.27in
210.00mm
3.32in
84.30mm
7.38in
187.40mm
PPC60TDT
PPC60TDT
SCALE:1:5
Origin Acoustics
6975 S Decatur Blvd
Suite 140
Las Vegas, NV 89118
844-ORIGIN1 (674-4461)
O R I G I N
www.originacoustics.com
®
A C O U S T I C S
INSTALLATION MANUAL
8.64in
219.56mm
3.05in
77.50mm
PPC50T-8
PPC50T
SCALE:1:5
Advertisement
Table of Contents
Summary of Contents for Origin PRO PPC-T
- Page 1 PROFESSIONAL PRODUCER PPC-T SPEAKERS 9.61in 10.02in 244.00mm 11.64in 9.61in 254.56mm 295.56mm 10.02in 244.00mm 254.56mm 8.27in 210.00mm 3.20in 3.32in 8.64in 3.94in 81.30mm 84.30mm 219.56mm 100.10mm 3.05in 77.50mm 8.70in 221.00mm 8.70in 221.00mm 7.38in 187.40mm PPC80T-8 PPC60T-8 PPC60TDT PPC50T-8 Origin Acoustics Origin Acoustics...
-
Page 2: Table Of Contents
Table of Contents 1. Introduction 2. Product Description 3. Specifications 4. Required Tools 5. What’s Included 6. System Wire Routing Considerations 7. Speaker Wire Polarity: Notes & Guidance 8. Speaker Installation Steps 9. 70V System Notes & Guidance 10. Tap Settings: Notes & Guidance 11. -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS This product must only be installed by professional AV integrators and installers. If using this product as surface mount, suspended, or any elevated location, be sure to consult a qualified structural engineer for are any questions or concerns regarding the structural integrity to ensure this product is used safely. -
Page 4: Introduction
1. Introduction Thank you for purchasing an Origin PRO Professional PPC-T Series Speaker. All of Origin PRO’s speakers are designed to have excellent sound quality, longevity, a simple installation process, and built specifically for commercial applications. This instruction booklet covers the necessary information for a smooth installation, including: the tools you will need, step-by-step instructions for installation, troubleshooting tips for any errors that may occur, and all warranty information. -
Page 5: Product Description
Each model is a 2-way loudspeaker with Silk tweeter, and front Mounted 8 ohm, 70 Tap Switch. The PPC-T Series are built with a standard dog-leg installation, yet reuse the same install brackets and cut-out templates as our Origin PRO PC In-Ceiling speakers, leaving the door open for simple future upgrades. -
Page 6: Specifications
3. PPC-T Speaker Specifications Model: PPC80T-8 • Part: PPC80T8000 Tweeter: 1”(25mm) Silk • Woofer: 8” (203mm) Polypropylene Frequency Response: 72Hz-20kHz -3dB | 50Hz-20kHz -10dB Power RMS | Peak: 30W | 100W Impedance: 8 ohm | 70V • Transformer Taps: 30W, 15W, 7.5W, 3.75W •... -
Page 7: Required Tools
Scan the QR Code on the reverse of this page for full instructions for this product. 5. What’s Included 100.10mm What’s Included What’s Included Recommended Tools Recommended Tools Speaker Grille Template 1. PPC-T Speaker • • Drywall Saw Drywall Saw • • Measuring Tape Measuring Tape •... -
Page 8: System Wire Routing Considerations
6a. System Wire Routing Considerations Plan how you will route the wire to the desired speaker location. There are several methods for routing the wire, and you may need to combine several of them. Behind the Baseboard The wire can Through Walls When running wires be routed behind the baseboard by through a wall, be sure to avoid all... -
Page 9: Speaker Placement
6b. System Set-Up (2 Speaker Placement) Position the two speakers in the middle of the room, no less than 6’ (2m) apart. Ideally, the two speakers would be placed an equal distance from the listener. If the room has a lower ceiling, the speakers can be closer together. Also, if the E60 INSTALLATION MANUAL speaker placement is intended for standing (as opposed to sitting) listeners, the Auxiliary Room (2 Speaker Placement) - Page 10 7a. Speaker Wire Polarity: Notes & Guidance You will need a wire that has at least two conductors; one that can be identified as the positive and the other as the negative. All two conductor wires have some means of identifying which conductor is which, but at times this identification may be subtle.
-
Page 11: Speaker Wire Polarity: Notes & Guidance
7b. Speaker Wire Gauge: Notes & Guidance The gauge of wire used can have an impact on the performance of your speakers. Generally, speaker wire is determined by the length of the run and wattage utilized. The longer your run is, the smaller the wire gauge must be. On commercial 70 Volt systems, 18 gauge, 2 conductor, stranded and jacketed without shield wire is commonly used. - Page 12 7c. Wire Gauge – 8 Ohm System Notes If using the PPC-T Speaker in a 8 Ohm system, the total wire resistance must be less than 10% of the speaker impedance. For example, since the speakers are nominally 8 ohms impedance, the total calculated wire resistance should be no more than 0.8 ohms.
- Page 13 First, for safety purposes, it is recommended to make the calculations based on 80% of the amplifiers rated power. • For example, 80% of an amplifiers rated power will mean that a 500W amplifier would safely deliver 400W of usable power (500W x 0.8 = 400W). Now, it is simply a matter of dividing 400 by the number of speakers and the tap setting being used in the system.
-
Page 14: Speaker Installation Steps
8. Speaker Installation Steps 8a. Cutting the Hole When you’ve decided on the locations for all of the speakers, use the template to trace a circle lightly in pencil where the hole should be. (If you don’t have a out Speaker Wire template, check the Specifications section for cutout sizes.) If you’re unsure on whether there may be obstacles (such as pipes or wires) where you plan on will need a wire that has at least two conductors;... - Page 15 3. Then, take the ceiling speaker wire and connect it to the Spring Terminal Connector on the Speaker. Push down on each connector, and insert each wire into the opening with the correct polarity. Make sure that the POSITIVE WIRE is attached to the RED CONNECTION and the NEGATIVE WIRe is being attached to the BLACK CONNECTION.
-
Page 16: Connecting The Wire
Connecting the Wire 8c. Installing the Speaker t the wires into the connectors, Make sure all the dogs are in the upright position and facing to the side, not out- ng sure that the positive wire is wards. Insert the speaker into the hole. Turn the fo Make sure all the dogs are in the g attached to the red connec- and the negative wire is being upright position and facing to the side, not outwards. - Page 17 8d. Installing the Grille Fit the grille over the speaker. 8e. Painting the Grille In some situations the speakers may look better if the color matched the walls, 2. Painting the Grille ceiling, or trim in the room. This can be accomplished by painting the grille. The grille must be painted with spray paint, and most hardware stores will mix a can In some situations the speakers may look better if the color matched the walls, of paint to match whatever color you need.
-
Page 18: System Notes & Guidance
9a. 70V System Notes & Guidance 70 Volt systems are advantageous when the design calls for multiple speakers from the same amplifier and/or long-distance wire runs. 9b. 70V Parallel Wiring Notes & Guidance • Use 1 SEPARATE wire run for: SUBWOOFERS •... -
Page 19: Tap Settings: Notes & Guidance
10. Tap Settings: Notes & Guidance This Professional PPC-T Speakers feature 3 different tap settings off the transformer, adjusted by a rotary switch on the side face of the speaker. The higher the wattage selected, the more output will be generated by the speaker. -
Page 20: Troubleshooting
11. Troubleshooting If you have a problem, try isolating it first. For example, if you’re playing a DVD and there is no sound, try replacing the DVD with another audio source to see if you get sound. If it does work, then the problem is with the television, DVD player, or the cables connecting them. -
Page 21: Technical Assistance
If you are considering returning the product, it’s required that you contact Origin PRO prior to any return attempts. This way we can determine if the issue can be resolved without returning the product, or if needed we can provide instructions and support for the return process. - Page 22 • Accidental damage • Damage caused by abuse or misuse • Damage caused by attempted repairs/modifications by anyone other than Origin PRO or an authorized dealer • Damage caused by improper installation • Normal wear, maintenance, and environmental issues •...
-
Page 23: Return Process
Before making any return attempts, it is required that you first contact Origin PRO. Return product to Origin PRO or your dealer, either in person or by mail. It’s preferable if the product is returned in the original packaging. If this is not possible, the customer is responsible for insuring the shipment for the full value of the product. - Page 24 03-05-25 6975 S Decatur Blvd, Las Vegas, NV 89118 • www.originpro.com • 844-674-4461 ©2025 Origin PRO. All copyrighted, trademarked and patented elements mentioned herein are the sole property of Origin PRO.
