S Y S T E M S
Integrating a Nureva® HDL310 and HDL410 with Mira Connect™
This integration guide provides detailed steps for configuring Mira Connect (using
HDL410 audio conferencing systems.
Figure 1:
The Mira Connect AV control system controls thousands of devices, including Nureva HDL310 and HDL410 audio
conferencing systems.
Getting Started with Mira Connect
Mira Connect is an AV control system that communicates with, and controls, devices over an Ethernet network, RS‑232 using
a Global Caché IP2SL, Infra‑Red (IR) using a Global Caché IP2IR, or with contact closures using a Global Caché IP2CC.
If you are just getting started with Mira Connect, please watch our
see our
additional
resources, see our
Mira Connect Administrators
When controlling devices over RS‑232, see the
read our
RS‑232 best practices
Figure 2:
The Mira Connect AV control is used in a variety of applications.
Aveo Systems, Inc. • Marietta, GA • USA • Phone: +1.678.653.7090
Email: sales@aveosystems.com •
aveosystems.com
IT Network Basics for AV Professionals
Guide.
Global Caché Integration Guide
and
RS‑232 troubleshooting
Nureva® HDL310 and HDL410
Mira
Portal) to control Nureva HDL310 and
short training
videos, review our
article, and find even more information in the
for how to configure a Global Caché IP2SL and
articles.
1
Mira Connect Integration Guide for
technical
documents,
Copyright © Aveo Systems, Inc. All rights reserved.
Advertisement
Summary of Contents for Aveo Systems Nureva HDL310
- Page 1 Portal) to control Nureva HDL310 and HDL410 audio conferencing systems. Figure 1: The Mira Connect AV control system controls thousands of devices, including Nureva HDL310 and HDL410 audio conferencing systems. Getting Started with Mira Connect Mira Connect is an AV control system that communicates with, and controls, devices over an Ethernet network, RS‑232 using a Global Caché...
-
Page 2: Integration Steps
HDL310 and HDL410 systems. Tested with Nureva firmware 1.9.282987‑1069. Integration Steps To integrate a Nureva HDL310 and HDL410 with Mira Connect, follow these steps as detailed in the following sections: Add a room to Mira Portal Pair Mira Connect to the room... - Page 3 Mira Connect software and request a pairing code. The following figures show the pairing steps that are displayed on the touchscreen when using Mira Connect appliances. Aveo Systems, Inc. • Marietta, GA • USA • Phone: +1.678.653.7090 Copyright © Aveo Systems, Inc. All rights reserved.
- Page 4 Step 3. Add a Nureva HDL310 and HDL410 to the room Navigate to the desired room, and then in the Mira Portal ‘Equipment’ tab for that room, click ADD to select a Nureva HDL310 and HDL410 to add to the room.
- Page 5 Figure 5: Click ADD to add equipment to the room. Add a Nureva HDL310 and HDL410 to the room in Mira Portal (https://mira.aveosystems.com). Scroll as necessary to find the product in the list of Audio DSP section of the equipment list.
- Page 6 Mira Connect must have a network route to the IP address of the Nureva HDL310 and HDL410 device in order to control it. • If the green circle with a white check mark is shown, Mira Connect was able to connect to the Nureva HDL310 and HDL410 at the specified IP address and authentication credentials.
- Page 7 Step 4. Select the Audio Control Points To add control points, click Edit from the device’s menu, and select the Audio Control tab. Aveo Systems, Inc. • Marietta, GA • USA • Phone: +1.678.653.7090 Copyright © Aveo Systems, Inc. All rights reserved.
- Page 8 Nureva® HDL310 and HDL410 S Y S T E M S The audio channels: Microphone, Loudspeaker, and Voice Amplification of the Nureva HDL310 and HDL410 represent the main microphone mute, loudspeaker volume, and voice amplification mute and volume control. Depending on your system, you’ll enter controls for mute and room volume as shown in the following figure.
-
Page 9: Control Ports
Figure 10: Example Mira Connect user interface with a Nureva HDL310 and HDL410 and a display. Note that the background image, logo, and side bar menu colors can be customized by editing the Visual Theme for the site in Mira Portal. - Page 10 IT Network Basics for AV Professionals article. • If you don’t want to see the Nureva HDL310 and HDL410’s volume control on Mira Connect, edit the device settings and remove the Nureva HDL310 and HDL410 room volume control. • If you want to control the voice amplification channel, edit device and add a Sound Reinforcement control, selecting the Voice Amplification channel for the mute and optionally for volume and click ‘Update Equipment’...
