Panasonic PalmCam PV-DC2090 Service Manual
Hide thumbs
Also See for PalmCam PV-DC2090:
- Operating instructions manual (88 pages) ,
- Operating instructions manual (88 pages) ,
- Operating instructions manual (88 pages)
Table of Contents
Advertisement
Quick Links
SPECIFICATIONS
ITEM
CCD
1/2.7 inch (9.34 mm) 1,320,000 Pixels
f = 5.2 – 15.6 mm (equivalent to a 34 – 102 mm lens
Lens
on a 35 mm still camera.) / F2.8 – 4.7
Auto/ Preset (Zone)
Focus
7.9 inch (20 cm) – ∞ (approx.)
Focusing
Area
Iris
F2.8 / F8
1/4 – 1/750 sec.
Shutter
Speed
Auto/ Indoor/ Outdoor
White
Balance
LCD
1.8 inch (45.7 mm) TFT Color Liquid Crystal Display
Viewfinder
Memory
CompactFlash (CF) Card (8MB)
1,280 x 960 pixels (Super Fine, Fine mode)
Image Size
640 x 480 pixels (Normal, Zoom,
320 x 240 pixels (
Regarding the Service Manual of the Electrical Adjustment Procedures for models PV-DC2090/ PV-DC2590,
please refer to the Service Manual / Order No. MKE9905501A1.
®
SPECIFICATION
mode)
mode)
®
ITEM
Approx. 15 images (Super Fine mode)
Approx. 30 images (Fine mode)
Storage
Approx. 100 images (Normal, Zoom,
Approx. 6 images (
JPEG (Design Rule for Camera File System)
Format
Serial
Digital Signal
Video Signal
NTSC Composite
4 AA Alkaline Battery/ 4 AA Ni-Cd Battery/
Power
4 AA nickel-hydride Battery/ AC Adaptor
Supply
Power
Digital Camera:
AC Adaptor (Optional): Input: 120V AC 60Hz 9W
Consumption
32 – 104 °F / 0 – 40 °C (Temperature)
Operating
Condition
10 % – 75 % (Humidity)
Digital Camera:
Weight
AC Adaptor (Optional): 3.4 oz./ 112 g
Digital Camera:
Dimensions
AC Adaptor (Optional): 1.97 (W) x 2.83 (H) x 0.79 (D) inch
Weight and dimensions shown are approximate.
Design and specifications are subject to change without notice.
© 1999 Matsushita-Kotobuki Electronics Industries LTD.
All rights reserved. Unauthorized copying and distribution
is a violation of law.
ORDER NO. MKE9904500C1
Digital Camera
PV-DC2090
PV-DC2590
SPECIFICATION
mode)
mode)
6V DC, 1.0A (Alkaline Battery)
8.4 oz./ 280 g
4.63 (W) x 2.68 (H) x 2.07 (D) inch
118 (W) x 68 (H) x 52 (D) mm
50 (W) x 72 (H) x 20 (D) mm
