motea Divit WH45 Mounting Instruction

Wheel hanging shelf

Advertisement

Quick Links

Scope of delivery
Lieferumfang /
Darstellung
Illustration
Motea GmbH · Gewerbepark Grünewald 2
58540 Meinerzhagen
Montageanleitung /
Allgemeine Hinweise
Vielen Dank für den Kauf eines Divit Reifen Wandregals WH45.
Bitte lesen Sie sich die folgenden Installationshinweise sorgfältig durch.
Die Motea GmbH übernimmt keine Haftung für Sach- und/oder
Personenschäden, die durch eine unsachgemäße beziehungsweise
mangelhafte Montage oder Nutzung entstehen.
Technische Änderungen, Druckfehler und Irrtümer vorbehalten.
General notes
Thank you for purchasing a Divit wheel hanging shelf WH45.
Please read the following installation instructions carefully. Motea GmbH
accepts no liability for damage to property and/or personal injury
resulting from improper or defective installation or use.
Technical changes, misprints and errors excepted.
Beschreibung
(links und rechts)
(left and right)
Mounting pin
Kleines Rundrohr
Small round tube
Großes Rundrohr
Large round tube
Zugschraube
Mounting instruction
Description
Wandstütze
Wall support
Montagepin
Bolzen
Bolt
Lag screw
1
Anzahl
Quantity
2
2
4
2
2
4
Revision status 001
motea.com/contact
02/2024
