OVO -630ST-25H User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
NAUM-EN-OVO-600ST-750SM-12-20-2024
Central Vacuum System
User Manual
For product codes ending -25H
ex: OVO-630ST-25H
OVO-750SM-25H
For product codes ending -35H
ex: OVO-600ST-35H
OVO-750SM-35H
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept any
WARNING:
Look inside the bottom canister for the
mounting bracket.
The mounting bracket is inside the foam in the bottom canister.
at: www.youtube.com/@ovovacuum4302
at: www.youtube.com/@ovovacuum4302
interference received, including interference that may cause undesired operation.
For the installation video,
Scan the QR code or
visit YouTube video
SMART units:
FOR SMART UNIT ONLY:

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OVO-630ST-25H and is the answer not in the manual?

Questions and answers

Related Manuals for OVO OVO-630ST-25H

Summary of Contents for OVO OVO-630ST-25H

  • Page 1 User Manual For the installation video, Scan the QR code or visit YouTube video at: www.youtube.com/@ovovacuum4302 SMART units: For product codes ending -25H ex: OVO-630ST-25H OVO-750SM-25H For product codes ending -35H ex: OVO-600ST-35H OVO-750SM-35H at: www.youtube.com/@ovovacuum4302 FOR SMART UNIT ONLY: This device complies with part 15 of the FCC Rules.

  • Page 2: Table Of Contents

    Index 1. Important safety instructions ..................3 General guidelines and references ................4 Grounding requirements General guidelines to be respected at all times Models / Hybrid filtration system .................5 Installation.......................6 - 9 System operation instructions..................10 System maintenance....................10 Filtration system Trouble Shooting....................11 - 12 Low-voltage system (When not connected to the application)........13 LED interpretation chart 9.

  • Page 3: Important Safety Instructions

    1.IMPORTANT SAFETY INSTRUCTIONS CAREFULLY READ ALL OF THESE INSTRUCTIONS BEFORE USING THIS CENTRAL VACUUM SYSTEM. When using an electrical appliance, it is necessary to observe certain basic precautions. WARNING - TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY: Unplug the power cord from the electrical outlet before performing any maintenance on the power unit.

  • Page 4: General Guidelines And References

    To speci cations. This appliance should not be used with an optimize the performance and lifespan of your OVO power adapter. While it is recommended to install this unit on its unit, it is essential to perform regular maintenance and independent circuit and breaker, it is not necessary to do so.

  • Page 5: Models / Hybrid Filtration System

    The permanent lter must be replaced for a new one every two (2) years to maintain the warranty on the vacuum. It must be replaced with OVO lter: FP-8 (for product code that end with: -25H) or FP-12 (for product code that end with: -35H).

  • Page 6: Installation

    4. INSTALLATION APPLICABLE TO ALL POWER UNITS: The power unit must be installed in a well-ventilated area, protected from the weather. It must be easily accessible and positioned away from any heat source. The power unit must be installed near an appropriate electrical outlet.
  • Page 7 4. INSTALLATION (Cont.) - If installing a non-smart vacuum unit Connect the top air and debris intake pipe to the PVC piping network ( SOLD SEPARATELY) We suggest to use exible pipes for faster and easier installation NOTE: Our exible pipes are 12’’ long and comes in a set of 2 with connection pieces . You can connect two (2) exible pipes together by using the PVC pipe OUR FLEXIBLE PIPE KIT IS SOLD SEPARATELY pieces and the provided metal ring.
  • Page 8 4.1 INSTALLATION (cont.) - If installing a Smart vacuum unit Connect the top air and debris intake pipe to the PVC piping network ( SOLD SEPARATELY) We suggest to use exible pipes for faster and easier installation NOTE: Our exible pipes are 12’’ long and comes in a set of 2 with connection pieces . You can connect two (2) exible pipes together by using the PVC pipe OUR FLEXIBLE PIPE KIT IS SOLD SEPARATELY pieces and the provided metal ring.
  • Page 9 7. Connect your low-voltage wire (Skip those steps if using ONLY the app) IF YOU HAVE MULTIPLE INCOMING WIRES, FOLLOW STEP 7.1 TO 7.5 Note: Never connect more than 1 wire into the Low-Voltage socket IF YOU HAVE ONLY 1 INCOMING WIRE, FOLLOW STEP 7.1, 5.4 AND 7.5 Step 7.1 Step 7.2 Step 7.3...

  • Page 10: System Operation Instructions

    5. SYSTEM OPERATION INSTRUCTIONS Your new system is now prepared for use. Here are a few simple guidelines to follow when using your OVO Central Vacuum System: Insert the wall end of the hose into any of the vacuum wall inlet valves installed throughout your home. When you're ready to begin, simply press the ON-OFF switch on the hose handle! NOTE: In reference to the low-voltage system, all vacuum inlet valves are equipped with two (2) spring-loaded metal pins.

  • Page 11: Trouble Shooting

    7. TROUBLE SHOOTING GENERAL The following may cause failure of the power unit: - Inadequate electrical power (Voltage or Amperage). Verify that the electrical power supplied complies with the power unit’s requirement - Abnormal performances of the electronic control module or the motor Before calling a service technician, in case of a malfunction, please review the following situations by running the following simple diagnostics: SITUATION...
  • Page 12 SITUATION VERIFICATION VACUUM WON’T START OR STOP (see the picture to see proper plug-in method) there may be a problem with the cables. If the unit does not start contact us directly at 1-800-776-7891 or via email at info@myovo.net Use wire or a paper clip. Insert one side of the wire or paper clip into the black terminal on the low-voltage socket and the other into the red terminal.

  • Page 13: Safety Notes

    - Always unplug the central vacuum power unit to prevent the risk of electrocution. - Ensure that the work area is safe and clear before installing your new OVO central vacuum power unit. - Wear the necessary protective clothing and equipment before starting any work (such as goggles and gloves).

  • Page 14: Connection Of The Unit To The Application (Smart Only)

    WARNING: This smart central vacuum only works on 2.4 GHz WiFi! 9. CONNECTING THE UNIT TO THE APP Our smart vacuum can be used either like a normal central vacuum system or by connecting it to the Nadair smart app on your smart phone. Follow these steps to connect the vacuum or scan the following QR code: Log in Sign Up...
  • Page 15 5A.3- After adding the device, you will be redirected to the main be used. See pages 18 to 20 for the product features and page. You are now connected. (A) Click on “OVO central vacuum” status menu. to access the product features menu. (B) Click on the power icon to quickly power on and o your unit.
  • Page 16 Cancel Adding a device Bluetooth device Nadair / OVO central vacuum 5B.4- In the app, the device will appear. Click on the 5B.3- In the app, at the bottom of the page, con rm add button (+) and follow the steps.

  • Page 17: Reset The Unit / Change User (Smart Only)

    5B.5- After adding the device, you will be redirected to the main be used. See pages 18 to 20 for the product features and page. You are now connected. (A) Click on “ Nadair / OVO status menu. central vacuum” to access the product features menu.

  • Page 18: Product Features And Status Menu (Smart Only)

    To start and stop your unit from your smart device NOTE: This central vacuum unit is equipped with soft-start/stop technology. It adds 20% to the life expectancy of your OVO central vacuum motor and automatically vacuums debris out of the hose and piping network to ensure Speed no debris falls on the oor after vacuuming.
  • Page 19 WARNING: This smart central vacuum only works on 2.4 GHz WiFi! 9.2 PRODUCT FEATURES AND STATUS MENU (Cont.) 9.2 b) SECTION 2: FILTER LIFE AND USAGE TIME A) Filter life: When at 100%, the icon “change bag” and “clean filter” will be turn blue and the LED light on the unit will be flashing.
  • Page 20 WARNING: This smart central vacuum only works on 2.4 GHz WiFi! 9.2 PRODUCT FEATURES AND STATUS MENU (Cont.) 9.2 c) SECTION 3: UNIT STATE AND RESET Speed Filter life A) Unit State: Usage time The state turn in blue will indicate the status of your unit.

  • Page 21: Application Trouble Shooting (Smart Only)

    USA: www.myovo.net/ FAQ - myovo.net/trouble-shooting Canada: www.myovo.ca/ FAQ - myovo.ca/trouble-shooting Nadair / OVO central vacuum 1- Select the “Me” button. 2- Choose the FAQ & Feedback section. 3- (A) Enter your question in the search bar, select most asked or FAQ question.

  • Page 22: Connection With Alexa (Smart Only)

    9.5 CONNECTING TO AMAZON ALEXA Nadair / OVO central vacuum 1- Select the “Me” button. 2- Choose “More Services” section. 3- Select Alexa if you want to link your device to Amazon Alexa. 4- Select how you want to link the device 5- Follow the steps to nish the association.

  • Page 23: Low-Voltage System (When Connected To The Application) (Smart Only)

    - Always unplug the central vacuum power unit to prevent the risk of electrocution. - Ensure that the work area is safe and clear before installing your new OVO central vacuum power unit. - Wear the necessary protective clothing and equipment before starting any work (such as goggles and gloves).
  • Page 24 The Central Vacuum Power Unit Body, Motor & Module – Ten (10 years): OVO will repair or replace any defective parts of the central vacuum motor, electronic module, body, housing, and dust bin for ten (10) years, as long as OVO will repair or replace any defective parts of the central vacuum motor, electronic module, body, housing, and dust bin for ten (10) years, as long as you own it, and if used in normal conditions and properly maintained, as stated in the power unit instruction manual.

This manual is also suitable for:

Ovo-750sm-25hOvo-600st-35hOvo-750sm-35h
