- Page 1 ® Video Spectral Comparator User Manual ® Product: VSC Manual Revision: 1.1 User Manual last updated: 15 November, 2024 Copyright © foster+freeman Ltd ...
- Page 2 Head Office & UK Sales Office US Sales Office foster+freeman Ltd foster+freeman USA Inc Vale Park 20145 Ashbrook Place Evesham Ashburn Worcestershire Virginia 20147 WR11 1TD USA UK + 44 (0) 1386 768050 +1 888 445 5048 + 44 (0) 1386 765351 +1 888 445 5049 sales@fosterfreeman.com usoffice@fosterfreeman.com www.fosterfreeman.com w ww.fosterfreeman.com German Sales Office Dutch Sales Office foster+freeman Europe GmbH ...
-
Page 3: Table Of Contents
Welcome About this manual Text Illustrations Safety and Warning Markers About this product Product Compliance FCC Compliance Hazard Protection Certificate of Conformity Calibration and Adjustment Safety Information General Safety Location Disposal Product Life Cycle Considerations Electrical Safety Mains Power Adaptor Mechanical Safety Optical Safety Risk Group 2 (Eye Safety) Exposure Hazard Values (EHV) Ultraviolet Light Sources UV-A (365 nm) UV-B (308 nm); UV-C (255 nm) Skin Protection Anti-Stokes Light Sources (IR 980 nm) Other Light Sources Risk Group 0 Thermal Safety Service, Care and Maintenance Servicing Care Cleaning Maintenance Access Covers VSC®90 - Main Unit Electrical Specification Electrical Connections... - Page 4 Transmitted Light OVD Lighting Coaxial Lighting Anti-Stokes Lighting Phosphorescence Optical Filters Filter Types Longpass Filter Bandpass Filter Shortpass Filter Camera Filters Fluorescence Examination User Guide Selecting a User Main Screen Current Applied Settings Sign Out Gallery Menu Overview Stored Images Save Current Image to the Gallery Save Current Image to Specified Location Import Images into Gallery Apply Image Settings Record Video Search Images Remove Images from Gallery Save Options Stop Recording Environment Menu Overview Illumination Modes and Light Sources Safety Interlocks OVD Lighting Spot Lighting Fluorescence Examination Anti Stokes Phosphorescence Coaxial Lighting Filters Camera Menu Overview Camera Settings Extended Camera Settings...
- Page 5 Features Menu Overview Quick Capture MRZ (Machine Readable Zones) MRZ controls Barcodes IPI (Invisible Personal Information) Latent Image Background Removal Face Matching Currency Documents Keesing Database Update Magnetic Security Feature Imager Compare AssureID™ Macros App Settings Annotations Image Settings Tools Text Add Notes Calibrate Measurement VSC®90 Overview...
-
Page 6: Welcome
Welcome ® Welcome to the foster+freeman VSC 90 Video Spectral Comparator. This equipment contains various light sources, methods of illumination and optical filters for the examination of questioned documents. About this manual Please read this information before using the product for the first time. Important information regarding the use of text, illustrations, safety and warnings within this manual. Text Text formats are used as follows: Important operating information Additional notes and advice Illustrations Illustrations are for explanatory purposes only. The appearance of the product, its components, accessories, and consumables may differ from that shown. Safety and Warning Markers Red markers prohibit certain actions or procedures. Disregard of these Prohibited warnings may pose a health or safety risk to the user or cause damage to the equipment. Yellow markers warn of a hazard. The user should be aware of the associated Caution risk and take appropriate precautions. Blue markers advise mandatory health and safety procedures, or other notable Mandatory information. Disregard of the advice may increase an associated risk. ... -
Page 7: About This Product
Before using the equipment for the first time, please read the safety information on the following pages. About this product Please read this information before using the product for the first time. Every effort has been made to ensure that the information presented in this document is correct at the time of writing. Foster+freeman reserve the right to make changes without prior notice. Product Compliance When correctly employed by appropriately trained personnel, this equipment is fully compliant with the relevant standards laid down by the UK Health & Safety Executive (HSE). Such compliances include: UKCA, CE and RoHS compliant. EN61010-1 safety standard for laboratory equipment compliant. EN62471 photobiological safety of lamps compliant. Electrical Safety Testing - (EST) EN 61010-1 :2010 - Safety requirements for electrical equipment for measurement, control, and laboratory use. Electromagnetic (EMC) - EN 61326-1 :2013 - Electrical equipment for measurement, control and laboratory use - EMC requirements. -
Page 8: Hazard Protection
1. This device may not cause harmful interference, 2. This device must accept any interference received, including interference that may cause undesired operation. Modifications not expressly approved by foster+freeman will void the user's authority to operate the equipment. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. The user must follow the specific operating instructions for satisfying RF exposure compliance. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Hazard Protection When correctly employed, this equipment provides the user with the necessary level of protection from operating hazards. Protection provided by the equipment may be impaired if the equipment is used in a manner not specified in the operating instructions. Certificate of Conformity A certificate of conformity for this product is available from foster+freeman Ltd. This equipment is manufactured in conformity with the requirements of the relevant directives of the European Community through compliance with a number of harmonised standards. Calibration and Adjustment This equipment is correctly calibrated and adjusted at the time of manufacture. Provided that the equipment is used in accordance with its operating instructions and is not maltreated, no further calibration or adjustment is required. -
Page 9: Safety Information
Safety Information Please read this information before using the product for the first time. In the event of a query, please contact customer support: customersupportteam@fosterfreeman.com General Safety Do not tamper with the safety interlocks. Use the equipment only for the intended purpose. Use the equipment only in accordance with the operating instructions. Use only with equipment specified by foster+freeman. Do not use damaged equipment. Do not operate the equipment with any access cover removed. Do not remove any access covers. Access covers are only to be removed by trained individuals authorised by foster+freeman. Use only with spares, accessories or other consumables supplied by foster+freeman. Dispose of the equipment only in a responsible manner. Do not attempt to defeat the safety interlocks. ® Do not place head inside the VSC ® The VSC 90 contains an RFID module that is classified as an intentional transmitter. Employ safe working practices. Location ... -
Page 10: Product Life Cycle Considerations
Product Life Cycle Considerations During the design and manufacture of our products, foster+ freeman has considered the environmental aspects of its activities, products, and services that it can control or influence, with regard to the following: Electrical items - Waste Electrical and Electronic Equipment Regulations SI 2013/3113 Wiring - Waste Electrical and Electronic Equipment Regulations SI 2013/3113 PCBs - Directive 1996/59/EC (OJ:L243/31/96) on the disposal of PCBs and PCTs Metalwork - Scrap Metal Dealers Act 2013 Chapter 10 Plastic - Waste (England and Wales) Regulations SI 2011/988 Glass - Dispose of as household waste. Batteries - Waste Batteries and Accumulators Regulations SI 2009/890 The legislation listed is the disposal route for products / items in the UK, disposal in territories outside of the UK must be in accordance with the legislation of that country. Electrical Safety DANGER: Risk of electric shock. This equipment must be earthed. Operate the equipment only from an appropriately rated electrical power source in ... -
Page 11: Mechanical Safety
Mechanical Safety CAUTION: Heavy. Use safe lifting and handling procedures. Weight of main unit, excluding PC, monitor or accessories = 17kg CAUTION: Fragile. Optical Safety Risk Group 2 (Eye Safety) CAUTION: Possible optical radiation hazard. Do not stare at LEDs. Do not look directly at any of the light sources while they are active. UV emitted from the product if safety interlocks are defeated. ® The VSC 90 has been classified to BS EN 62471 and is in excess of the Exempt Group, meaning that the system potentially poses a photobiological hazard. The photobiological hazard to the user exists only when the lid of the main unit is open. This product has been classified as Risk Group 2. The appropriate warnings are shown. Exposure Hazard Values (EHV) at the nominal worst-case exposure distance of 20 cm are as shown. Maximum daily safe exposure times based on Directive 2006/25/EC are also listed. Exposure times are representative of the normal use of the product. Exposure Hazard Values (EHV) This product has been classified as Risk Group 2. The appropriate warnings are shown. Exposure ... - Page 12 Do not touch any LEDs. Do not stare at any of the light sources. ® Do not place head near or inside the main VSC 90 unit. Do not defeat the safety interlocks. Wear adequate hand protection if using any of the UV light sources for extended periods of time. Avoid eye or skin exposure to unshielded UV if safety interlocks are defeated. Shortwave and mediumwave UV (255nm and 308nm) are very hazardous when the safety interlocks are defeated. Note that in almost all cases the 20cm exposure distance cannot be achieved without inserting the head ® into the VSC 90. Please note that these values are subject to change. EHV at LED source Hazard Risk Group 20cm from source Coaxial white Blue light 1 28.66% Transmitted flood UV 365 Actinic UV (eye and skin) 1 45.86% Transmitted flood white (5000K) Blue light 0 25.45% Transmitted flood IR 850 nm IR Eye ...
-
Page 13: Ultraviolet Light Sources
Risk Group 0 (Exempt) Risk Group 0 is a zero-risk classification for an LED that does not pose any photobiological hazard, as defined by EN 62471. Ultraviolet Light Sources This equipment contains light sources that can produce UV-A, UV-B and UV-C radiation. UV-A (365 nm) CAUTION: UV emitted from this product. CAUTION: Eye or skin irritation may result from exposure. Do not look directly at any of the longwave (365 nm) UV sources whilst they are active. Use appropriate shielding. UV-B (308 nm); UV-C (255 nm) Do not tamper with safety interlocks. UV emitted from this product if safety interlocks are defeated. CAUTION: UV radiation. CAUTION: Risk of eye damage. CAUTION: Risk of skin damage. Safety interlocks prevent the operation of potentially hazardous light sources unless the shielding flaps on the canopy are properly lowered. Skin Protection CAUTION: Risk of skin damage. -
Page 14: Thermal Safety
Risk Group 0 is a low-risk classification for an LED that does not pose any photobiological hazard, as defined by EN 62471. Thermal Safety The unit contains several sources of heat such as light sources and electronic circuits. No user serviceable lighting. Maintain adequate ventilation. The equipment generates heat that is removed by natural convection and with the use of a forced air cooling fan. Do not block ventilation from the rear of the unit when the equipment is in use. -
Page 15: Service, Care And Maintenance
Service, Care and Maintenance In the event of a query, please contact Customer Support: customersupportteam@fosterfreeman.com Servicing This equipment contains no user-serviceable parts. The equipment contains no user-replaceable parts. Do not use spares, accessories, or other consumables other than those supplied by foster+freeman. Refer all servicing to qualified foster+freeman personnel. Unauthorised servicing may void the warranty on this product. Care This product contains optical and other glass components. Protect the equipment from damage and contamination. When not required for use, store the equipment under its protective cover. Handle with care. Do not subject the equipment to mechanical shock. Do not drop. Cleaning Do not use abrasive cleaning materials or those containing strong acids or alkalis. Do not allow the ingress of liquids or other contaminants. Do not immerse. Remove dust deposits from external surfaces using a soft dry cloth or paper tissue. When necessary, use a soft cloth of paper tissue dampened with a mild cleaning solution. Allow all surfaces to dry ... -
Page 16: Vsc®90 - Main Unit
® 90 - Main Unit Electrical Specification Do not connect this product with an incompatible mains supply. Mains input 100-240V AC, 50-60Hz 120W MAX 2 .0A MAX ... -
Page 17: Electrical Connections
Electrical Connections 1. Computer connection via USB 3.0 for external computers. 2. USB 2.0. 3. USB 3.0. 4. Monitor connection. 5. Ethernet connection. 6. Mains electrical input. Mechanical Specification *Excluding P C, monitor and accessories. Environmental Specification Indoor use only. Maintain adequate ventilation. -
Page 18: Optical Specification
® 90: Environmental specification Location Indoor use only Altitude 2000m (Maximum) Ambient temperature (°C) 5 - 40 80% RH for temperatures up to 31°C, decreasing linearly to 50% RH for Ambient humidity (RH%) temperatures at 40°C Pollution degree of the Pollution Degree 2 intended environment Optical Specification ® The VSC 90 contains a wide array of different light sources, illumination modes and filters that are useful for questioned document examination. Light Sources ® The VSC 90 is capable of providing illumination in the Ultraviolet (UV), Visible and Infrared (IR) regions of the spectrum by using a wide array of light sources available within the unit. On Off Control (DC Power) ® The VSC 90 is powered on by pressing the button on the front canopy of the unit. Only a short press is required, do not press and hold this button. See: "User Guide" on page 21. Canopy ®... -
Page 19: Safety Interlock
Safety Interlock Do not attempt to defeat the safety interlocks. The canopy flaps are electrically interlocked to prevent the operation of potentially hazardous light sources. These light sources will not function unless the flaps are properly lowered, allowing the safety interlocks to be activated. Document Platen Documents for examination are usually placed face-up on the document ® platen under the canopy of the VSC Larger documents may extend under the hinged flaps on the side of the unit, or through the rear flap (highlighted). -
Page 20: Removing The Document Platen
Removing the Document Platen For some taller types of evidence, the document platen and transmitted light sources may need to be removed. Release the retaining screws at the rear of the main unit. Secure the retaining screw before transporting the equipment. Translucent Panel The centre of the document platen features a translight aperture, a panel of translucent material, below which are mounted the sources of transmitted light. The translucent panel is not removable. RFID Module An RFID module is built-in under the translight assembly for the reading of e-Chip data from identity documents. Monitor and Camera ® The VSC 90 features an ultra high-definition camera with a motorised lens allowing for auto-focusing, and a supplementary close-up lens. This allows for a magnification of 114x with a 27" QHD or 4K monitor and windows display scaling set to 125%. 135x magnification can be achieved on a 32" QHD or 4K monitor. -
Page 21: Light Sources
Light Sources ® The VSC 90 features a wide array of light sources in the UV, Visible and IR regions of the electromagnetic spectrum. All light sources are software-controlled to provide t he maximum visual contrast of a specific feature type within a questioned document. Light emitting diodes (LEDs) can be manufactured to produce a narrow bandwidth of light within the electromagnetic spectrum. Flood Lights Flood lights are used to evenly illuminate the entire document platen from above. The light sources available as flood lights are: UV-A, UV-B, UV-C, White visible light, and Infrared. Nominal w avelength (nm) Colour Bandwidth ( 10%) Peak Ultraviolet (UV) 245 - 265 Ultraviolet (UV) 295 - 320 Ultraviolet (UV) 350 – 3 80 White (5000K) 400 – 700 Infrared 700 - 800 Infrared 810 - 880 Infrared 890 - 980... -
Page 22: Transmitted Light
Transmitted Light Transmitted lights are used to illuminate a document from underneath to view security features such as watermarks or embedded security threads. ® The VSC 90 offers transmitted light as either a flood, where the entire translight aperture is illuminated; or as a spot, where only one region in the middle of the translight aperture is illuminated. Nominal w avelength (nm) Colour Flood Spot Bandwidth ( 10%) Peak Ultraviolet (UV) 350 - 380 White (5000K) 400 – 700 Infrared (IR) 700 - 800 Infrared (IR) 800 - 900 OVD Lighting Optical Variable Device (OVD) lighting uses white lights from different directions, usually used to view ® iridescent or non-iridescent security features such as holograms or kinegrams. The VSC 90 uses a total of 42 LEDs, arranged around the document platen, so that when cycling through these lights, any iridescent features may be viewed in their entirety. ®... -
Page 23: Phosphorescence
Phosphorescence ® The VSC 90 uses a source of UV-A light, 365 nm, to excite certain dyes or inks that will continue to emit radiation in the form of light for a short time once the source of excitement is no longer active. Fluorescence describes an ink that emits a longer wavelength of light during excitation, whereas phosphorescence describes the ability of an ink to continue to emit this light after the source of excitation is switched off. Capture of this phosphorescence relies on a frame delay, the time between t he source of excitation being switched off, and image capture. This frame delay can be determined by the user within the software. See: "Phosphorescence" on page 30. Nominal w avelength (nm) Colour Bandwidth ( 10%) Peak Ultraviolet (UV) 350 - 380... -
Page 24: Optical Filters
Optical Filters ® ® The VSC 90 contains 13 individual filters that are mounted on a wheel and controlled by the VSC software. Filter Types There are three filter types available, along with different light sources and illumination modes available ® within the VSC 90, allow for the document examiner to select precise wavelength ranges to view security features, or to determine the authenticity and integrity of a questioned document. Longpass Filter A longpass filter will block the shorter wavelengths and allow the longer w avelengths of light to transmit through the filter. Bandpass Filter A bandpass filter will block some of the shorter wavelengths and some of the longer wavelengths, allowing mid-range wavelengths of light to transmit through the filter. Shortpass Filter A shortpass filter will block the longer wavelengths and allow the shorter wavelengths of light to transmit through the filter. -
Page 25: Camera Filters
Camera Filters A range of camera filters are provided, mostly longpass filters with different wavelength cut-ons. For normal viewing, a shortpass or bandpass filter is used with the camera to mimic the view of the unaided eye. Cut-on wavelength 400 - 700 570 590 610 630 645 665 695 715 735 780 850 1000 (nm) (50%) Use of filter Visible filter for normal viewing Fluorescence examination and contrast enhancement. Fluorescence Examination For the safe viewing of fluorescence, a longpass filter with a cut-on wavelength that exceeds the long wavelength cut-off of the excitation light is required. There are many safe viewing filters for each waveband of excitation light, usually those with the shortest cut-on wavelength, although those with a longer cut-on may improve visual contrast. See: "Fluorescence Examination" on page 29. Recommended LED and camera filter combinations for viewing fluorescence. Blue - Deep Far Colour Violet Blue Cyan Green Orange Red White Green LED ... -
Page 26: User Guide
User Guide ® The VSC 90 and related software have been designed with the end-user in mind. The software is user friendly, icon-driven, with lots of different functions and the ability to customise and semi-automate the document examination process. ® Once the VSC 90 has been powered on, the software can be started. ® Double click the VSC 90 software icon to start the software. Selecting a User ® When the VSC 90 software has started, a window will open, prompting for the selection of a user. Use the drop-down menu to select an existing user profile. ® Import a profile from existing VSC software. Add a profile. This will open a dialog box for the creation of a new user profile. Once created, select add profile. Select the required user profile and select "Ok" to enter the main software. -
Page 27: Main Screen
Main Screen 1. Current applied settings 4. Camera menu 2. Gallery menu 5. Features menu 3. Environment menu 6. Main image viewer Current Applied Settings At the very top of the main screen, a green bar shows the profile of the user, the view and settings applied to the main viewing screen in the centre, and the current software version. Sign out. The current applied settings shows that the The current software image in the main viewer is live, with a white and version is shown here. Profile: The profile IR light source, and a visible light filter. selected here is "User". Sign Out ® Select this icon to sign out and close the VSC 90 software. -
Page 28: Gallery Menu Overview
Gallery Menu Overview 1. Stored images. 2. Save current image to the gallery. 3. Save current image to a specified location. 4. Import images to gallery. 5. Apply image settings to live image. 6. Record video. 7. Search images. 8. Remove images from gallery. 9. Save options. 10. Stop recording. Stored Images ® Images that have been taken and stored on the VSC 90 are accessible from the gallery menu. A scroll bar will allow for the user to scroll right or left to view more thumbnail images. Click on an image to select it. Selected images will have a yellow border. Double click an image to open it into the main image viewer. Save Current Image to the Gallery Selecting this icon will add an image from the live viewer to the gallery. -
Page 29: Search Images
Search Images Selecting this icon will allow for the filtering of images in the gallery based on light source or filter used. Remove Images from Gallery Selecting this icon will open a separate window where images can be selected and removed. Save Options Selecting this icon will open the save options, allowing for the save location of taken images to be determined. Stop Recording This icon becomes selectable once recording is in progress. Selecting this icon stops the recording, allowing for the recording to be played back in the main image viewer or saved to a specified destination. -
Page 30: Environment Menu Overview
Environment Menu Overview 1. Illumination modes. 2. Filters. 3. Light sources. 4. Add selected viewing conditions to an existing macro. See: "Macros" on page 55 The right pane is variable, and different filter options and lighting conditions can be selected depending on the active illumination mode and light source. The illumination mode or light source selected will be highlighted in orange. Any settings selected will show on the current applied settings bar at the top of the main screen. ... -
Page 31: Illumination Modes And Light Sources
Illumination Modes and Light Sources The mode of illumination can be selected from the right pane of the main screen. Once selected, the icon for the method in use will turn orange, and applicable light sources, filters and other options will be available. Illumination Light sources available mode IR 780 White UV 365nm IR 850 White + IR UV 308nm IR 940 IR (Activate all IR sources) UV 255nm IR 980 Left White + IR Left White Left I R ... -
Page 32: Ovd Lighting
Light sources requiring safety interlock activation: Flood UV 308 nm (UV-B) UV 255 nm (UV-C) Phosphorescence Anti-Stokes Infrared (980 nm) OVD Lighting The circular plot schematic of the OVD array is overlaid over the live image with the active light source being highlighted in yellow. The controls for the OVD lighting are visible when the light source is selected. Controls are located in the lower right corner of the environment menu. ... - Page 33 OVD Controls 1. Directional arrows: the active light source can be changed using the directional arrows on the OVD controls, or by selecting the required OVD light on the overlaid schematic. 2. OVD selector: Click to view the OVD schematic overlaid on the main image viewer. The overlay will disappear after 5 seconds. 3. OVD Sequence: another window will open, from which different sequences of OVD light can be selected or created. Sequences of OVDs are available from the OVD Sequence drop-down menu and include: All OVDs; Horizontal only; Vertical only. Any customised OVD sequences created can be selected from this list. Output options can also be selected from this window including: Composite image: overlays every OVD image, useful for including holograms / kinegrams in printed reports. Mosaic: this provides an image with thumbnails of every image taken, also useful for printed reports. Output individual: this will produce an output image for each OVD light selected. Output video: a video will be created of the document as each OVD is illuminated. 4. Sync video with live view. 5. OVD Scan: The OVDs will be illuminated in turn, and the time between image changes (1 - 5 seconds) can be selected. A drop- down box allows for the selection of either all OVDs, horizontal or vertical OVDs. Each new image will appear in the main image viewer. Select the time, OVDs, and use the start and stop functions. 6. Add to Macro. See: "Macros" on page 55...
-
Page 34: Spot Lighting
Spot Lighting Spot lighting is often used for the detection of fluorescence due to the light sources available. Underneath the filter selection is a fluorescence mode tick-box. When this is activated, the filter availability will change with each light source selected to offer the best possible detection of fluorescence. Blue - Deep Far Colour Violet Blue Cyan Green Amber Red White Green 395 - 420 - 475 - 490 - 540 - 600 - 625 - 680 - 420 - LED (10%) 450 - 520 Nominal 680 wavelength Camera (nm) filter (50%) Fluorescence Examination Spot lighting is a high-intensity coloured light source, that when used in combination with specific optical filters, can be used in the examination of fluorescence. Fluorescence scanning will interrogate the pixel intensity difference between two regions of a questioned document. Selecting Toggle Multi Lights will ... -
Page 35: Anti Stokes
Anti Stokes When anti stokes is selected, there are no selectable filter options. White light is active for document positioning prior to anti stokes activation. Select "On". This will activate the light source for up to 60 seconds. Each second of activation will require two seconds of cool- down, so 60 seconds of activation will require 120 seconds cool-down. The gain, or sensitivity to light, can be increased or decreased with the sliding bar. The colour of anti stokes fluorescence can be selected from the drop-down box. The colours available are blue, red, or green. Green is the most common form of anti stokes and is therefore the default option when the anti stokes light source is selected. Anti stokes and associated settings can be added to a macro. Phosphorescence When phosphorescence is selected, there are no selectable filter options. Selecting capture will activate the light source for a short length of time. Selecting the reset icon will allow for the main image to be reset for phosphorescence recapture. The frame delay, the length of time between the switching off of the light source and image capture. This can be increased or decreased with the sliding bar. The gain, or sensitivity to light, can be increased or decreased with the ... -
Page 36: Filters
Filters There are numerous filters available for each light source and wavelength selected. Cut-on wavelength 400 - 700 570 590 610 630 645 665 695 715 725 780 850 1000 (nm) (50%) Use of filter Visible filter for normal viewing Fluorescence examination and contrast enhancement. Camera Menu Overview 1. Camera Settings. 10. Reset Magnification. 2. Extended Camera Settings. 11. Zoom Presets. 3. Decrease Magnification. 12. Add Current Magnification to Preset. 4. Magnification Bar. 13. Delete a Preset. 5. Increase Magnification. 14. Show Histogram. 6. On Screen Magnification 15. Show Spectrum. 7. Document Thickness. 16. Show Camera Information. 8. Custom Zoom. 17. Reset Camera. 9. Refocus 18. Pause Live View. -
Page 37: Extended Camera Settings
Iris The iris controls how much light is taken in by the camera and influences the depth of field, also referred to as F-Stop. The depth of field denotes the distance at which the image is still in sharp focus. A smaller iris will result in a darker image and a deeper depth of field. A larger iris will result in a brighter image and a shorter depth of field. Auto Iris When selected, auto iris allows the software to adjust the iris and therefore the amount of light taken in by the camera. Focus The focus defines the clarity of an image and determines which areas of an image are sharp. Auto Focus When selected, auto focus allows the software to focus the camera on the object ® within the VSC Spot Focus Allows for the software to control the focus of the camera onto a single spot. Exposure Allows the user to override automatic exposure adjustments to make the image Compensation brighter or darker. Red Gain The gain determines the balance of light, dark and background noise within an image. A higher gain will result in a lighter image but increase the background noise. A lower gain will result in a dark image with less background noise. Use the slider to increase or decrease red gain. Blue Gain The gain determines the balance of light, dark and background noise within an image. A higher gain will result in a lighter image but increase the background noise. A lower gain will result in a dark image with less background noise. Use the slider to increase or decrease blue gain. Average Frames Each pixel in corresponding positions of multiple frames are averaged to create a ... - Page 38 Aperture The aperture is the hole created and controlled by the iris that allows the light to enter the camera to determine the depth of field. The depth of field denotes the distance at which the image is still in sharp focus. A lower aperture will result in a darker image and a deeper depth of field. A higher aperture will result in a brighter image and a shorter depth of field. Chroma Chroma refers to the purity of a colour, and chroma suppression is similar to Suppression saturation control. A hue with high chroma has no black, white or grey added to it. The higher the chroma suppression, the more black, white or grey is added to reduce the saturation of colours with a high chroma. Using chroma suppression will selectively desaturate specific high chroma colours, leaving other colours unaffected. It is used to remove false colours that may be visible on the edges of lines. Colour Gain Colour gain controls the intensity of colours within an image. Increasing colour gain will make colours appear more vibrant whereas decreasing colour gain will reduce the intensity of colours. Adjusting the colour gain will equally affect all colours within an image to increase or reduce colour intensity. Defogging Apply a defogging algorithm to reduce the effects of haze, smog, or other particles in the air that scatter and attenuate light to enhance the clarity of a captured image. The hue denotes the overall colour tint of an image. Noise Noise is defined as random and unwanted variations in brightness or colour that can Reduction make an image appear grainy, usually when an image is taken in low-light. Noise reduction involves the application of a digital filter that helps to reduce this noise and improve image clarity. Backlight This allows for the reduction of the effects of a strong backlight, or to increase light Compensation exposure for darkened areas, to improve the overall exposure of the image. High ...
-
Page 39: Magnification
Magnification Select the +/- to increase or decrease the current magnification. Select an area of the magnification bar to jump to that magnification. Alternatively, click, hold and drag the marker on the magnification bar to increase the magnification dramatically. On Screen Magnification ® When the VSC 90 is properly calibrated, the on-screen magnification values will be displayed underneath the zoom bar. Document Thickness Document thickness can be amended using the + / - icons to match the thickness of the document in question. Amending the document thickness will alter magnification and calibrations. Custom Zoom Using the keyboard, enter the desired zoom and press enter. Refocus ® The VSC 90 features a software controlled motorised lens that allows for auto-focusing. If the image does not appear to be in focus, select this icon to force a re-focus of the image. Reset Magnification Select this icon to reset the magnification to either the selected preset or the default magnification upon start-up. Zoom Presets ... -
Page 40: Show Histogram
Show Histogram Show the histogram of the image as an overlay. Show Spectrum Show the spectrum of the image as an overlay. Show Camera Info Show the camera information of the image as an overlay. Reset Camera Resets all camera settings back to default. Pause Live View This allows the live image to be paused. The image will be bordered by a red box when the live image is paused. Select the icon again to return to live view. -
Page 41: Features Menu Overview
Features Menu Overview 1. Quick capture. 2. MRZ (Machine readable zones). 3. Barcodes. 4. IPI (Invisible personal information). 5. Latent image. 6. Background removal. 7. 3D. 8. Currency. 9. Documents. 10. MSFI. 11. Compare. 12. Assure ID. 13. Macros. 14. Calibrate. 15. App Settings. 16. Diagnostics. 17. Image Settings. 18. Tools. 19. Text. 20. ... -
Page 42: Quick Capture
Quick Capture When selected, the quick capture window will open. Speeding up the process of multiple image capture, quick capture is designed to select multiple light sources, filters and OVD sequences. The images are then captured quickly and saved to the gallery without further user intervention. Select any combination of light sources, illumination modes and filters. Images will be captured with each of these settings applied in turn. -
Page 43: Mrz (Machine Readable Zones)
MRZ (Machine Readable Zones) Used to read MRZs within identity documents to determine if it conforms to ICAO (International Civil Aviation Organization) standards. Expected information is compared with the optical information obtained from the MRZ. The software reports errors on-screen and provides diagnostic tools to help users determine genuine nonconformity. Matches will be flagged with a green tick, and any issues will flag with a red cross. The validation process uses the standards specified in the ICAO document 9303 for Machine Readable Travel Documents. MRZ controls "Retry MRZ" will prompt reading of the MRZ after a failed attempt. "Save" will open a dialog box for the MRZ information to be saved to a specified location. "Edit MRZ" allows for the editing of any misread MRZ's. A window will open where the MRZ can be edited: Select an area with the mouse and use the keyboard to correct any misreads. ... - Page 44 "Default" returns the MRZ to the optical MRZ. "Test" will compare the MRZ to the ICAO standards. "Save" allows the MRZ to be saved. "Cancel" will return to the previous screen without editing the MRZ. "Read EChip" will prompt any connected E-chip readers to obtain the E-chip data for comparison with the optical MRZ. "Save PDF" will save the MRZ data as a PDF file. Select the save destination as required. "LS++" will open the LetterScreen++ controls: This will allow for the selection of the LetterScreen++ area by clicking and dragging the cursor from top-left to bottom-right and ensuring the entire image is inside the red box. Select the "LS++" button. Changing the colour table using the drop-down list allows for the selection of the pigment colour used in the LetterScreen feature. This can improve the capability of the software to detect the LetterScreen++ feature. However, RGB is the optimum setting and this should rarely need changing. "Pattern found" will display a green tick if positive, and a red cross if negative. "Save" will allow the LetterScreen++ to be saved. "Save PDF" will save the LetterScreen++ data into an individual PDF report. "Add to Macro" will add the LetterScreen++ function to a Macro, see: "Macros" on page 55. "Add to Macro" will allow MRZ reading to be added to a macro. See: "Macros" on page 55. "Image" will allow for the capture of an image of the MRZ.
-
Page 45: Barcodes
Barcodes This can be used to read one and two-dimensional barcodes, including QR codes. Select the barcodes icon to start. 1. Click and drag from the top-left to the bottom-right of the barcode. A red box should surround the barcode. 2. Select Scan, located on the right working pane, to read the barcode. 3. If needed, specific decoders can be selected from the drop-down menu in the working pane. 4. Barcode information will be visible in this right-hand working pane. 5. The barcode and information can be saved, cleared, or the process added to a Macro using: Save, Save PDF, Clear or Add to Macro. ... -
Page 46: Ipi (Invisible Personal Information)
IPI (Invisible Personal Information) IPI is used to decode invisible personal information, or scrambled indicia, usually used within passport images, identity cards and stamps. 1. A red rectangle will appear on screen surrounding the image. Ensure the image is fully inside the red border. The red border can be manually adjusted by clicking and moving with the mouse to ensure the best fit. 2. A preset can be selected from the drop-down menu on the right side. Presets may be added, amended or removed using the relevant buttons. 3. Either use the auto decode IPI function, or manually adjust the pitch and the angle on the software using the +/- or click and drag on the sliding bar until the information is clear. The decoded IPI will be visible using the control area on the right. 4. Save, save individual report to PDF, add to Macro or set current zoom to default Digital IPI Digital IPI can also be decoded using the IPI feature. If an identity document contains Digital IPI, select Digital IPI from the controls. The PI and decoded two- dimensional barcode information will display on the right. -
Page 47: Latent Image
Latent Image Some documentation will contain hidden images, and this function applies a digital filter to the image. This can apply a false colour and the angle can be changed or oscillated to better view the latent image. If oscillation is selected, then the angle applied to the software will cycle for a document examiner to better view a latent image. Without latent With latent image Enhanced: Enhanced and image viewer: viewer: False Colour: ... -
Page 48: Background Removal
Background Removal Removal of patterned backgrounds can increase the quality of the foreground images or text. 1. Select this icon to start the background removal process. 2. Click and drag from top-left to bottom-right to draw a red box around the area of interest 3. Select confirm crop in the top-right corner of the main image viewer. 4. Select the pattern type to remove: line, dots, grid or band. 5. Select the area to remove: foreground or background. 6. View the image in colour or greyscale. 7. Amend the angle, density, upper and lower limits using +/- or click and drag on the associated sliding bar. 8. Select back to gallery at the bottom-right of the screen to return to the live view. ... -
Page 49: Face Matching
Face Matching ® The VSC software uses the Gemalto LFIS face recognition system to enable the comparison of faces from digital eChip images, passport photographs, live images from a webcam, and any stored images. 1. Open the LFIS face matching software. 2. Select this icon to upload up to 3 stored images for face matching, 3. Select this icon to upload an image from the live view. 4. Select this icon to upload an image from a connected web cam. 5. A match or mismatch will be demonstrated with a green tick or red cross, along with a measure of confidence in the match denoted as a percentage. 6. Select save to open a new window to determine a save location for a brief report containing all image comparisons and results. 7. Select save PDF to open a new window to determine a save location for a full PDF report, with company logos, containing all image comparisons and results. - Page 50 3D can be used to scan the surface of an item or a document. This can be used in the determination of order of line deposition ® 1. Place the document or item inside the VSC ® 2. Select 3D, and allow the VSC 90 to scan the item. 3. Once the item has been scanned, the scan will open inside the FF3D software. 4. Select the area of interest and select generate. 5. The FF3D software will allow the user to move the 3D scan around, change the lighting and overlay false colours. Please refer to the user manual within the help section of the FF3D software for more information. ...
-
Page 51: Currency
Currency Compare currency under different lighting conditions to a database provided by ® Keesing t o determine authenticity. Once currency is selected, the screen will be divided in two. The live (or stored) image being examined will be open on the left and the database with database controls will be open on the right. The currency being displayed is noted above the database image. Directional arrows are used to navigate the database and view different currencies. Select different lighting conditions for the front or back of the currency. Options include: Flood Front. Flood Back. UV Front. UV Back. Rotate image clockwise 90°. Search currency by issuer, currency type, material, issuing bank, country of origin and date of circulation. ... - Page 52 Lists the information for the currency being displayed by the database. Add stored image to a custom database. Select the stored image or images to be added to the custom database. Select the down arrow and complete details as required. Apply image settings used within the database to the live image. Edit the details of an item within the custom database. Remove selected item from the custom database.
-
Page 53: Documents
Documents Compare identity documents under different lighting conditions to a database ® provided by Keesing t o determine authenticity. Once documents is selected, the screen will be divided in two. The live (or stored) image being examined will be open on the left and the database with database controls will be open on the right. The document type and location being displayed is noted above the database image. Directional arrows are used to navigate the database and view different documents. Select different lighting conditions for the front of the document. Options include: Flood Front. IR Flood Front. UV Flood Front. Rotate image clockwise 90°. Search document by issuer, type, Echip, single or double sided, country of origin, a nd date of circulation. ... -
Page 54: Keesing Database Update
Lists the information for the document being displayed by the database. Add stored image to a custom database. Select the stored image or images to be added to the custom database. Select the down arrow and complete details as required. Apply image settings used within the database to the live image in the right-hand pane. Edit the details of an item within the custom database. Remove selected item from the custom database. Keesing Database Update Information to be confirmed. -
Page 55: Magnetic Security Feature Imager
Magnetic Security Feature Imager Used for the visualisation of magnetic inks which may be used in the creation of some documents and banknotes, such as the US Dollar. ® This function is available on every VSC 90, but an MSFI reader is required, but provided separately. There is no light source used for this feature, visualisation is instead achieved using the MSFI reader placed directly on top of the document in question within the ® ... -
Page 56: Compare
Compare Compare is used to determine similarities and differences between two images. A live ® image from the VSC 90 can be opened alongside a stored image from the gallery for comparison. Alternatively, two images from the gallery can also be opened and compared. ... - Page 57 Control icons (right) 1. Live view: open the live view as image 1. Double click an image from the gallery menu and select either 1 or 2 to open it as that image. 2. Automatically detect differences in orientation and scale and position image 1 to match image 2. 3. Images 1 and 2 will be displayed side-by-side. 4. View image 1. 5. View image 2. 6. Strobe: alternate viewing of images 1 and 2, for a few seconds at a time. 7. Flip: swap which images are images 1 and 2. 8. Horizontal split: both images are opened into the same viewing window and a split bar can be moved up or down to view more or less of one image. 9. Vertical split: both images are opened into the same viewing window and a split bar can be moved left or right to view more or less of one image. 10. Overlay: overlay images 1 and 2. Transparency of images can be controlled using the click and drag bar at the bottom of the screen when in overlay mode. 11. Overlay with false colour: overlay images 1 and 2, with a magenta wash being applied to image 2. Transparency of images can be controlled using the click and drag bar at the bottom of the screen when in overlay mode. 12. Overlay with colour inversion: overlay images 1 and 2, with image 2 being inverted and subtracted from image 1. ...
-
Page 58: Assureid
™ AssureID ™ Opens a database provided by Acuant AssureID to authenticate identity documents from other providers. A separate licence is required to access and use this database. 1. Enter the questioned ID document and select the relevant magnification preset. 2. A new pane will open to the right of the main image viewer. Select "Capture Images" to begin. 3. Images will be automatically taken of the ID with white light, infrared and ultraviolet. 4. Select Open Acuant to open the third party AssureID™ software. 5. Another window will open with a prompt to click and drag a red box around the datapage, and select confirm. - Page 59 6. Ensure that the correct lighting type is assigned to each image using the drop-down boxes. 7. Select "Analyse Selected Images". 8. AssureID™ will provide a pass/check/fail for all points of investigation denoted by a green tick, orange exclamation mark, or red cross.
-
Page 60: Macros
Macros Select this icon to view, amend and delete macros. Macros are a pre-determined set of instructions that can be applied whenever the macro is selected and applied. 1. Select + to add a macro. 2. Name the macro. 3. Select the light source to open another window. 4. Add, amend, or remove steps as required to create a personalised sequence of events that will be carried out whenever the macro is selected. 5. Run Macro (bottom-right corner). -
Page 61: App Settings
App Settings ® Select this icon to view and amend the settings for the VSC 90 software. Changes may require the software to restart. Amend language, theme and save settings as required. Select the app settings icon again to close. ® Use the report manager to set up reporting within the VSC 90 software. To enable extended camera settings, select "Workspace Customisation". Under the heading "Advanced", select the check box labelled "Extended Camera Settings". Select and change any required settings with the use od the check boxes and drop-down boxes. -
Page 62: Annotations
Annotations When an image from the gallery is open in the main image viewer, the annotations icon is available. When selected, a floating window opens over the right of the image and allows for the addition of shapes, highlighting and text to be added to an image. Shapes and arrows can be overlaid onto captured images to identify areas of interest within a document. These shapes can be coloured, moved and resized. Text can be added to provide further information to the images. Other controls include undo, redo, remove, delete, send to front, send to back, and save. These controls can be applied to any annotation once selected. Measurements can also be applied to an image by selecting one of the measurement icons. -
Page 63: Image Settings
Image Settings From the image settings, the brightness, contrast, gamma, hue and saturation can be amended. Click and drag on the sliding bar to amend these settings. Select the relevant tick boxes to apply additional settings. Brightness Increases or decreases the overall lightness of an image. Adjust as required or select reset to return settings to default. Contrast The contrast of an image is the difference between the light and dark areas. Adjust as required or select reset to return settings to default. Gamma Gamma corrections control image brightness to brighten darker areas of an image. Gamma corrections are particularly helpful when using light sources that stimulate fluorescence. Adjust as required or select reset to return settings to default. The hue denotes the overall colour tint of an image. Adjust as required or select reset to return settings to default. Saturation Saturation controls the colour intensity of an image. Adjust as required or select reset to return settings to default. Digital zoom Adjust the slider as required to apply a digital zoom to the main image. Sharpen The software will compare and determine differences in brightness, and increase the contrast between adjacent pixels to improve image clarity. Blur The software will add blur to make the image less sharp and reduce the amount of detail. Erode The software will erode away the boundaries of the foreground object, useful for ... -
Page 64: Tools
Invert Invert the colour of each pixel in the image to its complementary colour. This may also be known as a negative. Mirror Horizontally flip an image. Horizontal Mirror Vertical Vertically flip an image. Equalise A computer image processing technique used to improve contrast in images by Histogram spreading out the most frequent intensity values. Show Select to show the cross-hairs in the centre of the live image overlay for ease of Crosshairs aligning evidence. Show Edge Select to show alignment lines on the edges of the live image overlay for ease of Markers aligning evidence. Grid Select to show a grid on the live image overlay for ease of aligning evidence. Ruler Apply a ruler overlay. Binarise Images are converted into a binary black and white image based on the pixel value of the original. Pixel Intensity Also known as a histogram, the pixel intensity chart demonstrates the number of Chart pixels in an image at each different intensity value. -
Page 65: Text
High Dynamic Range involves taking and combining multiple images captured at different exposures to create an image that best mimics colours and brightnesses as seen by the human eye. Merge Focal Planes Create a single deep-focus image from a stack of images taken at different depths of field. Composite Create a composite image overlaying two or more images to create a single image. False Colour Create a composite image with rearranged colour channels. The final image does not reflect the colours of the original. MIC / CPS Machine Identification Code / Counterfeit Protection System will exaggerate the yellow tracking dots on printed items. Text The text icon allows for the addition of text, or notes, to an image. The position, alignment, font, colour and size of this text can be changed. Add Notes This opens a window containing a notepad. This notepad can be moved around or pinned to the right side of the main image viewer. Notes can be added, saved, or discarded. Calibrate Measurement This will open a small window for the input of a known measurement from a scale or ruler within the image. This will allow for the calibration of measurements, allowing subsequent direct measurement of on-screen features. -
Page 66: Vsc®90 Overview
® 90 Overview ® This is an overview image of the VSC 90. The illustration will reflect the state of the unit, such as if the front or side flaps are open. - Page 67 Keep in touch with foster+freeman Ltd: https://www.youtube.com/user/fosterfreeman https://twitter.com/fosterfreeman https://www.facebook.com/fosterandfreeman/ https://www.instagram.com/fosterfreemanforensics/ https://uk.linkedin.com/company/foster-freeman...
-
Page 68: Revision History
Revision History Revision Revision Date Description of Change Author TBC/09/2024 Initial release Approval Marketing ...
