- Page 1 Wireless Panic Button(Double) User's Manual ZHEJIANG DAHUA VISION TECHNOLOGY CO., LTD. V2.0.3...
-
Page 2: Foreword
User's Manual Foreword General This manual introduces the installation, functions and operations of the Wireless Panic Button (hereinafter referred to as the "Button"). Read carefully before using the device, and keep the manual safe for future reference. Model DHI-ARD822-W2 (868); DHI-ARD822-W2 Safety Instructions The following signal words might appear in the manual. -
Page 3: About The Manual
User's Manual About the Manual The manual is for reference only. Slight differences might be found between the manual and the ● product. We are not liable for losses incurred due to operating the product in ways that are not in ●... -
Page 4: Important Safeguards And Warnings
User's Manual Important Safeguards and Warnings This section introduces content covering the proper handling of the button, hazard prevention, and prevention of property damage. Read carefully before using the button, and comply with the guidelines when using it. Operation Requirements Make sure that the power supply of the device works properly before use. -
Page 5: Table Of Contents
User's Manual Table of Contents Foreword................................I Important Safeguards and Warnings......................III 1 Introduction..............................1 1.1 Overview..............................1 1.2 Technical Specifications........................1 2 Checklist................................3 3 Appearance..............................4 4 Adding the Button to the Hub........................5 5 Installation............................... 6 6 Configuration..............................7 6.1 Viewing Status............................ -
Page 6: Introduction
User's Manual 1 Introduction 1.1 Overview Wireless panic button is a wireless button transmitter that sends a panic alarm signal to the hub of the alarm security system. By just the press of the button, alarm signals and events are sent to the monitoring company to ensure a prompt response, and to keep you up to date via the DMSS app. - Page 7 User's Manual Type Parameter Description Min. Voltage 2.2 VDC Battery Low Threshold 2.6 VDC Quiescent current: 4.3 uA ● Consumption Max. current: 60mA ● PS Type Type C 55 mm × 36 mm × 14.2 mm (2.17" × 1.42" × 0.56") (L × W Product Dimensions ×...
-
Page 8: Checklist
User's Manual 2 Checklist Figure 2-1 Checklist Table 2-1 Checklist Item Name Quantity Item Name Quantity A: Standard B: Optional Panic button Bracket Quick start guide Screw package Legal and regulatory — — — information... -
Page 9: Appearance
User's Manual 3 Appearance Figure 3-1 Appearance Table 3-1 Structure Name Description Button Press and hold both buttons at the same time for 8 ● seconds, and then the system enters pairing mode. Flashes green quickly: Pairing. Solid green for 2 seconds: Pairing successful. Slowly flashes green for 3 seconds: Pairing failed. -
Page 10: Adding The Button To The Hub
User's Manual 4 Adding the Button to the Hub Before you connect it to the hub, install the DMSS app to your phone. This manual uses iOS as an example. Prerequisites Make sure that the version of the DMSS app is 1.97 or later, and the hub is V1.001.0000000.7.R. ●... -
Page 11: Installation
User's Manual 5 Installation Prior to installation, add the button to the hub and check the signal strength of the installation location. We recommend installing the button in a place with a signal strength of at least 2 bars. The button supports wall mount and can be hand-held. This section uses wall mount as an example. -
Page 12: Configuration
User's Manual 6 Configuration You can view and edit general information of the button. 6.1 Viewing Status On the hub screen, select a button from the peripheral list, and then you can view the status of the button. Table 6-1 Status Parameter Value The status for whether the permanent deactivation of the button is... -
Page 13: Configuring The Button
User's Manual Parameter Value Program Version The program version of the button. 6.2 Configuring the Button On the hub screen, select a button from the peripheral list, and then tap to configure the parameters of the button. Table 6-2 Button parameter description Parameter Description View device name, type, SN and device model. - Page 14 User's Manual Parameter Description Enable Accidental Press protection to avoid triggering unintended operations by accidentally pressing the button. Off : Disable the accidental press protection function. ● Press and Hold : Select Press and Hold to enable the ● accidental press protection function. Once enabled, you Accidental Press Protection have to press and hold the button to send alarm messages to the hub.
-
Page 15: Appendix 1 Security Commitment And Recommendation
User's Manual Appendix 1 Security Commitment and Recommendation Dahua Vision Technology Co., Ltd. (hereinafter referred to as "Dahua") attaches great importance to cybersecurity and privacy protection, and continues to invest special funds to comprehensively improve the security awareness and capabilities of Dahua employees and provide adequate security for products. -
Page 16: Service Configuration
User's Manual Service Configuration 1. Enable HTTPS It is recommended that you enable HTTPS to access Web services through secure channels. 2. Encrypted transmission of audio and video If your audio and video data contents are very important or sensitive, we recommend you to use encrypted transmission function in order to reduce the risk of your audio and video data being eavesdropped during transmission. -
Page 17: Software Security
User's Manual By viewing logs, you can learn about the IP addresses that attempt to log in to the device and key operations of the logged users. 3. Configure network log Due to the limited storage capacity of devices, the stored log is limited. If you need to save the log for a long time, it is recommended to enable the network log function to ensure that the critical logs are synchronized to the network log server for tracing.
