Ultum Nature ATMOS Setup Instruction Manual

ATMOS
WIRELESS
REMOTE
SETUP INSTRUCTION GUIDE
POWER
BUTTON
COLOR CHANGING Slowly swipe
up and down for gradual RGB
color seclection.
Refer to SETUP GUIDE section.
CR2023
BATTERY
NOTE: Remove protective film
from battery before use.
WARRANTY INFORMATION
In the rare case that the unit you have received is defective, Ultum Nature Systems provides a one year limited warranty. Please take some time to register your new product at:
www.ultumnaturesystems.com/product-registration to expedite a potential future warranty claim.
Ultum Nature Systems warrants, to the original buyer, Atmos and Atmos Wireless Remote to be of the highest quality in material, craftsmanship and free of defects for a limited
warranty of one year, effective starting from the original date of purchase.
Under limited warranty, Ultum Nature Systems will replace or refund any product confirmed to be defective due to manufacturer flaws based on eligibility. This warranty extends only
to personal use and does not include any product that has been used for commercial or rental purposes, or any other use in which this product is not intended for. The warranty is
voided if the product has been subjected to abuse, tampering, modification or repair done by personal self, another person or by a non-qualified company. This warranty excludes
damage due to normal wear and tear and is not warranted against moisture or water damage.
This warranty is non-transferrable. Ultum Nature Systems assumes no liability and is not responsible in any way for any loss, damage or inconvenience caused by equipment failure or
user error, negligence, abuse or use that is noncompliant with the safety instructions and warnings included.
ALL EXPRESS AND IMPLIED WARRANTIES ARE LIMITED TO THE PERIOD OF THE ORIGINAL WARRANTY.
WOOD SURFACE
MOUNTING POINT
DISTANCE [2.11IN / 5.364CM]
Remote mounting bracket can be installed on
any smooth surface.
MOUNTING OPTION 1: Mounting holes for wood
surfaces
MOUNTING OPTION 2: Magnetized for metal
surfaces
MOUNTING OPTION 3: Adhere with double-sided
adhesive tape to other smooth surfaces
WIRELESS REMOTE SPECIFICATIONS
DIMENSIONS
MOUNTING POINT DISTANCE
BATTERY
VOLTAGE
OUTPUT SIGNAL
REMOTE RANGE
WORKING CURRENT
STANDBY CURRENT
STANDBY TIME
USAGE AND SAFETY INSTRUCTIONS
Please read the following safety instructions thoroughly before attempting to use this
product.
FOR MORE INFORMATION, PLEASE VISIT: www.ultumnaturesystems.com
• For indoor and aquarium use only.
• If the electrical cord or plug shows any damage, stop using immediately.
• Check that the voltage corresponds to the voltage of your electrical outlet.
• If the unit begins to operate abnormally, stop use immediately.
• Always unplug the unit before reaching into an aquarium and/or performing routine
• maintenance.
• Do not perform any modifications to the unit. Doing so may result in damage to the unit
• and/or injury.
• When installing or changing the battery, ensure battery position is correct before
• attempting to operate the unit. Monitor performance and replace the battery as
• necessary when the product becomes less responsive.
• Handle with care. This product is not waterproof and should not be submerged in or
• exposed to water.
EMC STANDARD (EMC)
MAGNETIC
SAFETY STANDARD (LVD)
MOUNTING
BRACKET
RADIO EQUIPMENT (RED)
CERTIFICATION
SETUP GUIDE
Before usage and installation, thoroughly inspect the unit for any defects, damages or
missing parts. If a part is missing or damaged, contact your Ultum Nature Systems dealer
immediately.
1. To turn the unit on, tap the ON/OFF button once.
2. To adjust brightness, hold the ON/OFF button for 1-6 seconds as desired.
3. To set the light to white, tap the ON/OFF button twice.
5.47 x 1.42 x 0.43IN / 13.89 x 3.61 x 1.09CM
2.11IN / 5.364CM
CR2032
3VDC
RF(2.4GHz)
30M / 98FT
WITHOUT OBSTRUCTION
<5mA
<10 A
1 YEAR
ETSI EN 301 489-1 V2.2.3
ETSI EN 301 489-17 V3.2.4
EN 62368-1:2020+A11:2020
ETSI EN 300 328 V2.2.2
CE,EMC,LVD,RED
• • •
•
• • • •
• • • •
• • •
