Memotec AiM ECULog User Manual

Hide thumbs

Advertisement

Table of Contents

User Manual
AiM ECULog | Data Logger
BA
memotec GmbH
Bauwaldstrasse 1
D-75031 Eppingen
+49.7260.920440
info@me-mo-tec.de
www.me-mo-tec.de

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AiM ECULog and is the answer not in the manual?

Questions and answers

Summary of Contents for Memotec AiM ECULog

  • Page 1 User Manual AiM ECULog | Data Logger memotec GmbH Bauwaldstrasse 1 D-75031 Eppingen +49.7260.920440 info@me-mo-tec.de www.me-mo-tec.de...
  • Page 2 User Manual ECULog Release 1.02...
  • Page 3 INDEX 1 – ECULog in a few words 2 – Available kits 3 – ECULog expansions and connections 4 – Configuration with RaceStudio 3 software 4.1 – Channels configuration 4.2 – ECU Stream configuration 4.3 – CAN Expansions configuration 4.4 – Math channels configuration 4.5 –...

  • Page 4: Available Kits

    1 – ECULog in a few words ECULog is a little, light and easy to use logger that samples and records channels coming from the vehicle ECU and from the connected CAN expansions It records the data both into the internal 4GB not volatile memory and in the USB-C memory card. ECULog allows the user to create math channels as well as a CAN Output using both the channels supplied by the vehicle ECU and these supplied by AiM CAN Expansions.
  • Page 5 ECULog OBDII kit: part number X08ECULOGOBD200 • ECULog (1) • 2m CAN/OBDII +power cable (2) • 2m USB 2.0 Type A-Type C cable (3) • 16GB Mini USB Drive (2) Accessories and spare parts: • V02.589.050 2m CAN/RS232 +power cable •...
  • Page 6 3 – ECULog expansions and connections ECULog supports the following AiM expansions: • GPS09c Pro • GPS09c Pro Open Module • LCU One CAN • LCU1 • Channel Expansion • • ACC2 • ACC2 Open The image below shows an example of AiM CAN Network.
  • Page 7 4 – Configuration with RaceStudio 3 software To configure ECULog follow these steps: • run RaceStudio 3 • press “New” button on the top right keyboard (1) • select ECULog (2) • press “OK” (3) • name the configuration if desired (default name is ECULog – 4) •...

  • Page 8: Channels Configuration

    4.1 – Channels configuration • Once the configuration created, the software enters “Channels” tab. It shows GPS channels, as well as odometer and it is possible to specify the fuel level. For these information to be available it is mandatory: •...

  • Page 9: Ecu Stream Configuration

    4.2 – ECU Stream configuration Entering “ECU Stream” tab a panel where to choose the connected ECU is prompted. Selecting an ECU that supplies information about fuel level the software informs the user as shown above and the corresponding channel is enabled in “Channels”...
  • Page 10 4.3 – CAN Expansions configuration Entering “CAN Expansions” tab a selection panel is prompted.
  • Page 11 Each expansion needs to be configured through the dedicated panel. In the following pages they are shown. Please refer to the single user manuals for further information. LCU One CAN setting panel. It is possible to select the multiplier to calculate AFR from lambda and add a custom value.
  • Page 12 Channel Expansion and ACC, ACC2 (all versions) are mutually exclusive; this is why setting one of them the others will not be available in CAN Expansions list. Channel Expansion channels can be set as digital or as analog.
  • Page 13 ACC ,ACC2 (all versions) and Channel Expansion are mutually exclusive; this is why setting one of them the others will not be available in available CAN Expansions list. ACC setting panel. Clicking on each channel a configuration panel is prompted.
  • Page 14 ACC2 and ACC2 Open can support up to four thermocouple. Selecting the number of thermocouple sensors it is supposed to connect the corresponding channels in the table bottom of the view switches to temperature channel; the remaining channels are configurable using the configuration panel that is prompted clicking the corresponding channel row in the table.
  • Page 15 4.4 – Math channels configuration As for any other AiM logger it is possible to add Math channels choosing them in a wide library. This can be done using the channels provided by the vehicle ECU or adding and configuring optional custom sensors. To create math channels;...
  • Page 16 4.5 – Status Variables configuration As any AiM logger ECULog allows to set different Status Variables. To do so press “Add Status Variable” button and fill in Name and display label. Status variable values can also be recorded enabling the related top left checkbox (highlighted below). They can work as: •...
  • Page 17 As shown here below Momentary and toggle working mode only allows to generate a square wave whose duration of each status can be customized.
  • Page 18 When the status variable is set as Multiposition the different positions as well the time threshold (if desired) need to be set. On the contrary activation/deactivation conditions, possibility to record values and condition type are the same of Momentary and Toggle working mode.

  • Page 19: Parameters Configuration

    4.6 – Parameters configuration Parameters Tab allows to set: Lap Detection (1): you can set the seconds the lap time is hold on the display; available options are: • from GPS: track width needs to be filled in • from optical beacon: it is possible to set a time period during which additional lap signals are ignored to avoid double lap time recording.
  • Page 20 4.7 – SmartyCam Stream ECULog can be connected to both AiM SmartyCam 2 and SmartyCam 3 through the CAN Bus to show the desired data on SmartyCam video. The logger transmits data to the Cameras in two slightly different ways according to the camera and to the fixed setting. Available options are: •...
  • Page 21 To transmit a different set of information a SmartyCam 3 with advanced setting is needed; please note: this function is for expert users only. Please follow this procedure: • configure ECULog in order to transmit a different SmartyCam stream • select the SmartyCam stream in SmartyCam 3 configuration •...
  • Page 22 5 – Dimensions, pinout and technical characteristics The image below shows ECULog dimensions in mm [inches].
  • Page 23 The image below shows ECULog pinout. Technical characteristics: • ECU connection: CAN, RS232 or K-Line to 1.000+ industry leading ECUs • Expansions: Channel Expansion, ACC, ACC2, LCU-One CAN, LCU1, SmartyCam 3 Series, GPS09c/GPS09c Pro Module • External Power: 9-15 C •...
  • Page 24 GmbH Bauwaldstrasse 1 D-75031 Eppingen +49.7260.920440 info@me-mo-tec.de www.me-mo-tec.de...
