USER AND MAINTENANCE MANUAL
Manufacturer:
SIEM - NOVA SRL - 20089 ROZZANO (MI)
Product: Smoke filtration system - Mod. FILTRUM®
ASSISTANCE
Read the instruction manual before using the device.
This manual should be kept close to the device for future reference.
SIGNS AND SYMBOLS - ISO 15223-1:2021(E)
In compliance with the
2017/745 MDR regulation
concerning medical devices.
CLASS I
Symbol for
"MANUFACTURING DATE"
(4 digits for the year, 2 for
the month and 2 for the
day)
Symbol for
"MANUFACTURER"
This symbol indicates that
there may be interference
close to the device
This symbol indicates the
pressure limitation for
operation, transport and
storage
This symbol indicates that
the device is a medical
device
This symbol indicates the
reference number of the
medical device
This symbol indicates that at
the end-of-life, the device
must be disposed of
according to local disposal
regulations
1 WARNINGS AND SAFETY INSTRUCTIONS
1.1 APPLICATION
The Smoke filtration system Model "FILTRUM®" is approved exclusively for the use as described in this user and maintenance
manual. SIEM – NOVA SRL can only guarantee the safe functioning of the device when it is used with the SIEM – NOVA SRL
accessories and components.
PLEASE READ AND OBSERVE THESE WARNINGS AND SAFETY INSTRUCTIONS BEFORE USING THE DEVICE.
1.2 Please note that these instructions for use are a general guide for the use of the device. Medical
information must be addressed to a doctor.
1.3 WARNING: The product has been designed with particular attention to patient and user safety.
Nevertheless, the following warnings must be observed
IMPORTANT: Users must be able to read, understand and follow the directions in this manual and the instructions
provided by your doctor. If you are dependent on the device for airway aspiration and stopping operation of the
device may lead to a critical situation, you must have another device available that can operate in an emergency.
Revision: 01 - 31.01.2024
VARALLI 1 (ITA) - Italy
- VIA
Code: 81000
This symbol indicates an
insulation class I device
This Symbol indicates a
type B applied part
This symbol indicates
alternating current
Do not reuse / for
disposable use only
This symbol indicates
the moisture limitation
for operation, transport
and storage
Unique Device Identifier
This symbol indicates
the serial number of the
medical device
This symbol indicates to
avoid wetting the device
.
Reproduction forbidden
This symbol indicates to
follow the instructions.
This symbol indicates
"warning or caution"
with the use of the
device
This symbol indicates
the footswitch
This symbol indicates to
avoid direct exposure of
the device to sunlight
This symbol indicates
the temperature
limitation for operation,
transport and storage
This symbol indicates
the model of the
medical device
Degree of protection of
IP21
the casing of the DM
CEI EN 60529/1997
This symbol indicates
the distributor's name
Page: 1 of 11
